STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
SPTM
R255 1-216-049-11 RES-CHIP 1K 5% 1/10W
R278 1-216-022-00 METAL CHIP 75 5% 1/10W
R279 1-216-022-00 METAL CHIP 75 5% 1/10W
R290 1-216-097-11 RES-CHIP 100K 5% 1/10W
R296 1-216-295-91 SHORT 0
R297 1-216-295-91 SHORT 0
R298 1-216-295-91 SHORT 0
R296 1-216-295-91 SHORT 0
<PIN>
TP201 1-784-921-11 PIN, CONNECTOR 4P
<VIBLATOR>
X202 1-781-821-21 VIBRATOR, CRYSTAL (14.31818MHz)
(DA3ES,DA5ES)
******************************************************
A-4476-706-A SPTM BOARD, COMPLETE (DA3ES,DA5ES)
A-4476-707-A SPTM BOARD, COMPLETE (VA555ES)
******************************
<CAPACITOR>
C511 1-130-471-00 MYLAR 0.001uF 5% 50V
(VA555ES)
C561 1-137-503-11 MYLAR 0.001uF 5% 50V
(VA555ES)
C615 1-137-503-11 MYLAR 0.0001uF 5% 50V
(VA555ES)
C665 1-137-503-11 MYLAR 0.0001uF 5% 50V
(VA555ES)
C715 1-137-503-11 MYLAR 0.0001uF 5% 50V
(VA555ES)
C765 1-137-503-11 MYLAR 0.0001uF 5% 50V
(VA555ES)
<CONNECTOR>
CN651 1-785-102-11 PIN, CONNECTOR 4P (DA3ES,DA5ES)
CNP506 1-784-921-11 PIN, CONNECTOR 4P
CNP507 1-784-922-11 PIN, CONNECTOR 5 P
CNS506 1-784-776-11 CONNECTOR, FFC 15 P
<DIODE>
D540 8-719-988-61 DIODE 1SS355TE-17
D541 8-719-988-61 DIODE 1SS355TE-17
D542 8-719-988-61 DIODE 1SS355TE-17
D543 8-719-988-61 DIODE 1SS355TE-17
D544 8-719-988-61 DIODE 1SS355TE-17 (DA3ES,DA5ES)
D545 8-719-988-61 DIODE 1SS355TE-17
D598 8-719-988-61 DIODE 1SS355TE-17
D607 8-719-988-61 DIODE 1SS355TE-17
D657 8-719-988-61 DIODE 1SS355TE-17
D667 8-719-988-61 DIODE 1SS355TE-17 (DA3ES,DA5ES)
D707 8-719-988-61 DIODE 1SS355TE-17
<COIL>
L501 1-419-666-11 COIL, AIR-CORE
L551 1-411-906-11 COIL, AIR-CORE
L601 1-411-906-11 COIL, AIR-CORE
L651 1-419-666-11 COIL, AIR-CORE
L701 1-419-666-11 COIL, AIR-CORE
L751 1-411-906-11 COIL, AIR-CORE
<TRANSISTOR>
Q598 8-729-230-49 TRANSISTOR 2SC2712-YG
Q611 8-729-230-49 TRANSISTOR 2SC2712-YG
Q621 8-729-230-49 TRANSISTOR 2SC2712-YG (DA3ES,DA5ES)
Q661 8-729-230-49 TRANSISTOR 2SC2712-YG
Q707 8-729-230-49 TRANSISTOR 2SC2712-YG
<RESISTOR>
0 R511 1-249-389-11 CARBON 4.7 5% 1/4W F
0 R512 1-249-393-11 CARBON 10 5% 1/4W F
(VA555ES)
0 R561 1-249-389-11 CARBON 4.7 5% 1/4W F
0 R562 1-249-393-11 CARBON 10 5% 1/4W F
(VA555ES)
0 R584 1-249-393-11 CARBON 10 5% 1/4W F
R585 1-216-073-91 RES-CHIP 10K 5% 1/10W
R586 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R589 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
0 R616 1-249-393-11 CARBON 10 5% 1/4W F
(VA555ES)
0 R631 1-249-389-11 CARBON 4.7 5% 1/4W F
R632 1-216-073-91 RES-CHIP 10K 5% 1/10W
R633 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
0 R634 1-249-393-11 CARBON 10 5% 1/4W F
R642 1-216-073-91 RES-CHIP 10K 5% 1/10W
(DA3ES,DA5ES)
0 R644 1-249-393-11 CARBON 10 5% 1/4W F
(DA3ES,DA5ES)
R645 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
(DA3ES,DA5ES)
0 R655 1-249-389-11 CARBON 4.7 5% 1/4W F
0 R666 1-249-393-11 CARBON 10 5% 1/4W F
(VA555ES)
R682 1-216-073-91 RES-CHIP 10K 5% 1/10W
R683 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
0 R684 1-249-393-11 CARBON 10 5% 1/4W F
0 R716 1-249-393-11 CARBON 10 5% 1/4W F
(VA555ES)
0 R731 1-249-389-11 CARBON 4.7 5% 1/4W F
R732 1-216-073-91 RES-CHIP 10K 5% 1/10W
R733 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
0 R734 1-249-393-11 CARBON 10 5% 1/4W F
0 R766 1-249-393-11 CARBON 10 5% 1/4W F
(VA555ES)
0 R781 1-249-389-11 CARBON 4.7 5% 1/4W F
<RELAY>
RY503 1-515-920-11 RELAY (24V)
RY601 1-515-920-11 RELAY (24V)
RY651 1-515-920-11 RELAY (24V)
RY661 1-515-920-11 RELAY (24V) (DA3ES,DA5ES)
RY702 1-515-920-11 RELAY (24V)
*****************************************************
A-4727-021-A SUB DSP BOARD,COMPLETE (DA5ES/VA555ES)
**********************************
<CAPACITOR>
C9001 1-165-319-11 CERAMIC CHIP 0.1uF 50V
S-VIDEO
SUB DSP
