Sony STR-DE135 - IC Pin Function Description

– 26 –
5-8. IC PIN FUNCTION DESCRIPTION
• DISPLAY BOARD IC201 µPD78044FGF-115-3B9 (SYSTEM CONTROLLER, FL DRIVER)
Pin No. Pin Name I/O Description
1 to 7
DIG7 to DIG1 O Digit drive signal output to the fluorescent indicator tube (FL201)
8
VDD — Power supply terminal (+5V)
9 S.CLK
O
Serial data transfer clock signal output to the LC78212 (IC401), PLL IC on FM/AM tuner pack
“L” active
10 S.DATA
O Serial data output to the LC78212 (IC401), PLL IC on FM/AM tuner pack “L” active
11 PLL.DATA
I Serial data input from the PLL IC on FM/AM tuner pack “L” active
12
S.CE (LC7822) O
Serial chip enable signal output to the LC78212 (IC401), PLL IC on FM/AM tuner pack
“H” active
13 S.CE (LV1010)
O Serial chip enable signal output terminal “L” active Not used (pull down)
14
REAR-RY O Relay drive signal output for the rear side speaker “H”: relay on Not used (open)
15
BRIDGE O Bridgeable relay drive signal output terminal “H”: relay on Not used (open)
16 PROTECT
I Over load detect signal input from the protect circuit “L”: protect detect
17
RESET
I
System reset signal input from the reset signal generator (IC950, Q201) “L”: reset
For several hundreds msec. after the power supply rises, “L” is input, then it changes to “H”
18 AUTO-STOP
I Tuned display detection signal input from the FM/AM tuner pack “L”: tuned
19 STEREO-IN
I Stereo detection signal input from the FM/AM tuner pack “L”: stereo
20 AVSS
— Ground terminal (for A/D converter analog system)
21 SP-RY
O Relay drive signal output for the speaker protect “H”: relay on
22 SURR-RY
O Relay drive signal output for the surround speaker “H”: relay on Not used (pull down)
23 POWER-RY
O Relay drive signal output for the power on/off control “H”: relay on
24 SIGNAL
I FM and AM signal meter voltage detection signal input from the FM/AM tuner pack
25 A/D-4
I
Key input terminal (A/D input) S210 (NAME) key input
(Used for the AEP and UK models only)
26 A/D-3
I
Key input terminal (A/D input) S231 to S239 (BASS BOOST, MUTING, SHIFT, 0, MEMORY
or MEMORY/ENTER, CD, MD/TAPE, TV/SAT or TV/LD, RDS PTY) keys input
(S239 RDS PTY key: used for the AEP and UK models only)
27 A/D-2
I
Key input terminal (A/D input) S221 to S230 (FM or FM/AM, 6, 5, 4, 7, 8, 9, FM MODE,
VIDEO, TUNER) keys input
28 A/D-1
I
Key input terminal (A/D input) S211 to S220 (DISPLAY, AM or RDS EON, 3, 2, 1, TUNING
or TUNING/CHAR –/+, PRESET TUNING or PRESET/PTY SELECT –/+, DIRECT) keys input
(S211 DISPLAY key: used for the AEP and UK models only)
29
AVDD — Power supply terminal (+5V) (for A/D converter analog system)
30 AVREF I
Reference voltage (+5V) input terminal (for A/D converter)
31
RDS DATA IN I RDS data input from the RDS decoder (IC1) (Used for the AEP and UK models only)
32
OPEN — Not used (open)
33
GND — Ground terminal
34
X1 I Main system clock input terminal (4.19 MHz)
35
X2 O Main system clock output terminal (4.19 MHz)
36
WOFER RLY O Relay drive signal output for the woofer speaker “H”: relay on Not used (open)
37
LED SELECT O LED select signal output terminal “H” active Not used (open)
38
DOLBY LED O LED drive signal output terminal “H”: LED on Not used (open)
39
C STUDIO LED O LED drive signal output terminal “H”: LED on Not used (open)
40
HALL LED O LED drive signal output terminal “H”: LED on Not used (open)
41
ENTER LED I Not used (fixed at “L”)
42
VOL DOWN O
Motor drive signal (volume down direction) output to the volume motor drive (IC202)
“H” active
43
VOL UP O
Motor drive signal (volume up direction) output to the volume motor drive (IC202)
“H” active
