Sony STR-DE135 - Main Board Parts List (Capacitors)

– 33 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
A-4419-005-A MAIN BOARD, COMPLETE (US)
A-4419-179-A MAIN BOARD, COMPLETE (AEP, UK)
*********************
3-905-609-01 SCREW (TRANSISTOR)
4-812-134-00 RIVET (DIA. 3.5), NYLON
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C3 1-162-288-31 CERAMIC 330PF 10% 50V
(AEP, UK)
C4 1-126-961-11 ELECT 2.2uF 20% 50V
(AEP, UK)
C5 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C6 1-162-291-31 CERAMIC 560PF 10% 50V
(AEP, UK)
C7 1-102-527-11 CERAMIC 82PF 5% 50V
(AEP, UK)
C8 1-102-852-91 CERAMIC 47PF 5% 50V
(AEP, UK)
C9 1-126-795-11 ELECT 10uF 20% 25V
(AEP, UK)
C353 1-164-159-11 CERAMIC 0.1uF 50V
C354 1-164-159-11 CERAMIC 0.1uF 50V
C406 1-164-159-11 CERAMIC 0.1uF 50V
C408 1-162-294-31 CERAMIC 0.001uF 10% 50V
C412 1-162-291-31 CERAMIC 560PF 10% 50V
C413 1-164-159-11 CERAMIC 0.1uF 50V
C415 1-164-159-11 CERAMIC 0.1uF 50V
C416 1-164-159-11 CERAMIC 0.1uF 50V
C421 1-126-964-11 ELECT 10uF 20% 50V
C422 1-126-964-11 ELECT 10uF 20% 50V
C427 1-124-252-00 ELECT 0.33uF 20% 50V
C428 1-130-489-00 MYLAR 0.033uF 5% 50V
C429 1-162-282-31 CERAMIC 100PF 10% 50V
C432 1-126-795-11 ELECT 10uF 20% 25V
C433 1-126-795-11 ELECT 10uF 20% 25V
C434 1-162-286-31 CERAMIC 220PF 10% 50V
C435 1-162-286-31 CERAMIC 220PF 10% 50V
C441 1-164-159-11 CERAMIC 0.1uF 50V
C471 1-126-964-11 ELECT 10uF 20% 50V
C472 1-126-964-11 ELECT 10uF 20% 50V
C477 1-124-252-00 ELECT 0.33uF 20% 50V
C478 1-130-489-00 MYLAR 0.033uF 5% 50V
C479 1-162-282-31 CERAMIC 100PF 10% 50V
C492 1-124-464-11 ELECT 0.22uF 20% 50V
C701 1-126-964-11 ELECT 10uF 20% 50V
C702 1-162-282-31 CERAMIC 100PF 10% 50V
C703 1-104-665-11 ELECT 100uF 20% 25V
C705 1-102-233-00 CERAMIC 33PF 10% 500V
C706 1-104-664-11 ELECT 47uF 20% 25V
C707 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,UK)
C710 1-104-664-11 ELECT 47uF 20% 16V
C711 1-137-372-11 FILM 0.022uF 5% 50V
C720 1-162-286-31 CERAMIC 220PF 10% 50V
C721 1-104-666-11 ELECT 220uF 20% 25V
C722 1-126-964-11 ELECT 10uF 20% 50V
C740 1-128-562-11 ELECT 47uF 20% 100V
C741 1-128-562-11 ELECT 47uF 20% 100V
C742 1-126-925-11 ELECT 470uF 20% 10V
C751 1-126-964-11 ELECT 10uF 20% 50V
C752 1-162-282-31 CERAMIC 100PF 10% 50V
C753 1-104-665-11 ELECT 100uF 20% 25V
C755 1-102-233-00 CERAMIC 33PF 10% 500V
C756 1-104-664-11 ELECT 47uF 20% 25V
C757 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP, UK)
C760 1-104-664-11 ELECT 47uF 20% 25V
C761 1-137-372-11 FILM 0.022uF 5% 50V
C770 1-162-286-31 CERAMIC 220PF 10% 50V
C801 1-104-664-11 ELECT 47uF 20% 25V
C802 1-104-664-11 ELECT 47uF 20% 25V
C803 1-107-766-11 ELECT (BLOCK) 8200uF 20% 71V
(AEP, UK)
C803 1-125-897-11 ELECT 10000uF 20% 71V
(US)
C804 1-107-766-11 ELECT (BLOCK) 8200uF 20% 71V
(AEP, UK)
C804 1-125-897-11 ELECT 10000uF 20% 71V
(US)
C805 1-130-781-00 FILM 0.22uF 10% 100V
(AEP, UK)
C805 1-137-420-11 FILM 0.047uF 10% 100V
(US)
C806 1-130-781-00 FILM 0.22uF 10% 100V
(AEP, UK)
C806 1-137-420-11 FILM 0.047uF 10% 100V
(US)
C807 1-104-664-11 ELECT 47uF 20% 25V
C808 1-104-664-11 ELECT 47uF 20% 25V
C809 1-126-959-11 ELECT 0.47uF 20% 50V
C810 1-126-959-11 ELECT 0.47uF 20% 50V
C811 1-126-942-61 ELECT 1000uF 20% 25V
C812 1-126-941-11 ELECT 470uF 20% 25V
C813 1-101-001-00 CERAMIC 0.001uF 50V
C814 1-101-001-00 CERAMIC 0.001uF 50V
C816 1-104-664-11 ELECT 47uF 20% 25V
C822 1-126-960-11 ELECT 1uF 20% 50V
C950 1-126-767-11 ELECT 1000uF 20% 16V
C951 1-164-097-11 CERAMIC 0.022uF 50V
C952 1-126-960-11 ELECT 1uF 20% 50V
C953 1-124-464-11 ELECT 0.22uF 20% 50V
C954 1-126-964-11 ELECT 10uF 20% 50V
C955 1-164-159-11 CERAMIC 0.1uF 50V
C956 1-164-159-11 CERAMIC 0.1uF 50V
C957 1-164-159-11 CERAMIC 0.1uF 50V
C958 1-164-097-11 CERAMIC 0.022uF 50V
C959 1-164-097-11 CERAMIC 0.022uF 50V
CC02 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP, UK)
CC03 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP, UK)
CC04 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP, UK)
CC05 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP, UK)
CC06 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP, UK)
MAIN
