Sony STR-DE135 - REAR PANEL SECTION; MAIN BOARD

– 6 –
REAR PANEL SECTION
MAIN BOARD
2 connector
(CNP901)
4 rear panel section
3 four screws
(BVTP3
× 8)
3 six screws
(BVTP3
× 8
)
1 flat wire
(CNS205)
2 connector
(CNS802)
2 two connectors
(CNP703, 704)
4 PC board holder
2 connector
(CNP801)
1 two flat wires
(CNS204, CNP404)
5 MAIN board
3 three screws
(BVTP3
× 8)
3 three screws
(BVTP3
× 8)
2 connector
(CNP702)
