Sony STR-DE335 - Page 38

– 55 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< COIL >
L1 1-410-521-11 INDUCTOR 100uH (DE335: AEP)
L301 1-410-509-11 INDUCTOR 10uH
L501 1-420-872-00 COIL, AIR-CORE
L601 1-420-872-00 COIL, AIR-CORE
L651 1-420-872-00 COIL, AIR-CORE
L701 1-420-872-00 COIL, AIR-CORE
L751 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR/IC >
Q361 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q362 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q363 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q364 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q365 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q366 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q367 8-729-119-78 TRANSISTOR 2SC403SP-51
Q401 8-729-202-67 FET 2SK246-GR3
Q402 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q451 8-729-202-67 FET 2SK246-GR3
Q452 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q510 8-729-119-78 TRANSISTOR 2SC403SP-51
Q601 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q602 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q603 8-749-010-25 IC MN2488-OPY-M
Q604 8-749-010-26 IC MP1620-OPY-M
Q610 8-729-119-78 TRANSISTOR 2SC403SP-51
Q620 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q651 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q652 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q653 8-749-010-25 IC MN2488-OPY-M
Q654 8-749-010-26 IC MP1620-OPY-M
Q670 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q701 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q702 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q703 8-749-010-25 IC MN2488-OPY-M
Q704 8-749-010-26 IC MP1620-OPY-M
Q710 8-729-119-78 TRANSISTOR 2SC403SP-51
Q720 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q721 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q722 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q723 8-729-119-78 TRANSISTOR 2SC403SP-51
Q751 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q752 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q753 8-749-010-25 IC MN2488-OPY-M
Q754 8-749-010-26 IC MP1620-OPY-M
Q770 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q801 8-729-140-97 TRANSISTOR 2SB734-34
Q802 8-729-119-78 TRANSISTOR 2SC403SP-51
Q809 8-729-119-78 TRANSISTOR 2SC403SP-51
Q951 8-729-026-68 TRANSISTOR 2SD2525 (TP)
< RESISTOR >
R5 1-249-421-11 CARBON 2.2K 5% 1/4W
(DE335: AEP)
R6 1-247-807-31 CARBON 100 5% 1/4W
(DE335: AEP)
R7 1-247-807-31 CARBON 100 5% 1/4W
(DE335: AEP)
R303 1-249-439-11 CARBON 68K 5% 1/4W
R306 1-249-436-11 CARBON 39K 5% 1/4W
R342 1-249-441-11 CARBON 100K 5% 1/4W
R343 1-249-441-11 CARBON 100K 5% 1/4W
R351 1-249-417-11 CARBON 1K 5% 1/4W
R352 1-249-417-11 CARBON 1K 5% 1/4W
R353 1-249-417-11 CARBON 1K 5% 1/4W
R354 1-249-417-11 CARBON 1K 5% 1/4W
R355 1-249-417-11 CARBON 1K 5% 1/4W
R356 1-249-417-11 CARBON 1K 5% 1/4W
R357 1-249-429-11 CARBON 10K 5% 1/4W
R358 1-249-439-11 CARBON 68K 5% 1/4W
R359 1-249-425-11 CARBON 4.7K 5% 1/4W
R360 1-249-425-11 CARBON 4.7K 5% 1/4W
R361 1-249-425-11 CARBON 4.7K 5% 1/4W
R362 1-249-425-11 CARBON 4.7K 5% 1/4W
R363 1-249-425-11 CARBON 4.7K 5% 1/4W
R364 1-249-425-11 CARBON 4.7K 5% 1/4W
R365 1-249-425-11 CARBON 4.7K 5% 1/4W
R366 1-249-425-11 CARBON 4.7K 5% 1/4W
R367 1-249-438-11 CARBON 56K 5% 1/4W
R368 1-249-425-11 CARBON 4.7K 5% 1/4W
R369 1-249-439-11 CARBON 68K 5% 1/4W
R370 1-249-429-11 CARBON 10K 5% 1/4W
R372 1-249-441-11 CARBON 100K 5% 1/4W
R374 1-249-429-11 CARBON 10K 5% 1/4W
R375 1-249-429-11 CARBON 10K 5% 1/4W
R380 1-249-441-11 CARBON 100K 5% 1/4W
R381 1-249-441-11 CARBON 100K 5% 1/4W
! R397 1-249-410-11 CARBON 270 5% 1/4W F
R399 1-249-426-11 CARBON 5.6K 5% 1/4W
R402 1-249-417-11 CARBON 1K 5% 1/4W
R403 1-249-417-11 CARBON 1K 5% 1/4W
R404 1-249-417-11 CARBON 1K 5% 1/4W
R405 1-249-417-11 CARBON 1K 5% 1/4W
R406 1-249-417-11 CARBON 1K 5% 1/4W
R407 1-249-417-11 CARBON 1K 5% 1/4W
R414 1-249-425-11 CARBON 4.7K 5% 1/4W
R415 1-249-417-11 CARBON 1K 5% 1/4W
R431 1-247-843-11 CARBON 3.3K 5% 1/4W
R432 1-247-883-00 CARBON 150K 5% 1/4W
R433 1-249-427-11 CARBON 6.8K 5% 1/4W
R434 1-249-413-11 CARBON 470 5% 1/4W
R435 1-249-418-11 CARBON 1.2K 5% 1/4W
R438 1-249-441-11 CARBON 100K 5% 1/4W
R441 1-249-441-11 CARBON 100K 5% 1/4W
R442 1-249-418-11 CARBON 1.2K 5% 1/4W
R443 1-249-418-11 CARBON 1.2K 5% 1/4W
R444 1-247-903-00 CARBON 1M 5% 1/4W
R447 1-249-436-11 CARBON 39K 5% 1/4W
R448 1-249-436-11 CARBON 39K 5% 1/4W
R449 1-249-433-11 CARBON 22K 5% 1/4W
R452 1-249-417-11 CARBON 1K 5% 1/4W
R453 1-249-417-11 CARBON 1K 5% 1/4W
R454 1-249-417-11 CARBON 1K 5% 1/4W
MAIN
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
