– 56 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R455 1-249-417-11 CARBON 1K 5% 1/4W
R456 1-249-417-11 CARBON 1K 5% 1/4W
R457 1-249-417-11 CARBON 1K 5% 1/4W
R464 1-247-903-00 CARBON 1M 5% 1/4W
R465 1-249-417-11 CARBON 1K 5% 1/4W
R469 1-247-903-00 CARBON 1M 5% 1/4W
R481 1-247-843-11 CARBON 3.3K 5% 1/4W
R482 1-247-883-00 CARBON 150K 5% 1/4W
R483 1-249-427-11 CARBON 6.8K 5% 1/4W
R484 1-249-413-11 CARBON 470 5% 1/4W
R491 1-249-441-11 CARBON 100K 5% 1/4W
R492 1-247-903-00 CARBON 1M 5% 1/4W
R494 1-247-903-00 CARBON 1M 5% 1/4W
R518 1-249-389-11 CARBON 4.7 5% 1/4W
! R519 1-249-403-11 CARBON 68 5% 1/4W F
! R523 1-249-403-11 CARBON 68 5% 1/4W F
R530 1-249-426-11 CARBON 5.6K 5% 1/4W
R532 1-249-426-11 CARBON 5.6K 5% 1/4W
R562 1-249-437-11 CARBON 47K 5% 1/4W
R581 1-249-434-11 CARBON 27K 5% 1/4W
(DE335: AEP)
R581 1-249-436-11 CARBON 39K 5% 1/4W
(DE335: MY, SP, AUS/V323)
R581 1-249-437-11 CARBON 47K 5% 1/4W
(DE335: US, CND, E/SE391)
R601 1-249-417-11 CARBON 1K 5% 1/4W
R602 1-249-439-11 CARBON 68K 5% 1/4W
R603 1-249-414-11 CARBON 560 5% 1/4W
R604 1-249-439-11 CARBON 68K 5% 1/4W
R610 1-249-421-11 CARBON 2.2K 5% 1/4W
R611 1-249-440-11 CARBON 82K 5% 1/4W
R613 1-249-414-11 CARBON 560 5% 1/4W
! R614 1-249-408-11 CARBON 180 5% 1/4W F
(EXCEPT DE335: AEP)
! R614 1-249-409-11 CARBON 220 5% 1/4W F
(DE335: AEP)
! R615 1-249-408-11 CARBON 180 5% 1/4W F
(EXCEPT DE335: AEP)
! R615 1-249-409-11 CARBON 220 5% 1/4W F
(DE335: AEP)
! R616 1-233-352-41 ENCAPSULATED COMPONENT (0.22+0.22)
! R617 1-249-393-11 CARBON 10 5% 1/4W F
R618 1-249-389-11 CARBON 4.7 5% 1/4W
R619 1-249-403-11 CARBON 68 5% 1/4W F
R620 1-249-419-11 CARBON 1.5K 5% 1/4W
R621 1-249-427-11 CARBON 6.8K 5% 1/4W
R622 1-249-431-11 CARBON 15K 5% 1/4W
R623 1-249-437-11 CARBON 47K 5% 1/4W
R630 1-249-426-11 CARBON 5.6K 5% 1/4W
R632 1-249-426-11 CARBON 5.6K 5% 1/4W
! R644 1-249-403-11 CARBON 68 5% 1/4W F
R651 1-249-417-11 CARBON 1K 5% 1/4W
R652 1-249-439-11 CARBON 68K 5% 1/4W
R653 1-249-414-11 CARBON 560 5% 1/4W
R654 1-249-439-11 CARBON 68K 5% 1/4W
R660 1-249-421-11 CARBON 2.2K 5% 1/4W
R661 1-249-440-11 CARBON 82K 5% 1/4W
R663 1-249-414-11 CARBON 560 5% 1/4W
! R664 1-249-408-11 CARBON 180 5% 1/4W F
(DE335: AEP)
! R664 1-249-409-11 CARBON 220 5% 1/4W F
(EXCEPT DE335: AEP)
! R665 1-249-408-11 CARBON 180 5% 1/4W F
(DE335: AEP)
! R665 1-249-409-11 CARBON 220 5% 1/4W F
(EXCEPT DE335: AEP)
! R666 1-233-352-41 ENCAPSULATED COMPONENT (0.22+0.22)
! R667 1-249-393-11 CARBON 10 5% 1/4W F
R668 1-249-389-11 CARBON 4.7 5% 1/4W
R670 1-249-419-11 CARBON 1.5K 5% 1/4W
R671 1-249-427-11 CARBON 6.8K 5% 1/4W
R672 1-249-431-11 CARBON 15K 5% 1/4W
R673 1-249-437-11 CARBON 47K 5% 1/4W
R701 1-249-417-11 CARBON 1K 5% 1/4W
R702 1-249-439-11 CARBON 68K 5% 1/4W
R703 1-247-828-11 CARBON 750 5% 1/4W
(DE335: US, CND, AEP, E/SE391)
R703 1-249-416-11 CARBON 820 5% 1/4W
(DE335: MY, SP, AUS/V323)
R704 1-249-439-11 CARBON 68K 5% 1/4W
R705 1-249-429-11 CARBON 10K 5% 1/4W
R706 1-249-435-11 CARBON 33K 5% 1/4W
R707 1-249-435-11 CARBON 33K 5% 1/4W
R710 1-249-421-11 CARBON 2.2K 5% 1/4W
R711 1-249-440-11 CARBON 82K 5% 1/4W
R713 1-249-414-11 CARBON 560 5% 1/4W
! R714 1-249-408-11 CARBON 180 5% 1/4W F
(DE335: AEP)
! R714 1-249-409-11 CARBON 220 5% 1/4W F
(EXCEPT DE335: AEP)
! R715 1-249-408-11 CARBON 180 5% 1/4W F
(DE335: AEP)
! R715 1-249-409-11 CARBON 220 5% 1/4W F
(EXCEPT DE335: AEP)
! R716 1-233-352-41 ENCAPSULATED COMPONENT (0.22+0.22)
! R717 1-249-393-11 CARBON 10 5% 1/4W F
R718 1-249-389-11 CARBON 4.7 5% 1/4W
! R719 1-249-403-11 CARBON 68 5% 1/4W F
R720 1-249-419-11 CARBON 1.5K 5% 1/4W
R721 1-249-427-11 CARBON 6.8K 5% 1/4W
R722 1-249-431-11 CARBON 15K 5% 1/4W
R723 1-249-437-11 CARBON 47K 5% 1/4W
R724 1-249-425-11 CARBON 4.7K 5% 1/4W
R725 1-249-427-11 CARBON 6.8K 5% 1/4W
R726 1-249-417-11 CARBON 1K 5% 1/4W
R727 1-249-427-11 CARBON 6.8K 5% 1/4W
R730 1-249-426-11 CARBON 5.6K 5% 1/4W
R731 1-249-426-11 CARBON 5.6K 5% 1/4W
! R732 1-249-393-11 CARBON 10 5% 1/4W F
! R733 1-249-393-11 CARBON 10 5% 1/4W F
R734 1-249-420-11 CARBON 1.8K 5% 1/4W
R738 1-249-434-11 CARBON 27K 5% 1/4W
(DE335: AEP)
R738 1-249-436-11 CARBON 39K 5% 1/4W
(DE335: MY, SP, AUS/V323)
R738 1-249-437-11 CARBON 47K 5% 1/4W
(DE335: US, CND, E/SE391)
MAIN
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
