Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R742 1-249-425-11 CARBON 4.7K 5% 1/4W
R743 1-249-425-11 CARBON 4.7K 5% 1/4W
! R744 1-249-403-11 CARBON 68 5% 1/4W F
R751 1-249-417-11 CARBON 1K 5% 1/4W
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-247-828-11 CARBON 750 5% 1/4W
(DE335: US, CND, AEP/SE391)
R753 1-249-416-11 CARBON 820 5% 1/4W
(DE335: MY, SP, AUS/V323)
R753 1-249-442-11 CARBON 510 5% 1/4W
(DE335: US, MY, SP, AUS/V323)
R754 1-249-439-11 CARBON 68K 5% 1/4W
R755 1-249-429-11 CARBON 10K 5% 1/4W
R756 1-249-435-11 CARBON 33K 5% 1/4W
R757 1-249-435-11 CARBON 33K 5% 1/4W
R760 1-249-421-11 CARBON 2.2K 5% 1/4W
R761 1-249-440-11 CARBON 82K 5% 1/4W
R763 1-249-414-11 CARBON 560 5% 1/4W
! R764 1-249-408-11 CARBON 180 5% 1/4W F
(DE335: AEP)
! R764 1-249-409-11 CARBON 220 5% 1/4W F
(EXCEPT DE335: AEP)
! R765 1-249-408-11 CARBON 180 5% 1/4W F
(DE335: AEP)
! R765 1-249-409-11 CARBON 220 5% 1/4W F
(EXCEPT DE335: AEP)
! R766 1-233-352-41 ENCAPSULATED COMPONENT (0.22+0.22)
! R767 1-249-393-11 CARBON 10 5% 1/4W F
R768 1-249-389-11 CARBON 4.7 5% 1/4W
R770 1-249-419-11 CARBON 1.5K 5% 1/4W
R771 1-249-427-11 CARBON 6.8K 5% 1/4W
R772 1-249-431-11 CARBON 15K 5% 1/4W
R773 1-249-437-11 CARBON 47K 5% 1/4W
R788 1-249-434-11 CARBON 27K 5% 1/4W
(DE335: AEP)
R788 1-249-436-11 CARBON 39K 5% 1/4W
(DE335: MY, SP, AUS/V323)
R788 1-249-437-11 CARBON 47K 5% 1/4W
(DE335: US, CND, E/SE391)
! R803 1-247-739-11 CARBON 100 5% 1/2W F
(DE335: US, CND/SE391)
! R803 1-249-389-11 CARBON 4.7 5% 1/4W F
(EXCEPT DE335: US, CND/SE391)
R804 1-249-427-11 CARBON 6.8K 5% 1/4W
R821 1-249-437-11 CARBON 47K 5% 1/4W
R822 1-249-425-11 CARBON 4.7K 5% 1/4W
R823 1-249-437-11 CARBON 47K 5% 1/4W
R824 1-249-425-11 CARBON 4.7K 5% 1/4W
! R830 1-249-403-11 CARBON 68 5% 1/4W F
! R831 1-249-403-11 CARBON 68 5% 1/4W F
R950 1-249-421-11 CARBON 2.2K 5% 1/4W
R951 1-249-428-11 CARBON 8.2K 5% 1/4W
R952 1-249-422-11 CARBON 2.7K 5% 1/4W
R953 1-249-433-11 CARBON 22K 5% 1/4W
R954 1-249-437-11 CARBON 47K 5% 1/4W
R955 1-249-429-11 CARBON 10K 5% 1/4W
R956 1-247-843-11 CARBON 3.3K 5% 1/4W
R957 1-249-417-11 CARBON 1K 5% 1/4W
R960 1-249-431-11 CARBON 15K 5% 1/4W
RR04 1-249-393-11 CARBON 10 5% 1/4W (DE335: AEP)
RR05 1-249-393-11 CARBON 10 5% 1/4W (DE335: AEP)
RR54 1-249-393-11 CARBON 10 5% 1/4W (DE335: AEP)
RR55 1-249-393-11 CARBON 10 5% 1/4W (DE335: AEP)
< RELAY >
RY301 1-755-267-11 RELAY
RY551 1-515-921-11 RELAY (12V)
RY601 1-515-921-11 RELAY (12V)
RY701 1-515-921-11 RELAY (12V)
RY801 1-755-013-11 RELAY (EXCEPT DE335: CND)
RY851 1-515-918-11 RELAY (DE335: CND)
RY852 1-515-918-11 RELAY (DE335: CND)
< TERMINAL >
TM601 1-537-510-11 TERMINAL BOARD (SPEAKER) (6P)
(SPEAKERS CENTER/REAR)
TM701 1-537-376-11 TERMINAL BOARD (SP)
(SPAEAKERS FRONT A/B)
< VIBRATOR >
X1 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)
(DE335: AEP)
************************************************************
1-673-055-11 PHONO BOARD (SE391)
************
< CAPACITOR >
C401 1-162-282-31 CERAMIC 100PF 10% 50V
C402 1-126-962-11 ELECT 3.3uF 20% 50V
C403 1-126-966-11 ELECT 33uF 20% 16V
C404 1-162-282-31 CERAMIC 100PF 10% 50V
C405 1-137-459-11 FILM 0.0056uF 5% 100V
C407 1-137-365-11 FILM 0.0015uF 5% 50V
C409 1-126-962-11 ELECT 3.3uF 20% 50V
C410 1-164-159-21 CERAMIC 0.1uF 50V
C451 1-162-282-31 CERAMIC 100PF 10% 50V
C452 1-126-962-11 ELECT 3.3uF 20% 50V
C453 1-126-966-11 ELECT 33uF 20% 16V
C454 1-162-282-31 CERAMIC 100PF 10% 50V
C455 1-137-459-11 FILM 0.0056uF 5% 100V
C457 1-137-365-11 FILM 0.0015uF 5% 50V
C459 1-126-962-11 ELECT 3.3uF 20% 50V
C460 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CNS451 1-750-179-11 SOCKET, CONNECTOR 5P
< IC >
IC402 8-759-636-74 IC M5218AP-22
< JACK >
J451 1-785-837-11 PIN JACK 2P (PHONO IN)
MAIN PHONO
