– 58 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< RESISTOR >
R401 1-249-411-11 CARBON 330 5% 1/4W
R409 1-249-437-11 CARBON 47K 5% 1/4W
R410 1-247-897-11 CARBON 560K 5% 1/4W
R411 1-249-416-11 CARBON 820 5% 1/4W
R412 1-247-897-11 CARBON 560K 5% 1/4W
R413 1-249-437-11 CARBON 47K 5% 1/4W
R416 1-249-417-11 CARBON 1K 5% 1/4W
R417 1-247-897-11 CARBON 560K 5% 1/4W
R451 1-249-411-11 CARBON 330 5% 1/4W
R459 1-249-437-11 CARBON 47K 5% 1/4W
R460 1-247-897-11 CARBON 560K 5% 1/4W
R461 1-249-416-11 CARBON 820 5% 1/4W
R462 1-247-897-11 CARBON 560K 5% 1/4W
R463 1-249-437-11 CARBON 47K 5% 1/4W
R466 1-249-417-11 CARBON 1K 5% 1/4W
R467 1-247-897-11 CARBON 560K 5% 1/4W
************************************************************
1-673-051-11 POWER SWITCH BOARD
********************
< CONNECTOR >
CNS203 1-573-105-11 CONNECTOR, PC BOARD 4P
< SWITCH >
S200 1-762-196-21 SWITCH, TACT (1/u)
************************************************************
1-673-050-11 PRIMARY BOARD (EXCEPT DE335: E)
**************
1-533-293-11 FUSE HOLDER
< CONNECTOR >
* CNP902 1-564-321-21 PIN, CONNECTOR 2P
< FUSE >
! F901 1-532-464-51 FUSE (T2.5AL/250V)
(DE335: AEP, MY SP, AUS/V323)
! F901 1-533-310-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(6.3A/125V) (DE335: US, CND/SE391)
************************************************************
A-4419-137-A REAR AMP BOARD, COMPLETE (DE335: E)
A-4419-192-A REAR AMP BOARD, COMPLETE (SE391)
A-4419-481-A REAR AMP BOARD, COMPLETE
(DE335: US, CND)
A-4419-747-A REAR AMP BOARD, COMPLETE (DE335: AEP)
A-4419-750-A REAR AMP BOARD, COMPLETE
(DE335: MY, SP, AUS/V323)
*************************
< CAPACITOR >
C444 1-126-163-11 ELECT 4.7uF 20% 50V
C445 1-126-163-11 ELECT 4.7uF 20% 50V
C502 1-162-282-31 CERAMIC 100PF 10% 50V
C503 1-104-665-11 ELECT 100uF 20% 10V
C505 1-102-233-00 CERAMIC 33PF 10% 500V
C510 1-104-664-11 ELECT 47uF 20% 16V
C511 1-137-372-11 FILM 0.022uF 5% 50V
C520 1-162-286-31 CERAMIC 220PF 10% 50V
C551 1-126-963-11 ELECT 4.7uF 20% 50V
C552 1-162-282-31 CERAMIC 100PF 10% 50V
C553 1-104-665-11 ELECT 100uF 20% 10V
C555 1-102-233-00 CERAMIC 33PF 10% 500V
< CONNECTOR >
* CNS501 1-564-519-11 PLUG, CONNECTOR 4P
* CNS502 1-564-520-11 PLUG, CONNECTOR 5P
CNS503 1-784-727-11 CONNECTOR, FFC 5P
< IC >
IC501 8-759-326-52 IC uPC2581V
< TRANSISTOR/IC >
Q501 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q502 8-729-209-15 TRANSISTOR 2SD2012
Q503 8-749-010-25 IC MN2488-OPY-M
Q504 8-749-010-26 IC MP1620-OPY-M
Q520 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W
R502 1-249-439-11 CARBON 68K 5% 1/4W
R503 1-249-412-11 CARBON 390 5% 1/4W
(EXCEPT DE335: AEP)
R503 1-249-414-11 CARBON 560 5% 1/4W
(DE335: AEP)
R504 1-249-439-11 CARBON 68K 5% 1/4W
R510 1-247-840-00 CARBON 2.4K 5% 1/4W
R511 1-249-440-11 CARBON 82K 5% 1/4W
R513 1-249-414-11 CARBON 560 5% 1/4W
! R514 1-249-408-11 CARBON 180 5% 1/4W F
(DE335: AEP)
! R514 1-249-409-11 CARBON 220 5% 1/4W F
(EXCEPT DE335: AEP)
! R515 1-249-408-11 CARBON 180 5% 1/4W F
(DE335: AEP)
! R515 1-249-409-11 CARBON 220 5% 1/4W F
(EXCEPT DE335: AEP)
! R516 1-233-352-41 ENCAPSULATED COMPONENT (0.22+0.22)
! R517 1-249-393-11 CARBON 10 5% 1/4W F
R520 1-249-419-11 CARBON 1.5K 5% 1/4W
R521 1-249-427-11 CARBON 6.8K 5% 1/4W
R522 1-249-431-11 CARBON 15K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W
R552 1-249-439-11 CARBON 68K 5% 1/4W
R553 1-249-413-11 CARBON 470 5% 1/4W
R554 1-249-429-11 CARBON 10K 5% 1/4W
R557 1-249-409-11 CARBON 220 5% 1/4W
R558 1-249-409-11 CARBON 220 5% 1/4W
R559 1-249-420-11 CARBON 1.8K 5% 1/4W
R560 1-249-420-11 CARBON 1.8K 5% 1/4W
************************************************************
PHONO POWER SWITCH PRIMARY REAR AMP
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
