Sony STR-DE335 - Page 42

– 59 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
1-673-049-11 SECONDARY BOARD
*****************
< CONNECTOR >
CNP801 1-691-773-11 PLUG (MICRO CONNECTOR) 11P
< RESISTOR >
! R810 1-240-877-91 FUSIBLE 0.15 5% 1/4W F
! R811 1-240-877-91 FUSIBLE 0.15 5% 1/4W F
************************************************************
1-673-045-11 SP SW BOARD
************
< CONNECTOR >
CNP703 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CNP704 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< JACK >
J741 1-750-731-11 JACK (LARGE TYPE) (PHONES) (SE391)
J741 1-750-733-11 JACK (LARGE TYPE) (PHONES) (DE335/V323)
< RESISTOR >
R741 1-247-753-11 CARBON 1.2K 5% 1/2W
R742 1-247-753-11 CARBON 1.2K 5% 1/2W
R791 1-247-753-11 CARBON 1.2K 5% 1/2W
R792 1-247-753-11 CARBON 1.2K 5% 1/2W
< SWITCH >
S701 1-771-634-11 SWITCH, PUSH (2 KEY)
(SPEAKERS A/B ON/OFF)
************************************************************
1-673-048-11 STANDBY BOARD
**************
1-533-293-11 FUSE HOLDER
(DE335: AEP, E, MY, SP, AUS/V323)
< AC OUTLET >
! CNJ903 1-251-416-11 OUTLET, A.C. (DE335: AUS) (AC OUTLET)
! CNJ903 1-526-794-11 OUTLET, AC (DE335: AEP, MY, SP)
(AC OUTLET)
! CNJ903 1-526-822-00 OUTLET, AC (V323) (AC OUTLET)
< CONNECTOR >
CNP802 1-779-495-11 PLUG, CONNECTOR PIN 4P
CNP901 1-564-321-00 PIN, CONNECTOR 2P
* CNP903 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
(DE335:AEP, MY, SP, AUS/V323)
CNP905 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P (DE335: E)
* CNP906 1-564-687-11 PIN, CONNECTOR 3P (DE335: E)
< DIODE >
D816 8-719-911-19 DIODE 1SS119 (DE335: US, AEP, SP)
D816 8-719-991-33 DIODE 1SS133T-77
(EXCEPT DE335: US, AEP, SP)
< FUSE >
! F902 1-532-464-51 FUSE (T2.5AL/250V)
(DE335: AEP, MY, SP, AUS/V323)
! F903 1-532-388-51 FUSE (T2AL/250V) (DE335: E)
< TERMINAL EARTH >
* G900 1-537-738-21 TERMINAL, EARTH (DE335: US, CND/SE391)
< AC OUTLET >
! J911 1-251-718-11 OUTLET (2 GANG), AC (SE391) (AC OUTLET)
! J911 1-785-834-11 OUTLET (1P) (DE335: US, CND, E)
(AC OUTLET)
< RESISTOR >
! R901 1-202-725-00 SOLID 3.3M 10% 1/2W
(DE335: US, CND/SE391)
< RELAY >
! RY901 1-755-146-11 RELAY, AC POWER (SE391)
! RY901 1-755-276-11 RELAY, POWER (DE335/V323)
< TRANSFORMER >
! T902 1-433-685-11 TRANSFORMER, POWER
(DE335: AEP, MY, SP, AUS/V323)
! T902 1-433-686-11 TRANSFORMER, POWER
(DE335: US, CND/SE391)
! T902 1-433-687-11 TRANSFORMER, POWER (DE335: E)
************************************************************
1-673-044-11 TONE BOARD
***********
< CAPACITOR >
C421 1-137-440-11 FILM 0.018uF 5% 50V
C422 1-124-463-00 ELECT 0.1uF 20% 50V
C423 1-137-368-11 FILM 0.0047uF 5% 50V
C424 1-137-372-11 FILM 0.022uF 5% 50V
C471 1-137-440-11 FILM 0.018uF 5% 50V
C472 1-124-463-00 ELECT 0.1uF 20% 50V
C473 1-137-368-11 FILM 0.0047uF 5% 50V
C474 1-137-372-11 FILM 0.022uF 5% 50V
< CONNECTOR >
CNS404 1-770-399-11 HOUSING, CONNECTOR (PC BOARD) 6P
< RESISTOR >
R420 1-249-415-11 CARBON 680 5% 1/4W
R421 1-249-431-11 CARBON 15K 5% 1/4W
R422 1-249-422-11 CARBON 2.7K 5% 1/4W
R423 1-247-903-00 CARBON 1M 5% 1/4W
R424 1-247-903-00 CARBON 1M 5% 1/4W
R470 1-249-415-11 CARBON 680 5% 1/4W
R471 1-249-431-11 CARBON 15K 5% 1/4W
R472 1-249-422-11 CARBON 2.7K 5% 1/4W
R473 1-247-903-00 CARBON 1M 5% 1/4W
SECONDARY SP SW STANDBY TONE
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
