Sony STR-DE335 - Page 43

– 60 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R474 1-247-903-00 CARBON 1M 5% 1/4W
< VARIABLE RESISTOR >
RV421 1-223-362-11 RES, VAR, CARBON 100K/100K (BASS)
RV422 1-223-363-11 RES, VAR, CARBON 125K/125K (TREBLE)
RV423 1-238-965-21 RES, VAR, CARBON 100K/100K (BALANCE)
************************************************************
1-673-053-11 VIDEO BOARD
***********
< CAPACITOR >
C260 1-126-960-11 ELECT 1uF 20% 50V
(DE335/V323)
C261 1-126-960-11 ELECT 1uF 20% 50V
(DE335/V323)
C262 1-164-159-11 CERAMIC 0.1uF 50V
(DE335/V323)
C263 1-104-664-11 ELECT 47uF 20% 25V
(DE335/V323)
C264 1-164-159-11 CERAMIC 0.1uF 50V
(DE335/V323)
C265 1-126-924-11 ELECT 330uF 20% 10V
(DE335/V323)
C266 1-162-215-31 CERAMIC 47PF 5% 50V
(DE335/V323)
C267 1-162-215-31 CERAMIC 47PF 5% 50V
(DE335/V323)
C268 1-126-960-11 ELECT 1uF 20% 50V
(DE335/V323)
C301 1-126-795-11 ELECT 10uF 20% 50V
C306 1-126-795-11 ELECT 10uF 20% 50V
C317 1-126-795-11 ELECT 10uF 20% 50V
C318 1-126-795-11 ELECT 10uF 20% 50V
C375 1-126-795-11 ELECT 10uF 20% 50V
C376 1-126-795-11 ELECT 10uF 20% 50V
CC272 1-162-282-31 CERAMIC 100PF 10% 50V
(DE335: AEP)
CC274 1-162-282-31 CERAMIC 100PF 10% 50V
(DE335: AEP)
CC276 1-162-282-31 CERAMIC 100PF 10% 50V
(DE335: AEP)
CC278 1-162-282-31 CERAMIC 100PF 10% 50V
(DE335: AEP)
CC280 1-162-282-31 CERAMIC 100PF 10% 50V
(DE335: AEP)
CC282 1-162-282-31 CERAMIC 100PF 10% 50V
(DE335: AEP)
< CONNECTOR >
CNP500 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
CNS250 1-569-315-11 SOCKET, CONNECTOR 5P (DE335/V323)
< IC >
IC251 8-759-333-84 IC NJM2279D (DE335/V323)
< JACK >
J251 1-770-336-11 JACK, PIN 2P (5.1CH/DVD VIDEO, TV/SAT
VIDEO IN) (EXCEPT DE335: AEP/SE391)
J251 1-770-336-11 JACK, PIN 2P (5.1CH/DVD VIDEO,
TV/LD VIDEO IN) (DE335: AEP)
J252 1-774-821-11 JACK, PIN 3P (VIDEO IN/OUT,
MONITOR VIDEO OUT) (DE335/V323)
J501 1-779-599-11 JACK, PIN 6P (5.1CH/DVD: FRONT, REAR,
WOOFER, CENTER)
< RESISTOR >
R208 1-247-804-11 CARBON 75 5% 1/4W
(DE335/V323)
R209 1-247-804-11 CARBON 75 5% 1/4W
(DE335/V323)
R210 1-247-804-11 CARBON 75 5% 1/4W
(DE335/V323)
R211 1-247-804-11 CARBON 75 5% 1/4W
(DE335/V323)
R212 1-247-804-11 CARBON 75 5% 1/4W
(DE335/V323)
! R213 1-249-407-11 CARBON 150 5% 1/4W F
(DE335/V323)
R214 1-249-421-11 CARBON 2.2K 5% 1/4W
R215 1-249-421-11 CARBON 2.2K 5% 1/4W
R217 1-249-421-11 CARBON 2.2K 5% 1/4W
R218 1-249-421-11 CARBON 2.2K 5% 1/4W
R219 1-249-421-11 CARBON 2.2K 5% 1/4W
R220 1-249-421-11 CARBON 2.2K 5% 1/4W
! R229 1-249-410-11 CARBON 270 5% 1/4W F
(DE335/V323)
R347 1-249-437-11 CARBON 47K 5% 1/4W
R348 1-249-437-11 CARBON 47K 5% 1/4W
R349 1-249-437-11 CARBON 47K 5% 1/4W
R350 1-249-437-11 CARBON 47K 5% 1/4W
R351 1-249-437-11 CARBON 47K 5% 1/4W
R371 1-249-437-11 CARBON 47K 5% 1/4W
************************************************************
1-673-054-11 VOL SEL BOARD (DE335: E)
*************
1-533-399-31 HOLDER, FUSE
< CONNECTOR >
* CNP907 1-565-395-11 PIN, CONNECTOR 3P
CNP908 1-564-321-00 PIN, CONNECTOR 2P
* CNP910 1-564-687-11 PIN, CONNECTOR 3P
< FUSE >
! F904 1-532-388-51 FUSE (T2AL/250V) (DE335: E)
< SWITCH >
S901 1-571-437-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (DE335: E)
************************************************************
1-673-043-11 VOLUME BOARD
*************
< CAPACITOR >
C420 1-162-207-31 CERAMIC 22PF 5% 50V
C425 1-126-795-11 ELECT 10uF 20% 25V
TONE VIDEO VOL SEL VOLUME
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
