! RF800 1-212-887-00 FUSIBLE 180 5% 1/4W F
(AEP,UK,G,EE,E,SP,MY,CH)
RR01 1-249-418-11 CARBON 1.2K 5% 1/4W F
(AEP,UK,G,EE)
RR51 1-249-418-11 CARBON 1.2K 5% 1/4W F
(AEP,UK,G,EE)
< RELAY >
RY301 1-515-793-11 RELAY
RY551 1-515-920-11 RELAY (24V)
RY601 1-515-920-11 RELAY (24V)
RY701 1-515-920-11 RELAY (24V)
RY801 1-755-206-11 RELAY (EXCEPT CND)
RY851 1-515-918-11 RELAY (CND)
RY852 1-515-918-11 RELAY (CND)
< TERMINAL >
TM601 1-537-510-11 TERMINAL BOARD (6P)(SURROUND SPEAKER)
TM701 1-537-376-11 TERMINAL BOARD (FRONT SPEAKER)
(US,CND,AUS)
< VIBRATOR >
X1 1-579-900-21 VIBRATOR, CRYSTAL 4.332MHz (AEP,UK,G,EE)
X301 1-579-952-11 VIBRATOR, CERAMIC 8MHz
************************************************************
* 1-669-280-11 PRIMARY BOARD
*************
1-533-233-21 HOLDER, FUSE
< FUSE >
! F901 1-532-464-51 FUSE TIME LAG 2.5A/250V (EXCEPT US,CND)
! F901 1-533-310-11 FUSE,GLASS TUBE6.3A/125V (US,CND)
************************************************************
* 1-669-281-11 SECONDARY BOARD
***************
1-533-233-21 HOLDER, FUSE
< CONNECTOR >
CNP801 1-764-479-11 PIN, CONNECTOR (PC BOARD) 10P
< FUSE >
! F801 1-532-504-51 FUSE TIME LAG 4A/250V(EXCEPT US,CND)
! F801 1-576-108-11 FUSE 4A/125V(US,CND)
! F802 1-532-504-51 FUSE TIME LAG 4A/250V(EXCEPT US,CND)
! F802 1-576-108-11 FUSE 4A/125V(US,CND)
************************************************************
* 1-669-284-11 SP-SCREW BOARD (AEP,UK,G,EE,E,SP,MY,CH)
**************
< CAPACITOR >
CC12 1-164-096-11 CERAMIC 0.01uF 50V
CC13 1-164-096-11 CERAMIC 0.01uF 50V
CC62 1-164-096-11 CERAMIC 0.01uF 50V
CC63 1-164-096-11 CERAMIC 0.01uF 50V
< CONNECTOR >
CNS707 1-564-505-11 PLUG, CONNECTOR 2P
< RESISTOR >
RR04 1-249-393-11 CARBON 10 5% 1/4W F
RR05 1-249-393-11 CARBON 10 5% 1/4W F
RR54 1-249-393-11 CARBON 10 5% 1/4W F
RR55 1-249-393-11 CARBON 10 5% 1/4W F
< TERMINAL >
TMS701 1-537-740-11 TERMINAL BOARD (FRONT SPEAKERS)
************************************************************
* 1-669-282-11 SP-SW BOARD
***********
< CONNECTOR >
CNP703 1-764-474-11 PIN, CONNECTOR (PC BOARD) 5P
CNP704 1-764-473-11 PIN, CONNECTOR (PC BOARD) 3P
< JACK >
J741 1-750-733-11 JACK (LARGE TYPE)(PHONES)
< RESISTOR >
R741 1-247-753-11 CARBON 1.2K 5% 1/2W
R742 1-247-753-11 CARBON 1.2K 5% 1/2W
R791 1-247-753-11 CARBON 1.2K 5% 1/2W
R792 1-247-753-11 CARBON 1.2K 5% 1/2W
< SWITCH >
S701 1-762-319-11 SWITCH, PUSH (2 KEY)(SPEAKER A/B)
************************************************************
* 1-669-279-11 STAND BY BOARD
**************
1-533-233-21 HOLDER, FUSE
< JACK >
! CNJ902 1-251-691-11 OUTLET (AC) (US,CND)
< CONNECTOR >
CNP802 1-779-495-11 PLUG, CONNECTOR PIN 4P
CNP901 1-564-321-00 PIN, CONNECTOR 2P
CNP903 1-580-230-11 PIN,CONNECTOR(PC BOARD)2P
(EXCEPT US,CND)
< DIODE >
D816 8-719-911-19 DIODE 1SS119
< FUSE >
! F902 1-532-464-51 FUSE TIME LAG 2.5A/250V(EXCEPT US,CND)
< TERMINAL >
* G900 1-537-738-21 TERMINAL, EARTH (US,CND,AUS,E,SP,MY,CH)
< RESISTOR >
! R901 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MAIN PRIMARY SECONDARY SP-SCREW SP-SW STAND BY
