Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 39 —
< RELAY >
! RY901 1-755-018-11 RELAY
< TRANSFORMER >
! T902 1-431-740-11 TRANSFORMER, POWER (US,CND)
! T902 1-431-739-11 TRANSFORMER, POWER (EXCEPT US,CND)
************************************************************
* 1-669-283-11 VIDEO BOARD
***********
< CAPACITOR >
C260 1-126-960-11 ELECT 1uF 20% 50V
C261 1-126-960-11 ELECT 1uF 20% 50V
C262 1-164-159-11 CERAMIC 0.1uF 50V
C263 1-104-664-11 ELECT 47uF 20% 25V
C264 1-164-159-11 CERAMIC 0.1uF 50V
C265 1-126-924-11 ELECT 330uF 20% 10V
C266 1-162-215-31 CERAMIC 47PF 5% 50V
C267 1-162-215-31 CERAMIC 47PF 5% 50V
C268 1-126-960-11 ELECT 1uF 20% 50V
CC272 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,UK,G,EE)
CC274 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,UK,G,EE)
CC276 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,UK,G,EE)
CC278 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,UK,G,EE)
CC280 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,UK,G,EE)
< CONNECTOR >
CNP500 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
CNS250 1-568-439-11 SOCKET, CONNECTOR 7P
< IC >
IC251 8-759-333-84 IC NJM2279D
< JACK >
J251 1-695-317-21 JACK,PIN 2P(VIDEO/TV/LD VIDEO IN)
J252 1-766-199-11 JACK,PIN 3P(VIDEO OUT/VIDEO IN/MONITOR)
J253 1-774-843-11 JACK,PIN 1P(WOOFER AUDIO OUT)
J501 1-779-380-11 JACK,PIN 6P(FRONT/REAR/CENTER/WOOFER)
< RESISTOR >
R261 1-247-804-11 CARBON 75 5% 1/4W
R262 1-247-804-11 CARBON 75 5% 1/4W
R263 1-247-804-11 CARBON 75 5% 1/4W
R264 1-247-804-11 CARBON 75 5% 1/4W
! R267 1-249-407-11 CARBON 150 5% 1/4W F
R268 1-249-411-11 CARBON 330 5% 1/4W
! R269 1-247-804-11 CARBON 75 5% 1/4W
(US,CND,AUS,E,SP,MY,CH)
R272 1-249-421-11 CARBON 2.2K 5% 1/4W F
R274 1-249-421-11 CARBON 2.2K 5% 1/4W F
R275 1-249-429-11 CARBON 10K 5% 1/4W
R276 1-249-421-11 CARBON 2.2K 5% 1/4W F
R277 1-249-429-11 CARBON 10K 5% 1/4W
R278 1-249-421-11 CARBON 2.2K 5% 1/4W F
R280 1-249-421-11 CARBON 2.2K 5% 1/4W F
R282 1-249-421-11 CARBON 2.2K 5% 1/4W F
************************************************************
* A-4407-451-A VR-TONE BOARD, COMPLETE
***********************
< CAPACITOR >
C220 1-126-301-11 ELECT 1uF 20% 50V
C221 1-126-301-11 ELECT 1uF 20% 50V
C361 1-164-159-11 CERAMIC 0.1uF 50V
C362 1-164-159-11 CERAMIC 0.1uF 50V
C363 1-164-159-11 CERAMIC 0.1uF 50V
C364 1-164-159-11 CERAMIC 0.1uF 50V
C365 1-164-159-11 CERAMIC 0.1uF 50V
C366 1-164-159-11 CERAMIC 0.1uF 50V
C381 1-126-963-11 ELECT 4.7uF 20% 50V
C382 1-126-963-11 ELECT 4.7uF 20% 50V
C383 1-126-963-11 ELECT 4.7uF 20% 50V
C384 1-126-963-11 ELECT 4.7uF 20% 50V
C385 1-126-963-11 ELECT 4.7uF 20% 50V
C421 1-137-440-11 FILM 0.018uF 5% 50V
C422 1-124-463-00 ELECT 0.1uF 20% 50V
C423 1-137-368-11 FILM 0.0047uF 5% 50V
C424 1-137-372-11 FILM 0.022uF 5% 50V
C471 1-137-440-11 FILM 0.018uF 5% 50V
C472 1-124-463-00 ELECT 0.1uF 20% 50V
C473 1-137-368-11 FILM 0.0047uF 5% 50V
C474 1-137-372-11 FILM 0.022uF 5% 50V
< CONNECTOR >
CNP202 1-770-393-11 PIN, CONNECTOR (PC BOARD) 9P
CNS402 1-568-442-11 SOCKET, CONNECTOR 9P
CNS502 1-568-443-11 SOCKET, CONNECTOR 13P
< DIODE >
D238 8-719-046-39 DIODE SEL5821A-TH15 (MUTING)
< TRANSISTOR >
Q361 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q362 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q363 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q364 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q365 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q366 8-729-141-30 TRANSISTOR 2SC3623A-LK
< RESISTOR >
R229 1-249-406-11 CARBON 120 5% 1/4W F
R351 1-249-417-11 CARBON 1K 5% 1/4W F
R352 1-249-417-11 CARBON 1K 5% 1/4W F
R353 1-249-417-11 CARBON 1K 5% 1/4W F
R354 1-249-417-11 CARBON 1K 5% 1/4W F
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
STAND BY VIDEO VR-TONE
To Next Page
