Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 40 —
R355 1-249-417-11 CARBON 1K 5% 1/4W F
R356 1-249-417-11 CARBON 1K 5% 1/4W F
R361 1-249-425-11 CARBON 4.7K 5% 1/4W F
R362 1-249-425-11 CARBON 4.7K 5% 1/4W F
R363 1-249-425-11 CARBON 4.7K 5% 1/4W F
R364 1-249-425-11 CARBON 4.7K 5% 1/4W F
R365 1-249-425-11 CARBON 4.7K 5% 1/4W F
R366 1-249-425-11 CARBON 4.7K 5% 1/4W F
R367 1-249-441-11 CARBON 100K 5% 1/4W
R368 1-249-441-11 CARBON 100K 5% 1/4W
R369 1-249-441-11 CARBON 100K 5% 1/4W
R370 1-249-441-11 CARBON 100K 5% 1/4W
R371 1-249-441-11 CARBON 100K 5% 1/4W
R372 1-249-441-11 CARBON 100K 5% 1/4W
R421 1-249-430-11 CARBON 12K 5% 1/4W
R422 1-249-422-11 CARBON 2.7K 5% 1/4W F
R423 1-247-903-00 CARBON 1M 5% 1/4W
R424 1-247-903-00 CARBON 1M 5% 1/4W
R425 1-249-415-11 CARBON 680 5% 1/4W F
R471 1-249-430-11 CARBON 12K 5% 1/4W
R472 1-249-422-11 CARBON 2.7K 5% 1/4W F
R473 1-247-903-00 CARBON 1M 5% 1/4W
R474 1-247-903-00 CARBON 1M 5% 1/4W
R475 1-249-415-11 CARBON 680 5% 1/4W F
< VARIABLE RESISTOR >
RV404 1-225-446-11 RES, VAR, CARBON 100KX6
(MASTER VOLUME)
RV421 1-223-362-11 RES, VAR, CARBON 100K/100K (BASS)
RV422 1-223-363-11 RES, VAR, CARBON 125K/125K (TREBLE)
RV423 1-225-447-11 RES, VAR, CARBON 100K/100K (BALANCE)
< SWITCH >
S240 1-762-751-11 SWITCH, TACTILE
************************************************************
* 1-669-276-11 10 KEY BOARD
************
< CONNECTOR >
CNS205 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
< RESISTOR >
R232 1-249-411-11 CARBON 330 5% 1/4W
R233 1-249-413-11 CARBON 470 5% 1/4W F
R234 1-249-415-11 CARBON 680 5% 1/4W F
R235 1-249-417-11 CARBON 1K 5% 1/4W F
R236 1-249-419-11 CARBON 1.5K 5% 1/4W F
R237 1-249-421-11 CARBON 2.2K 5% 1/4W F
R238 1-247-843-11 CARBON 3.3K 5% 1/4W
R239 1-249-411-11 CARBON 330 5% 1/4W
R240 1-249-413-11 CARBON 470 5% 1/4W F
R241 1-249-415-11 CARBON 680 5% 1/4W F
R242 1-249-417-11 CARBON 1K 5% 1/4W F
R243 1-249-419-11 CARBON 1.5K 5% 1/4W F
R244 1-249-421-11 CARBON 2.2K 5% 1/4W F
R245 1-247-843-11 CARBON 3.3K 5% 1/4W
R246 1-249-411-11 CARBON 330 5% 1/4W
R247 1-249-413-11 CARBON 470 5% 1/4W F
R248 1-249-415-11 CARBON 680 5% 1/4W F
R249 1-249-417-11 CARBON 1K 5% 1/4W F
R250 1-249-419-11 CARBON 1.5K 5% 1/4W F
R251 1-249-421-11 CARBON 2.2K 5% 1/4W F
R252 1-247-843-11 CARBON 3.3K 5% 1/4W
R253 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S217 1-554-303-21 SWITCH, TACTILE (EFFECT/DELAY)
S218 1-554-303-21 SWITCH, TACTILE (SURROUND ON/OFF)
S219 1-554-303-21 SWITCH, TACTILE (BASS BOOST)
S220 1-554-303-21 SWITCH, TACTILE (PHONES)(AEP,UK,G,EE)
S221 1-554-303-21 SWITCH, TACTILE (TUNER) (AEP,UK,G,EE)
S222 1-554-303-21 SWITCH, TACTILE (TV/LD)
S223 1-554-303-21 SWITCH, TACTILE (VIDEO)
S224 1-554-303-21 SWITCH, TACTILE (SHIFT)
S225 1-554-303-21 SWITCH, TACTILE (6)
S226 1-554-303-21 SWITCH, TACTILE (7)
S227 1-554-303-21 SWITCH, TACTILE (8)
S228 1-554-303-21 SWITCH, TACTILE (9)
S229 1-554-303-21 SWITCH, TACTILE (0)
S230 1-554-303-21 SWITCH, TACTILE (SET UP)
S231 1-554-303-21 SWITCH, TACTILE (CD) (AEP,UK,G,EE)
S232 1-554-303-21 SWITCH, TACTILE (DIRECT TUNING)
S233 1-554-303-21 SWITCH, TACTILE (1)
S234 1-554-303-21 SWITCH, TACTILE (2)
S235 1-554-303-21 SWITCH, TACTILE (3)
S236 1-554-303-21 SWITCH, TACTILE (4)
S237 1-554-303-21 SWITCH, TACTILE (5)
S238 1-554-303-21 SWITCH, TACTILE (TAPE/MD)
S239 1-554-303-21 SWITCH, TACTILE (MODE)
S241 1-762-751-11 SWITCH, TACTILE (TUNER)
(US,CND,AUS,E,SP,MY,CH)
S242 1-762-751-11 SWITCH, TACTILE (CD)
(US,CND,AUS,E,SP,MY,CH)
S243 1-554-303-21 SWITCH, TACTILE (5.1/DVD INPUT)
************************************************************
MISCELLANEOUS
*************
12 1-782-086-11 WIRE (FLAT TYPE) (27 CORE)
13 1-769-911-11 WIRE (FLAT TYPE) (9 CORE)
14 1-769-972-11 WIRE (FLAT TYPE) (13 CORE)
! 58 1-777-071-21 CORD, POWER (E,SP,MY,CH)
! 58 1-783-203-11 CORD, POWER (AUS)
! 58 1-783-204-11 CORD, POWER (US,CND)
63 1-693-407-41 TUNER (US,CND)
63 1-693-408-41 TUNER (AUS,AEP,UK,G,E,SP,MY,CH)
63 1-693-411-41 TUNER (EE)
64 1-782-080-11 WIRE (FLAT TYPE) (15 CORE)
65 1-782-074-11 WIRE (FLAT TYPE) (7 CORE)
! CNJ902 1-251-416-11 OUTLET, AC (AUS)
! CNJ902 1-526-794-11 OUTLET, AC (AEP,G,EE,E,SP,MY,CH)
! T901 1-431-267-11 TRANSFORMER, POWER (US)
! T901 1-431-268-11 TRANSFORMER, POWER (CND)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
VR-TONE 10 KEY
