Sony STR-DE485 - Page 44

44
STR-DE485/DE485E
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R123 1-249-413-11 CARBON 470 5% 1/4W
R124 1-249-415-11 CARBON 680 5% 1/4W
R125 1-249-417-11 CARBON 1K 5% 1/4W
R126 1-249-419-11 CARBON 1.5K 5% 1/4W
R127 1-249-421-11 CARBON 2.2K 5% 1/4W
R128 1-249-425-11 CARBON 4.7K 5% 1/4W
R131 1-249-409-11 CARBON 220 5% 1/4W
R132 1-249-411-11 CARBON 330 5% 1/4W
R133 1-249-413-11 CARBON 470 5% 1/4W
R134 1-249-415-11 CARBON 680 5% 1/4W
R135 1-249-417-11 CARBON 1K 5% 1/4W
R136 1-249-419-11 CARBON 1.5K 5% 1/4W
R137 1-249-421-11 CARBON 2.2K 5% 1/4W
R141 1-249-421-11 CARBON 2.2K 5% 1/4W
R142 1-249-421-11 CARBON 2.2K 5% 1/4W
R143 1-249-421-11 CARBON 2.2K 5% 1/4W
R144 1-249-421-11 CARBON 2.2K 5% 1/4W
R148 1-249-421-11 CARBON 2.2K 5% 1/4W
R150 1-249-440-11 CARBON 82K 5% 1/4W
R153 1-247-807-31 CARBON 100 5% 1/4W
R154 1-249-393-11 CARBON 10 5% 1/4W
R155 1-249-441-11 CARBON 100K 5% 1/4W
R160 1-247-807-31 CARBON 100 5% 1/4W
R161 1-247-807-31 CARBON 100 5% 1/4W
R162 1-247-807-31 CARBON 100 5% 1/4W
R163 1-247-807-31 CARBON 100 5% 1/4W
R164 1-249-429-11 CARBON 10K 5% 1/4W
R165 1-249-403-11 CARBON 68 5% 1/4W
R166 1-249-409-11 CARBON 220 5% 1/4W
R167 1-249-409-11 CARBON 220 5% 1/4W
R168 1-249-409-11 CARBON 220 5% 1/4W
R169 1-249-409-11 CARBON 220 5% 1/4W
R170 1-249-429-11 CARBON 10K 5% 1/4W
R171 1-249-429-11 CARBON 10K 5% 1/4W
R175 1-249-393-11 CARBON 10 5% 1/4W
R198 1-249-381-11 CARBON 1 5% 1/4W
R199 1-249-381-11 CARBON 1 5% 1/4W
< ROTARY ENCODER >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (PRESET/PTY SELECT –)
(AEP,UK)
S100 1-771-410-21 SWITCH, TACTILE (PRESET TUNING –)
(EXCEPT AEP,UK)
S101 1-771-410-21 SWITCH, TACTILE (TUNING –)
S102 1-771-410-21 SWITCH, TACTILE (NAME)
S103 1-771-410-21 SWITCH, TACTILE (ENTER)
S104 1-771-410-21 SWITCH, TACTILE (SOUND CONTROL LEVEL)
S105 1-771-410-21 SWITCH, TACTILE (SOUND CONTROL SURR)
S106 1-771-410-21 SWITCH, TACTILE (MENU –)
S107 1-771-410-21 SWITCH, TACTILE (SET UP)
S108 1-771-410-21 SWITCH, TACTILE (VIDEO 1)
S109 1-771-410-21 SWITCH, TACTILE (MD/TAPE)
S110 1-771-410-21 SWITCH, TACTILE (MUTING)
S111 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S112 1-771-410-21 SWITCH, TACTILE (TREBLE +)
S113 1-771-410-21 SWITCH, TACTILE (MULTI CH IN)
S114 1-771-410-21 SWITCH, TACTILE (CD)
S115 1-771-410-21 SWITCH, TACTILE (TUNER)
S116 1-771-410-21 SWITCH, TACTILE (VIDEO 2)
S117 1-771-410-21 SWITCH, TACTILE (BASS –)
S118 1-771-410-21 SWITCH, TACTILE (SOUND FIELD MODE)
S119 1-771-410-21 SWITCH, TACTILE (PRESET/PTY SELECT +)
(AEP,UK)
S119 1-771-410-21 SWITCH, TACTILE (PRESET TUNING +)
(EXCEPT AEP,UK)
S120 1-771-410-21 SWITCH, TACTILE (FM/AM) (AEP,UK)
S120 1-771-410-21 SWITCH, TACTILE (FM) (EXCEPT AEP,UK)
S121 1-771-410-21 SWITCH, TACTILE (SHIFT)
S122 1-771-410-21 SWITCH, TACTILE (FM MODE)
S123 1-771-410-21 SWITCH, TACTILE (MENU >)
S124 1-771-410-21 SWITCH, TACTILE (MENU <)
S125 1-771-410-21 SWITCH, TACTILE (PTY) (AEP,UK)
S125 1-771-410-21 SWITCH, TACTILE (AM) (EXCEPT AEP,UK)
S126 1-771-410-21 SWITCH, TACTILE (MEMORY)
S127 1-771-410-21 SWITCH, TACTILE (TUNING +)
S128 1-771-410-21 SWITCH, TACTILE (MENU +)
S130 1-771-410-21 SWITCH, TACTILE (TREBLE –)
S131 1-771-410-21 SWITCH, TACTILE (DVD/LD)
S132 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO EX C)
S133 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO EX B)
S134 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO EX A)
S135 1-771-410-21 SWITCH, TACTILE (BASS +)
S136 1-771-410-21 SWITCH, TACTILE (SOUND FIELD A.F.D.)
S137 1-771-410-21 SWITCH, TACTILE (SOUND FIELD 2CH)
*************************************************************
1-683-763-11 HEADPHONE BOARD
*****************
< CAPACITOR >
C790 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP791 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J791 1-815-313-21 JACK (PHONES) (CH,SP,TW)
J791 1-815-314-21 JACK (PHONES) (EXCEPT CH,SP,TW)
*************************************************************
DISPLAY HEADPHONE
