Sony STR-DE485 - Main Board Components

45
STR-DE485/DE485E
Ref. No. Part No. Description Remark
A-4727-811-A MAIN BOARD, COMPLETE (US)
A-4727-836-A MAIN BOARD, COMPLETE (CND)
A-4727-848-A MAIN BOARD, COMPLETE (AEP,UK)
A-4727-998-A MAIN BOARD, COMPLETE (E,MX,AR)
A-4728-004-A MAIN BOARD, COMPLETE (CH)
A-4728-861-A MAIN BOARD, COMPLETE (AUS,SP,TW)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C371 1-161-494-00 CERAMIC 0.022uF 25V
C372 1-161-494-00 CERAMIC 0.022uF 25V
C373 1-161-494-00 CERAMIC 0.022uF 25V
C374 1-164-159-11 CERAMIC 0.1uF 50V
C375 1-161-494-00 CERAMIC 0.022uF 25V
C376 1-161-494-00 CERAMIC 0.022uF 25V
C402 1-126-964-11 ELECT 10uF 20% 50V
C404 1-126-964-11 ELECT 10uF 20% 50V
C405 1-126-964-11 ELECT 10uF 20% 50V
C406 1-126-964-11 ELECT 10uF 20% 50V
C407 1-126-964-11 ELECT 10uF 20% 50V
C408 1-126-964-11 ELECT 10uF 20% 50V
C409 1-126-964-11 ELECT 10uF 20% 50V
C411 1-126-961-11 ELECT 2.2uF 20% 50V
C412 1-126-961-11 ELECT 2.2uF 20% 50V
C413 1-126-964-11 ELECT 10uF 20% 50V
C414 1-126-964-11 ELECT 10uF 20% 50V
C415 1-124-261-00 ELECT 10uF 20% 50V
C416 1-126-964-11 ELECT 10uF 20% 50V
C417 1-124-261-00 ELECT 10uF 20% 50V
C418 1-126-964-11 ELECT 10uF 20% 50V
C419 1-126-964-11 ELECT 10uF 20% 50V
C431 1-126-961-11 ELECT 2.2uF 20% 50V
C432 1-126-961-11 ELECT 2.2uF 20% 50V
C433 1-126-964-11 ELECT 10uF 20% 50V
C452 1-126-964-11 ELECT 10uF 20% 50V
C454 1-126-964-11 ELECT 10uF 20% 50V
C455 1-126-964-11 ELECT 10uF 20% 50V
C456 1-126-964-11 ELECT 10uF 20% 50V
C457 1-126-964-11 ELECT 10uF 20% 50V
C458 1-126-964-11 ELECT 10uF 20% 50V
C459 1-126-964-11 ELECT 10uF 20% 50V
C461 1-126-961-11 ELECT 2.2uF 20% 50V
C462 1-126-961-11 ELECT 2.2uF 20% 50V
C464 1-164-159-11 CERAMIC 0.1uF 50V
C465 1-126-969-11 ELECT 220uF 20% 50V
C466 1-126-964-11 ELECT 10uF 20% 50V
C467 1-164-159-11 CERAMIC 0.1uF 50V
C471 1-126-963-11 ELECT 4.7uF 20% 50V
C472 1-126-963-11 ELECT 4.7uF 20% 50V
C481 1-126-964-11 ELECT 10uF 20% 50V
C482 1-126-964-11 ELECT 10uF 20% 50V
C483 1-126-964-11 ELECT 10uF 20% 50V
C484 1-126-964-11 ELECT 10uF 20% 50V
C485 1-126-964-11 ELECT 10uF 20% 50V
C486 1-126-964-11 ELECT 10uF 20% 50V
C487 1-126-964-11 ELECT 10uF 20% 50V
C488 1-164-159-11 CERAMIC 0.1uF 50V
C489 1-128-809-11 CERAMIC 100PF 5% 50V
C490 1-128-809-11 CERAMIC 100PF 5% 50V
C491 1-126-964-11 ELECT 10uF 20% 50V
C492 1-126-964-11 ELECT 10uF 20% 50V
C493 1-126-964-11 ELECT 10uF 20% 50V
C494 1-126-964-11 ELECT 10uF 20% 50V
C495 1-126-964-11 ELECT 10uF 20% 50V
C496 1-126-963-11 ELECT 4.7uF 20% 50V
C497 1-128-809-11 CERAMIC 100PF 5% 50V
C498 1-162-211-31 CERAMIC 33PF 5% 50V
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C503 1-104-665-11 ELECT 100uF 20% 10V
C504 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C505 1-101-810-00 CERAMIC 100PF 5% 500V
C506 1-101-810-00 CERAMIC 100PF 5% 500V
C507 1-128-809-11 CERAMIC 100PF 5% 50V
C510 1-126-947-11 ELECT 47uF 20% 25V
C511 1-136-157-00 FILM 0.022uF 5% 50V
C516 1-162-815-11 CERAMIC 47PF 5% 500V
C517 1-162-815-11 CERAMIC 47PF 5% 500V
C519 1-128-813-11 CERAMIC 220PF 5% 50V
C540 1-126-964-11 ELECT 10uF 20% 50V
C541 1-127-876-11 CERAMIC 0.01uF 10% 50V
C601 1-126-963-11 ELECT 4.7uF 20% 50V
C603 1-104-665-11 ELECT 100uF 20% 10V
C604 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C605 1-102-233-00 CERAMIC 33PF 10% 500V
C606 1-128-813-11 CERAMIC 220PF 5% 50V
C607 1-128-809-11 CERAMIC 100PF 5% 50V
C610 1-126-947-11 ELECT 47uF 20% 25V
C611 1-136-157-00 FILM 0.022uF 5% 50V
C616 1-106-355-12 MYLAR 0.0033uF 5% 200V
C617 1-106-355-12 MYLAR 0.0033uF 5% 200V
C619 1-128-813-11 CERAMIC 220PF 5% 50V
C620 1-162-815-11 CERAMIC 47PF 5% 500V
C621 1-162-815-11 CERAMIC 47PF 5% 500V
C640 1-126-964-11 ELECT 10uF 20% 50V
C642 1-127-876-11 CERAMIC 0.01uF 10% 50V
C651 1-126-963-11 ELECT 4.7uF 20% 50V
C653 1-104-665-11 ELECT 100uF 20% 10V
C654 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C655 1-102-233-00 CERAMIC 33PF 10% 500V
C656 1-128-813-11 CERAMIC 220PF 5% 50V
C657 1-128-809-11 CERAMIC 100PF 5% 50V
C660 1-126-947-11 ELECT 47uF 20% 25V
C661 1-136-157-00 FILM 0.022uF 5% 50V
C666 1-162-815-11 CERAMIC 47PF 5% 500V
Ref. No. Part No. Description Remark
MAIN
