Sony STR-DE515 - Page 15

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 35 —
< RELAY >
RY551 1-515-920-11 RELAY (24V)
RY601 1-515-920-11 RELAY (24V)
RY701 1-515-920-11 RELAY (24V)
RY801 1-515-894-11 RELAY
(D460Z/DE515:US,E,SP,AUS,EA,PX,MY/V505)
RY851 1-515-918-11 RELAY (DE515:Canadian)
RY852 1-515-918-11 RELAY (DE515:Canadian)
< TERMINAL >
TM1 1-537-714-11 TERMINAL BOARD (ANTENNA)
(DE515:SP,AUS,MY/V505)
TM1 1-694-265-11 TERMINAL BOARD (ANTENNA)(DE515:E,EA,PX)
TM1 1-537-240-51 TERMINAL BOARD (ANTENNA)
(D460Z/DE515:US,Canadian)
TM601 1-537-510-11 TERMINAL BOARD (6P)
(SURROUND SPEAKERS)
TM701 1-537-376-11 TERMINAL BOARD (FRONT SPEAKERS)
< TUNER >
TU001 1-233-594-11 ENCAPSULATED COMPONENT
(DE515:E,SP,AUS,EA,PX,MY/V505)
TU001 1-233-593-11 ENCAPSULATED COMPONENT
(D460Z/DE515:US,Canadian)
< VIBRATOR >
X301 1-579-952-21 VIBRATOR, CERAMIC 8MHz
************************************************************
* 1-665-286-11 PRIMARY BOARD
**************
(D460Z/DE515:US,Canadian,SP,MY,AUS/V505)
1-533-233-21 HOLDER, FUSE
< FUSE >
! F901 1-532-464-51 FUSE (T2.5AL/250V) (DE515:AUS/V505)
! F901 1-533-310-11 FUSE (6.3A/125V) (D460Z/DE515:US,Canadian)
**************************************************************
* 1-665-287-11 SECONDARY BOARD
***************
1-533-233-21 HOLDER, FUSE
< CONNECTOR >
CNP801 1-764-479-11 PIN, CONNECTOR (PC BOARD) 10P
< FUSE >
! F801 1-532-464-51 FUSE (T3.15A/250V) (DE515:SP,MY/V505)
! F801 1-576-108-11 FUSE, GLASS TUBE (4A/125V)
(D460Z/DE515:US,Canadian)
! F801 1-532-504-51 FUSE (T4AL) (DE515:E,EA,PX,AUS)
! F802 1-532-464-51 FUSE (T3.15AL) (DE515:SP,MY/V505)
! F802 1-532-504-51 FUSE (T4AL) (DE515:E,EA,PX,AUS)
! F802 1-576-108-11 FUSE, GLASS TUBE (4A/125V)
(D460Z/DE515:US,Canadian)
************************************************************
* 1-665-263-11 SELECTOR BOARD (DE515:E,EA,PX)
***************
1-533-233-21 HOLDER, FUSE
< CONNECTOR >
* CNP907 1-565-395-11 PIN, CONNECTOR 3P
CNP908 1-564-321-00 PIN, CONNECTOR 2P
* CNP910 1-564-687-11 PIN, CONNECTOR 3P
< FUSE >
! F904 1-532-464-51 FUSE (T2.5AL/250V)
< SWITCH >
! S901 1-571-437-11 SWITCH, POWER (VOLTAGE SELECTOR)
************************************************************
* 1-665-289-11 SP SW BOARD
************
< CONNECTOR >
CNP703 1-764-474-11 PIN, CONNECTOR (PC BOARD) 5P
CNP704 1-764-473-11 PIN, CONNECTOR (PC BOARD) 3P
< JACK >
J741 1-750-735-11 JACK (LARGE TYPE)(PHONES)(V505)
J741 1-750-733-11 JACK (LARGE TYPE)(PHONES)(D460Z/DE515)
< RESISTOR >
R741 1-247-753-11 CARBON 1.2K 5% 1/2W
R742 1-247-753-11 CARBON 1.2K 5% 1/2W
R791 1-247-753-11 CARBON 1.2K 5% 1/2W
R792 1-247-753-11 CARBON 1.2K 5% 1/2W
< SWITCH >
S701 1-762-319-11 SWITCH, PUSH (2 KEY)(SPEAKERS)
************************************************************
* 1-665-285-11 STBY BOARD
***********
1-533-233-21 HOLDER, FUSE
< JACK >
! CNJ902 1-540-057-11 OUTLET, AC (POLAR) (US,Canadian,E,EA,PX)
< CONNECTOR >
CNP802 1-779-495-11 PLUG, CONNECTOR PIN 4P
CNP901 1-564-321-00 PIN, CONNECTOR 2P
CNP902 1-564-321-00 PIN, CONNECTOR 2P (DE515:E,EA,PX)
CNP903 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
(DE515:SP,MY,AUS/V505)
CNP905 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
(DE515:E,EA,PX)
* CNP906 1-564-687-11 PIN, CONNECTOR 3P (DE515:E)
< DIODE >
D816 8-719-987-63 DIODE 1N4148M
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
SECONDARY SELECTOR SP SW STBY
PRIMARY
MAIN
