Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 36 —
< FUSE >
! F902 1-532-464-51 FUSE (T2.5AL) (SP,MY,AUS,CH)
< TERMINAL >
* G900 1-537-738-21 TERMINAL,EARTH (US,Canadian)
< RESISTOR >
! R901 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,Canadian)
< RELAY >
! RY901 1-515-720-11 RELAY
< TRANSFORMER >
! T902 1-450-358-11 TRANSFORMER, POWER
(E,SP,AUS,EA,PX,MY,CH)
! T902 1-450-361-11 TRANSFORMER, POWER (US,Canadian)
************************************************************
* A-4392-780-A SWITCH BOARD, COMPLETE
***********************
< CAPACITOR >
C425 1-126-096-11 ELECT 10uF 20% 35V
C426 1-126-096-11 ELECT 10uF 20% 35V
C427 1-162-207-31 CERAMIC 22PF 5% 50V
C428 1-124-252-00 ELECT 0.33uF 20% 50V
C429 1-130-489-00 MYLAR 0.033uF 5% 50V
C430 1-102-973-00 CERAMIC 100PF 5% 50V
C432 1-126-096-11 ELECT 10uF 20% 35V
C433 1-126-096-11 ELECT 10uF 20% 35V
C475 1-126-096-11 ELECT 10uF 20% 35V
C476 1-126-096-11 ELECT 10uF 20% 35V
C477 1-162-207-31 CERAMIC 22PF 5% 50V
C478 1-124-252-00 ELECT 0.33uF 20% 50V
C479 1-130-489-00 MYLAR 0.033uF 5% 50V
C480 1-102-973-00 CERAMIC 100PF 5% 50V
C492 1-124-464-11 ELECT 0.22uF 20% 50V
C500 1-164-159-11 CERAMIC 0.1uF 50V
C501 1-162-294-31 CERAMIC 0.001uF 10% 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C511 1-126-163-11 ELECT 4.7uF 20% 50V
C512 1-126-163-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
* CN501 1-569-306-11 SOCKET, CONNECTOR (L TYRE) 15P
* CN505 1-569-306-11 SOCKET, CONNECTOR (L TYRE) 15P
* CNP507 1-770-394-11 PIN, CONNECTOR (PC BOARD) 10P
CNS503 1-695-092-11 SOCKET, CONNECTOR 7P
CNS504 1-695-092-11 SOCKET, CONNECTOR 7P
< DIODE >
D421 8-719-987-63 DIODE 1N4148M
< IC >
IC404 8-759-636-74 IC M5218AP-22
IC500 8-759-805-14 IC LC7822
IC502 8-759-636-74 IC M5218AP-22
< TRANSISTOR >
Q401 8-729-202-67 TRANSISTOR 2SK246-GR3
Q402 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q451 8-729-202-67 TRANSISTOR 2SK246-GR3
Q452 8-729-141-30 TRANSISTOR 2SC3623A-LK
< RESISTOR >
R426 1-249-429-11 CARBON 10K 5% 1/4W
R427 1-249-439-11 CARBON 68K 5% 1/4W
R428 1-249-417-11 CARBON 1K 5% 1/4W F
R430 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-247-843-11 CARBON 3.3K 5% 1/4W
R432 1-247-883-00 CARBON 150K 5% 1/4W
R433 1-249-427-11 CARBON 6.8K 5% 1/4W F
R434 1-249-413-11 CARBON 470 5% 1/4W F
R438 1-249-441-11 CARBON 100K 5% 1/4W
R441 1-249-441-11 CARBON 100K 5% 1/4W
R444 1-247-903-00 CARBON 1M 5% 1/4W
R464 1-247-903-00 CARBON 1M 5% 1/4W
R469 1-247-903-00 CARBON 1M 5% 1/4W
R476 1-249-429-11 CARBON 10K 5% 1/4W
R477 1-249-439-11 CARBON 68K 5% 1/4W
R478 1-249-417-11 CARBON 1K 5% 1/4W F
R480 1-249-437-11 CARBON 47K 5% 1/4W
R481 1-247-843-11 CARBON 3.3K 5% 1/4W
R482 1-247-883-00 CARBON 150K 5% 1/4W
R483 1-249-427-11 CARBON 6.8K 5% 1/4W F
R484 1-249-413-11 CARBON 470 5% 1/4W F
R491 1-249-441-11 CARBON 100K 5% 1/4W
R492 1-247-903-00 CARBON 1M 5% 1/4W
R494 1-247-903-00 CARBON 1M 5% 1/4W
R501 1-247-843-11 CARBON 3.3K 5% 1/4W
R502 1-249-425-11 CARBON 4.7K 5% 1/4W F
R503 1-249-429-11 CARBON 10K 5% 1/4W
R504 1-249-425-11 CARBON 4.7K 5% 1/4W F
R505 1-249-421-11 CARBON 2.2K 5% 1/4W
R507 1-249-417-11 CARBON 1K 5% 1/4W F
R508 1-247-849-11 CARBON 5.6K 5% 1/4W
R511 1-249-441-11 CARBON 100K 5% 1/4W
R512 1-249-441-11 CARBON 100K 5% 1/4W
R519 1-249-429-11 CARBON 10K 5% 1/4W
R520 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
* 1-665-261-11 VIDEO BOARD
***********
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C250 1-126-960-11 ELECT 1uF 20% 50V
C251 1-126-960-11 ELECT 1uF 20% 50V
C252 1-164-159-11 CERAMIC 0.1uF 50V
C253 1-104-664-11 ELECT 47uF 20% 25V
C254 1-164-159-11 CERAMIC 0.1uF 50V
SWITCH VIDEOSTBY
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
