Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 37 —
C255 1-126-924-11 ELECT 330uF 20% 10V
C256 1-162-215-31 CERAMIC 47PF 5% 50V
C257 1-162-215-31 CERAMIC 47PF 5% 50V
C258 1-126-960-11 ELECT 1uF 20% 50V
C291 1-126-795-11 ELECT 10uF 20% 50V
(DE515,MY/V505)
C292 1-104-664-11 ELECT 47uF 20% 25V
(DE515,MY/V505)
< CONNECTOR >
CNS250 1-569-060-11 SOCKET, CONNECTOR 11P
CNS506 1-569-321-11 SOCKET, CONNECTOR 15P
< DIODE >
D291 8-719-001-30 DIODE UZL-9H3 (DE515/V505)
D292 8-719-987-63 DIODE 1N4148M (DE515/V505)
D310 8-719-987-63 DIODE 1N4148M (DE515/V505)
< IC >
IC251 8-759-333-84 IC NJM2279D
IC290 8-759-634-65 IC M5278D09 (DE515/V505)
< JACK >
J251 1-695-317-21 JACK, PIN 2P (VIDEO/TV DBS)
J252 1-766-199-11 JACK, PIN 3P (VIDEO/MONITOR)
J253 1-774-843-11 JACK, PIN 1P (WOOFER)
J254 1-774-136-11 CONNECTOR, ROUND TYPE 6P
(REAR SPEAKER) (DE515/V505)
J501 1-779-380-11 JACK, PIN 6P
(FRONT/REAR/WOOFER/CENTER)
< TRANSISTOR >
Q291 8-729-119-78 TRANSISTOR 2SC403SP-51 (DE515/V505)
Q292 8-729-030-19 TRANSISTOR 2SB1640 (DE515/V505)
Q293 8-729-209-15 TRANSISTOR 2SB2012 (DE515/V505)
Q367 8-729-119-78 TRANSISTOR 2SC403SP-51 (DE515/V505)
< RESISTOR >
R251 1-247-804-11 CARBON 75 5% 1/4W
R252 1-247-804-11 CARBON 75 5% 1/4W
R253 1-247-804-11 CARBON 75 5% 1/4W
R254 1-247-804-11 CARBON 75 5% 1/4W
R255 1-249-429-11 CARBON 10K 5% 1/4W
R256 1-249-429-11 CARBON 10K 5% 1/4W
! R257 1-249-407-11 CARBON 150 5% 1/4W F
! R258 1-249-411-11 CARBON 330 5% 1/4W
R259 1-247-804-11 CARBON 75 5% 1/4W
R262 1-249-433-11 CARBON 22K 5% 1/4W
(DE515/V505)
R263 1-249-421-11 CARBON 2.2K 5% 1/4W
(DE515/V505)
R264 1-249-433-11 CARBON 22K 5% 1/4W
(DE515/V505)
R272 1-249-417-11 CARBON 1K 5% 1/4W F
R274 1-249-417-11 CARBON 1K 5% 1/4W F
R276 1-249-417-11 CARBON 1K 5% 1/4W F
R278 1-249-417-11 CARBON 1K 5% 1/4W F
R280 1-249-417-11 CARBON 1K 5% 1/4W F
R282 1-249-417-11 CARBON 1K 5% 1/4W F
R287 1-249-437-11 CARBON 47K 5% 1/4W
(DE515:SP,MY/V505)
R287 1-247-871-11 CARBON 47K 5% 1/4W
(DE515:US,Canadian,E,EA,PX,AUS)
R288 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE515:SP,MY/V505)
R288 1-247-847-11 CARBON 4.7K 5% 1/4W
(DE515:US,Canadian,E,EA,PX,AUS)
! R290 1-215-882-00 METAL OXIDE 22 5% 2W F
(DE515/V505)
! R291 1-215-882-00 METAL OXIDE 22 5% 2W F
(DE515/V505)
! R292 1-215-882-00 METAL OXIDE 22 5% 2W F
(DE515/V505)
! R293 1-215-882-00 METAL OXIDE 22 5% 2W F
(DE515/V505)
! R294 1-215-882-00 METAL OXIDE 22 5% 2W F
(DE515/V505)
! R295 1-215-882-00 METAL OXIDE 22 5% 2W F
(DE515/V505)
! R296 1-215-882-00 METAL OXIDE 22 5% 2W F
(DE515/V505)
! R297 1-215-882-00 METAL OXIDE 22 5% 2W F
(DE515/V505)
! R298 1-215-882-00 METAL OXIDE 22 5% 2W F
(DE515/V505)
! R299 1-215-882-00 METAL OXIDE 22 5% 2W F
(DE515/V505)
R397 1-249-419-11 CARBON 1.5K 5% 1/4W
R399 1-249-426-11 CARBON 5.6K 5% 1/4W
< RELAY>
RY301 1-515-793-11 RELAY
************************************************************
* A-4392-778-A VR TONE BOARD, COMPLETE
************************
(Including VOLUME BOARD)
< CAPACITOR >
C220 1-126-301-11 ELECT 1uF 20% 50V
C221 1-126-301-11 ELECT 1uF 20% 50V
C361 1-164-159-11 CERAMIC 0.1uF 50V
C362 1-164-159-11 CERAMIC 0.1uF 50V
C363 1-164-159-11 CERAMIC 0.1uF 50V
C364 1-164-159-11 CERAMIC 0.1uF 50V
C365 1-164-159-11 CERAMIC 0.1uF 50V
C381 1-126-963-11 ELECT 4.7uF 20% 50V
C382 1-126-963-11 ELECT 4.7uF 20% 50V
C383 1-126-963-11 ELECT 4.7uF 20% 50V
C384 1-126-963-11 ELECT 4.7uF 20% 50V
C385 1-126-963-11 ELECT 4.7uF 20% 50V
C421 1-137-440-11 FILM 0.018uF 5% 50V
C422 1-124-463-00 ELECT 0.1uF 20% 50V
C423 1-137-368-11 FILM 0.0047uF 5% 50V
VIDEO
VR TONE
(VOLUME)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
