Sony STR-DE515 - Page 18

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 38 —
C424 1-137-372-11 FILM 0.022uF 5% 50V
C471 1-137-440-11 FILM 0.018uF 5% 50V
C472 1-124-463-00 ELECT 0.1uF 20% 50V
C473 1-137-368-11 FILM 0.0047uF 5% 50V
C474 1-137-372-11 FILM 0.022uF 5% 50V
< CONNECTOR >
* CNP202 1-770-394-11 PIN, CONNECTOR (PC BOARD) 10P
CNS402 1-568-442-11 SOCKET, CONNECTOR 9P
CNS502 1-569-321-11 SOCKET, CONNECTOR 15P
CNS507 1-770-403-11 HOUSING,CONNECTOR(PC BOARD)10P
< DIODE >
D238 8-719-313-50 DIODE SEL6810A-TH12 (BASS BOOST)
< TRANSISTOR >
Q361 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q362 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q363 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q364 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q365 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q366 8-729-141-30 TRANSISTOR 2SC3623A-LK
< RESISTOR >
R351 1-249-417-11 CARBON 1K 5% 1/4W F
R352 1-249-417-11 CARBON 1K 5% 1/4W F
R353 1-249-417-11 CARBON 1K 5% 1/4W F
R354 1-249-417-11 CARBON 1K 5% 1/4W F
R355 1-249-417-11 CARBON 1K 5% 1/4W F
R361 1-249-425-11 CARBON 4.7K 5% 1/4W F
R362 1-249-425-11 CARBON 4.7K 5% 1/4W F
R363 1-249-425-11 CARBON 4.7K 5% 1/4W F
R364 1-249-425-11 CARBON 4.7K 5% 1/4W F
R365 1-249-425-11 CARBON 4.7K 5% 1/4W F
R366 1-249-441-11 CARBON 100K 5% 1/4W
R367 1-249-441-11 CARBON 100K 5% 1/4W
R368 1-249-441-11 CARBON 100K 5% 1/4W
R369 1-249-441-11 CARBON 100K 5% 1/4W
R370 1-249-441-11 CARBON 100K 5% 1/4W
R371 1-249-441-11 CARBON 100K 5% 1/4W
< RESISTOR >
R421 1-249-430-11 CARBON 12K 5% 1/4W
R422 1-249-422-11 CARBON 2.7K 5% 1/4W F
R423 1-247-903-00 CARBON 1M 5% 1/4W
R424 1-247-903-00 CARBON 1M 5% 1/4W
R425 1-249-415-11 CARBON 680 5% 1/4W F
R471 1-249-430-11 CARBON 12K 5% 1/4W
R472 1-249-422-11 CARBON 2.7K 5% 1/4W F
R473 1-247-903-00 CARBON 1M 5% 1/4W
R474 1-247-903-00 CARBON 1M 5% 1/4W
R475 1-249-415-11 CARBON 680 5% 1/4W F
< VARIABLE RESISTOR >
RV404 1-225-446-11 RES, VAR, CARBON 100KX6
(MASTER VOLUME)
RV421 1-223-362-11 RES, VAR, CARBON 100K/100K (BASS)
RV422 1-223-363-11 RES, VAR, CARBON 125K/125K (TREBLE)
RV423 1-225-447-11 RES, VAR, CARBON 100K/100K (BALANCE)
< SWITCH >
S240 1-762-751-11 SWITCH, TACTILE (BASS BOOST)
************************************************************
MISCELLANEOUS
**************
10 1-782-084-11 WIRE (FLAT TYPE) (23 CORE)
11 1-782-075-11 WIRE (FLAT TYPE) (9 CORE)
12 1-782-243-11 WIRE (FLAT TYPE) 15P
53 1-769-746-61 LEAD (WITH CONNECTOR)
(2 CORE)(DE515:E,EA,PX)
61 1-782-077-11 WIRE (FLAT TYPE) (11 CORE)
! 71 1-696-847-11 CORD, POWER (AUS)
! 71 1-777-070-11 CORD, POWER (US,CND)
! 71 1-777-071-11 CORD, POWER (E,SP,EA,PX,MY,CH)
72 1-569-008-21 ADAPTOR, CONVERSION 2P (E,EA,PX)
! CNJ903 1-251-416-11 OUTLET, A.C. (AUS)
! CNJ903 1-526-794-11 OUTLET, A.C. (SP,MY,CH)
! T901 1-431-267-11 TRANSFORMER, POWER (US)
! T901 1-431-268-11 TRANSFORMER, POWER (Canadian)
! T901 1-431-269-11 TRANSFORMER, POWER (SP,MY,CH)
! T901 1-431-270-11 TRANSFORMER, POWER (AUS)
! T901 1-431-271-11 TRANSFORMER, POWER (E,EA,PX)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-475-136-11 REMOTE COMMANDER (RM-U301)
1-501-594-11 ANTENNA (FM) (DE515:SP,MY,AUS/V505)
1-501-659-11 ANTENNA (FM)
(D460Z/DE515:US,Canadian,E,EA,PX)
1-501-721-11 ANTENNA (LOOP)
3-859-657-21 MANUAL, INSTRUCTION (ENGLISH)
(D460Z/DE515:US,AUS)
3-859-657-31 MANUAL, INSTRUCTION (ENGLISH/FRENCH)
(DE515:Canadian)
3-859-657-61 MANUAL, INSTRUCTION
(ENGLISH/FRENCH/SPANISH/CHINESE)
(DE515:E,SP,EA,PX,MY/V505)
4-981-643-01 COVER,BATTERY (FOR RM-U301)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-880-09 SCREW +BVTT 4X8 (S)
#3 7-685-872-09 SCREW +BVTT 3X8 (S)
#4 7-658-646-71 SCREW +BTP 3X8
STR-D460Z/DE515/V505
Sony Corporation
Home A&V Products Company
9-960-890-11
97D167043-1
Printed in Singapore © 1997.4
Published by Service and Safety
Engineering Dept. (Shibaura)
