Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 72 —
C655 1-126-934-11 ELECT 220uF 20% 10V
C680 1-162-282-31 CERAMIC 100PF 10% 50V
C689 1-164-079-11 CERAMIC 330PF 10% 50V
C699 1-102-934-00 CERAMIC 1.0PF 0.25PF 50V
C801 1-136-153-00 FILM 0.01uF 5% 50V
C802 1-136-153-00 FILM 0.01uF 5% 50V
C803 1-136-153-00 FILM 0.01uF 5% 50V
C804 1-136-153-00 FILM 0.01uF 5% 50V
C811 1-126-953-11 ELECT 2200uF 20% 35V
C812 1-126-952-11 ELECT 1000uF 20% 35V
C813 1-126-937-11 ELECT 4700uF 20% 16V
C993 1-126-960-11 ELECT 1uF 20% 50V
CC04 1-164-070-11 CERAMIC 100PF 5% 50V
CC05 1-164-070-11 CERAMIC 100PF 5% 50V
CC06 1-164-070-11 CERAMIC 100PF 5% 50V
CC08 1-164-070-11 CERAMIC 100PF 5% 50V
CC09 1-164-070-11 CERAMIC 100PF 5% 50V
CC10 1-164-070-11 CERAMIC 100PF 5% 50V
CC11 1-164-070-11 CERAMIC 100PF 5% 50V
CC12 1-164-070-11 CERAMIC 100PF 5% 50V
CC13 1-164-070-11 CERAMIC 100PF 5% 50V
CC54 1-164-070-11 CERAMIC 100PF 5% 50V
CC55 1-164-070-11 CERAMIC 100PF 5% 50V
CC56 1-164-070-11 CERAMIC 100PF 5% 50V
CC58 1-164-070-11 CERAMIC 100PF 5% 50V
CC59 1-164-070-11 CERAMIC 100PF 5% 50V
CC60 1-164-070-11 CERAMIC 100PF 5% 50V
CC61 1-164-070-11 CERAMIC 100PF 5% 50V
CC62 1-164-070-11 CERAMIC 100PF 5% 50V
CC63 1-164-070-11 CERAMIC 100PF 5% 50V
< CONNECTOR >
CNP303 1-779-977-11 PIN, CONNECTOR 6P
CNP601 1-785-104-11 PIN, CONNECTOR 6P
CNP602 1-785-102-21 PIN, CONNECTOR 4P
CNP751 1-779-978-11 PIN, CONNECTOR 3P
CNP801 1-785-102-11 PIN, CONNECTOR 4P
CNP802 1-785-103-11 PIN, CONNECTOR 5P
CNS306 1-784-778-11 CONNECTOR, FFC 17P
< DIODE >
D490 8-719-210-21 DIODE 11EQS04-NTA2B
D491 8-719-210-21 DIODE 11EQS04-NTA2B
D494 8-719-210-21 DIODE 11EQS04-NTA2B
D495 8-719-210-21 DIODE 11EQS04-NTA2B
D496 8-719-210-21 DIODE 11EQS04-NTA2B
D497 8-719-210-21 DIODE 11EQS04-NTA2B
D501 8-719-911-19 DIODE 1SS133T-72
D502 8-719-109-51 DIODE MTZJ-T-72-2.2
D503 8-719-109-51 DIODE MTZJ-T-72-2.2
D504 8-719-911-19 DIODE 1SS133T-72
D505 8-719-911-19 DIODE 1SS133T-72
D506 8-719-911-19 DIODE 1SS133T-72
D545 8-719-911-19 DIODE 1SS133T-72
D546 8-719-911-19 DIODE 1SS133T-72
D547 8-719-911-19 DIODE 1SS133T-72
D548 8-719-911-19 DIODE 1SS133T-72
D549 8-719-911-19 DIODE 1SS133T-72
D551 8-719-911-19 DIODE 1SS133T-72
D552 8-719-109-51 DIODE MTZJ-T-72-2.2
D553 8-719-109-51 DIODE MTZJ-T-72-2.2
D554 8-719-911-19 DIODE 1SS133T-72
D555 8-719-911-19 DIODE 1SS133T-72
D556 8-719-911-19 DIODE 1SS133T-72
D598 8-719-911-19 DIODE 1SS133T-72
D599 8-719-911-19 DIODE 1SS133T-72
D601 8-719-911-19 DIODE 1SS133T-72
D602 8-719-109-51 DIODE MTZJ-T-72-2.2
D603 8-719-109-51 DIODE MTZJ-T-72-2.2
D604 8-719-911-19 DIODE 1SS133T-72
D605 8-719-911-19 DIODE 1SS133T-72
D606 8-719-911-19 DIODE 1SS133T-72
D607 8-719-911-19 DIODE 1SS133T-72
D608 8-719-911-19 DIODE 1SS133T-72
D649 8-719-911-19 DIODE 1SS133T-72
D681 8-719-911-19 DIODE 1SS133T-72
D698 8-719-911-19 DIODE 1SS133T-72
D802 8-719-024-99 DIODE 11ES2-NTA2B
D803 8-719-024-99 DIODE 11ES2-NTA2B
D804 8-719-024-99 DIODE 11ES2-NTA2B
D805 8-719-024-99 DIODE 11ES2-NTA2B
D806 8-719-024-99 DIODE 11ES2-NTA2B
D807 8-719-024-99 DIODE 11ES2-NTA2B
D808 8-719-024-99 DIODE 11ES2-NTA2B
D809 8-719-024-99 DIODE 11ES2-NTA2B
< EARTH TERMINAL >
* EB301 1-537-738-21 TERMINAL, EARTH
* EB302 1-537-738-21 TERMINAL, EARTH
< FUSE >
! F803 1-532-504-51 FUSE TIME LAG 4A/250V (AEP)
! F804 1-533-419-11 FUSE, GLASS CYLINDRICAL (DIA.5) 4A/125V
(US,CND)
! F804 1-532-504-51 FUSE TIME LAG 4A/250V (AEP)
! F805 1-533-419-11 FUSE, GLASS CYLINDRICAL (DIA.5) 4A/125V
(US,CND)
! F805 1-532-504-51 FUSE TIME LAG 4A/250V (AEP)
< IC >
IC301 8-759-582-64 IC TC9273N-004
IC302 8-759-636-74 IC M5218AP-22
IC303 8-759-582-65 IC TC9273N-014
IC304 8-759-636-74 IC M5218AP-22
IC401 8-759-231-59 IC M5F7815L
IC402 8-759-245-87 IC M5F7915L
IC404 8-759-708-05 IC NJM78L05A-T3
IC414 8-759-534-63 IC TC9299P
IC415 8-759-534-63 IC TC9299P
IC416 8-759-534-63 IC TC9299P
IC501 8-759-326-52 IC uPC2581V
IC601 8-759-326-52 IC uPC2581V
< JACK >
J301 1-784-429-11 JACK, PIN 4P (PHONO/CD)
J302 1-784-429-11 JACK, PIN 4P (MD/TAPE)
J304 1-784-920-11 JACK, PIN 6P (TV/LD/DVD/VIDEO 2)
J305 1-784-920-11 JACK, PIN 6P (VIDEO 2/VIDEO 1)
MAIN
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
