Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 73 —
< COIL >
L501 1-411-906-11 COIL, AIR-CORE (AEP)
L501 1-420-872-00 COIL, AIR-CORE (US,CND)
L551 1-411-906-11 COIL, AIR-CORE (AEP)
L551 1-420-872-00 COIL, AIR-CORE (US,CND)
< TRANSISTOR >
Q501 8-729-900-36 TRANSISTOR BA1F4M-TP
Q503 8-729-900-63 TRANSISTOR BN1F4M-TP
Q504 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q505 8-729-026-08 TRANSISTOR 2SC4495
Q506 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q507 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q508 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q509 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q510 8-729-900-63 TRANSISTOR BN1F4M-TP
Q511 8-729-900-63 TRANSISTOR BN1F4M-TP
Q546 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q547 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q548 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q549 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q554 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q555 8-729-026-08 TRANSISTOR 2SC4495
Q556 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q557 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q558 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q559 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q560 8-729-900-63 TRANSISTOR BN1F4M-TP
Q561 8-729-900-63 TRANSISTOR BN1F4M-TP
Q596 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q598 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q599 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q601 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q604 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q605 8-729-026-08 TRANSISTOR 2SC4495
Q606 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q607 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q608 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q609 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q610 8-729-900-63 TRANSISTOR BN1F4M-TP
Q611 8-729-900-63 TRANSISTOR BN1F4M-TP
Q613 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q645 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q681 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q698 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q745 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q992 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
< RESISTOR >
R301 1-249-401-11 CARBON 47 5% 1/4W F
(US,CND)
R301 1-249-425-11 CARBON 4.7K 5% 1/4W F
(AEP)
R302 1-249-441-11 CARBON 100K 5% 1/4W
R303 1-249-440-11 CARBON 82K 5% 1/4W
R304 1-249-408-11 CARBON 180 5% 1/4W F
R305 1-249-428-11 CARBON 8.2K 5% 1/4W F
R306 1-249-441-11 CARBON 100K 5% 1/4W
R307 1-247-807-31 CARBON 100 5% 1/4W
R308 1-249-441-11 CARBON 100K 5% 1/4W
R309 1-249-413-11 CARBON 470 5% 1/4W F
R310 1-249-417-11 CARBON 1K 5% 1/4W F
R311 1-249-417-11 CARBON 1K 5% 1/4W F
R312 1-249-417-11 CARBON 1K 5% 1/4W F
R316 1-249-417-11 CARBON 1K 5% 1/4W F
R317 1-249-417-11 CARBON 1K 5% 1/4W F
R318 1-249-417-11 CARBON 1K 5% 1/4W F
R319 1-249-417-11 CARBON 1K 5% 1/4W F
R320 1-249-417-11 CARBON 1K 5% 1/4W F
R325 1-249-417-11 CARBON 1K 5% 1/4W F
R331 1-247-887-00 CARBON 220K 5% 1/4W
R335 1-247-887-00 CARBON 220K 5% 1/4W
R344 1-247-807-31 CARBON 100 5% 1/4W
R345 1-247-807-31 CARBON 100 5% 1/4W
R346 1-249-397-11 CARBON 22 5% 1/4W F
R347 1-249-397-11 CARBON 22 5% 1/4W F
R351 1-249-401-11 CARBON 47 5% 1/4W F
(US,CND)
R351 1-249-425-11 CARBON 4.7K 5% 1/4W F
(AEP)
R352 1-249-441-11 CARBON 100K 5% 1/4W
R353 1-249-440-11 CARBON 82K 5% 1/4W
R354 1-249-408-11 CARBON 180 5% 1/4W F
R355 1-249-428-11 CARBON 8.2K 5% 1/4W F
R356 1-249-441-11 CARBON 100K 5% 1/4W
R357 1-247-807-31 CARBON 100 5% 1/4W
R358 1-249-441-11 CARBON 100K 5% 1/4W
R359 1-249-413-11 CARBON 470 5% 1/4W F
R360 1-249-417-11 CARBON 1K 5% 1/4W F
R361 1-249-417-11 CARBON 1K 5% 1/4W F
R362 1-249-417-11 CARBON 1K 5% 1/4W F
R366 1-249-417-11 CARBON 1K 5% 1/4W F
R367 1-249-417-11 CARBON 1K 5% 1/4W F
R368 1-249-417-11 CARBON 1K 5% 1/4W F
R369 1-249-417-11 CARBON 1K 5% 1/4W F
R370 1-249-417-11 CARBON 1K 5% 1/4W F
R375 1-249-417-11 CARBON 1K 5% 1/4W F
R381 1-247-887-00 CARBON 220K 5% 1/4W
R385 1-247-887-00 CARBON 220K 5% 1/4W
R386 1-249-437-11 CARBON 47K 5% 1/4W
R391 1-249-437-11 CARBON 47K 5% 1/4W
R394 1-249-397-11 CARBON 22 5% 1/4W F
R395 1-249-397-11 CARBON 22 5% 1/4W F
R396 1-249-417-11 CARBON 1K 5% 1/4W F
R398 1-249-417-11 CARBON 1K 5% 1/4W F
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-439-11 CARBON 68K 5% 1/4W
R503 1-249-439-11 CARBON 68K 5% 1/4W
R504 1-247-843-11 CARBON 3.3K 5% 1/4W
R505 1-249-437-11 CARBON 47K 5% 1/4W
R509 1-247-807-31 CARBON 100 5% 1/4W
R520 1-249-429-11 CARBON 10K 5% 1/4W
R521 1-249-422-11 CARBON 2.7K 5% 1/4W F
R522 1-249-433-11 CARBON 22K 5% 1/4W
R523 1-249-442-11 CARBON 510 5% 1/4W
! R524 1-249-408-11 CARBON 180 5% 1/4W F
! R525 1-249-408-11 CARBON 180 5% 1/4W F
! R526 1-234-182-11 ENCAPSULATED COMPONENT
MAIN
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
