Sony STR-DE695 - Front Panel Section; Back Panel

10
STR-DE695
2-2. FRONT PANEL SECTION
2-3. BACK PANEL
9 front panel section
5
3
two screws
(BVTP3 x 8)
6 two screws
(BVTP3 x 8)
2 CNP791
8 CN201
7 VIDEO3 board
4 five screws
(BVTP3 x 8)
1 CNS505
1 CNP901
2 CN806
3 CNP807
4 CNP501
5 CNS508
6 CNS509
8 two screws (BVTP3 x 8)
qs two screws (BVTP3 x 8)
7 two screws (BVTP3 x 8)
9 five screws
(BVTP3 x 8)
0 five screws
(BVTP3 x 8)
qd screw (BVTP3 x 8
)
qa screw (BVTP3 x 8)
qf back panel
