17
STR-DE695
Pin No. Pin Name I/O Pin Description
55 RSTX I RESET IC
56 VCC — Power supply pin (+3.2 V)
57 X1 I System clock signal input (16.5 MHz)
58 X0 O System clock signal output (16.5 MHz)
59 VSS — Ground
60 VOLT_DETECT_STOP I VOLTAGE DOWN DETECT
61 RDS_INT I RDS CLOCK IN (AEP,UK model only)
62 PW_ON/OFF I POWER ON/OFF SW
63 SIRCS I REMOTE SENSOR
64, 65 NO USED — Not used (Fixed at L)
66 CTRL S OUT O Not used (Fixed at L)
67 DIR CE O DIR CE
68 VCC — Power supply pin (+3.2 V)
69 DI I DIR DATA IN
70 D.DO O DIR DATA OUT
71 ERROR I DIR ERROR
72 XRST1 O AUDIO DSP IC RESET
73 PM1 O AUDIO DSP IC PM1
74 9718.GB9 I AUDIO DSP IC GP9
75 9718.BST1 O AUDIO DSP IC BST1
76 9718.HCS1 O AUDIO DSP IC HCS1
77 VCC — Power supply pin (+3.2 V)
78 9718.HACN1 I AUDIO DSP IC HACN1
79 9718.PLL1 I AUDIO DSP IC PLL1
80 DIR_DATAO O DIR DATA 0
81 DIR_XSTATE O DIR XSTATE
82 DIR_XMODE O DIR XMODE
83 DIR_CKSEL1 O DIR CKSEL1
84 DIR_CLK O DIR CLOCK
85 AK5380_PDN O AK5380 PDN
86 A1 IN I CONTROL A1 INPUT
87 A1 OUT O CONTROL A1 OUTPUT
88 AK4355_CSN O AK4355 CSN
89 AK4355_CDTI O AK4355 CDTI
90 AK4355_CCLK O AK4355 CCLK
91 AK4381_CSN O AK4381 CSN
92 AK4381_PDN O AK4381 PDN
93 AK4355_PDN O AK4355 PDN
94 FLASH_A — FLASH PROGRAMMING (Fixed at L)
95 FLASH_B — FLASH PROGRAMMING (Fixed at L)
96 FLASH_C — FLASH PROGRAMMING (Fixed at H)
97 VCC — Power supply pin (+3.2 V)
98 VSS — Ground
99 EEPROM.SDA I/O EEPROM
100 EEPROM.SCL I/O EEPROM
101 VSS — Ground
102 9718.HCLK O AUDIO DSP IC CLOCK
103 HDIN O AUDIO DSP DATA IN
104 HDOUT I AUDIO DSP HD OUT
105 OSD_CLK O OSD CLOCK
106 OSD_DATA O OSD DATA
107 OSD_LAT O OSD LATCH
108 A_D O AUDIO DSP2 IC
