Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DH720/DH720HP
8181
C679 1-136-157-00 FILM 0.022uF 5% 50V
C702 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C703 1-114-956-81 CERAMIC 10PF 5% 1KV
C705 1-116-177-31 CERAMIC 3PF 1KV
C707 1-126-947-11 ELECT 47uF 20% 25V
C708 1-114-989-81 CERAMIC 47PF 5% 1KV
C709 1-114-989-81 CERAMIC 47PF 5% 1KV
C710 1-126-964-11 ELECT 10uF 20% 50V
C711 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C712 1-126-923-91 ELECT 220uF 20% 10V
C720 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C729 1-136-157-00 FILM 0.022uF 5% 50V
C752 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C753 1-114-956-81 CERAMIC 10PF 5% 1KV
C755 1-116-177-31 CERAMIC 3PF 1KV
C757 1-126-947-11 ELECT 47uF 20% 25V
C758 1-114-989-81 CERAMIC 47PF 5% 1KV
C759 1-114-989-81 CERAMIC 47PF 5% 1KV
C760 1-126-964-11 ELECT 10uF 20% 50V
C761 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C762 1-126-923-91 ELECT 220uF 20% 10V
C770 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C779 1-136-157-00 FILM 0.022uF 5% 50V
C802 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C803 1-114-956-81 CERAMIC 10PF 5% 1KV
C805 1-116-177-31 CERAMIC 3PF 1KV
C807 1-126-947-11 ELECT 47uF 20% 25V
C808 1-114-989-81 CERAMIC 47PF 5% 1KV
C809 1-114-989-81 CERAMIC 47PF 5% 1KV
C810 1-126-964-11 ELECT 10uF 20% 50V
C811 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C812 1-126-923-91 ELECT 220uF 20% 10V
C820 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C829 1-136-157-00 FILM 0.022uF 5% 50V
C852 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C853 1-114-956-81 CERAMIC 10PF 5% 1KV
C855 1-116-177-31 CERAMIC 3PF 1KV
C857 1-126-947-11 ELECT 47uF 20% 25V
C858 1-114-989-81 CERAMIC 47PF 5% 1KV
C859 1-114-989-81 CERAMIC 47PF 5% 1KV
C860 1-126-964-11 ELECT 10uF 20% 50V
C861 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C862 1-126-923-91 ELECT 220uF 20% 10V
C870 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C879 1-136-157-00 FILM 0.022uF 5% 50V
C910 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C911 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C912 1-126-943-11 ELECT 2200uF 20% 25V
C913 1-126-942-61 ELECT 1000uF 20% 25V
C930 1-165-946-11 ELECT (BLOCK) 6800uF 20% 71V
C931 1-165-946-11 ELECT (BLOCK) 6800uF 20% 71V
C932 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C933 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
CC01 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (ECE)
CC02 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (ECE)
CC03 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (ECE)
CC05 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (ECE)
CC08 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (ECE)
CC11 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (ECE)
CC12 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (ECE)
CC13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (ECE)
CC14 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (ECE)
CC15 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (ECE)
CC17 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (ECE)
CC18 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (ECE)
CC51 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (ECE)
CC52 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (ECE)
CC53 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (ECE)
CC55 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (ECE)
CC58 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (ECE)
< CONNECTOR >
*
CN391 1-564-508-11 PLUG, CONNECTOR 5P
CNP410 1-784-039-21 CONNECTOR, BOARD TO BOARD 19P
CNP411 1-784-039-21 CONNECTOR, BOARD TO BOARD 19P
CNP920 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P
*
CNP930 1-564-508-11 PLUG, CONNECTOR 5P
< DIODE >
D301 6-502-961-01 DI DA2J10100L
D302 8-719-049-09 DIODE 1SS367-T3SONY
D303 8-719-049-09 DIODE 1SS367-T3SONY
D326 6-500-335-01 DIODE MC2838-T112-1
D327 6-500-335-01 DIODE MC2838-T112-1
D350 6-502-961-01 DI DA2J10100L
D352 8-719-053-18 DIODE 1SR154-400TE-25
D355 6-502-961-01 DI DA2J10100L
D360 6-502-961-01 DI DA2J10100L
D365 6-502-961-01 DI DA2J10100L
D375 6-502-961-01 DI DA2J10100L
D536 6-501-734-01 DIODE MAZ8056GMLS0
D550 6-502-961-01 DI DA2J10100L
D551 6-502-961-01 DI DA2J10100L
D611 6-502-961-01 DI DA2J10100L
D620 6-502-961-01 DI DA2J10100L
D661 6-502-961-01 DI DA2J10100L
D670 6-502-961-01 DI DA2J10100L
D711 6-502-961-01 DI DA2J10100L
D720 6-502-961-01 DI DA2J10100L
D761 6-502-961-01 DI DA2J10100L
D770 6-502-961-01 DI DA2J10100L
D811 6-502-961-01 DI DA2J10100L
D820 6-502-961-01 DI DA2J10100L
D861 6-502-961-01 DI DA2J10100L
D870 6-502-961-01 DI DA2J10100L
D910 8-719-053-18 DIODE 1SR154-400TE-25
D911 8-719-053-18 DIODE 1SR154-400TE-25
D912 8-719-053-18 DIODE 1SR154-400TE-25
D913 8-719-053-18 DIODE 1SR154-400TE-25
D920 6-502-961-01 DI DA2J10100L
D921 8-719-061-07 DIODE D5SBA60-F
< EARTH TERMINAL >
ET300 1-537-738-21 TERMINAL, GROUND
< FUSE >
0
F910 1-523-085-11 FUSE 2.5A 250V
0
F911 1-523-085-11 FUSE 2.5A 250V
0
F912 1-523-080-11 FUSE 6.3A 250V
0
F913 1-523-080-11 FUSE 6.3A 250V
MAIN
Ver. 1.1
To Next Page
