Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DH720/DH720HP
82
< IC >
IC350 6-712-294-01 IC KIA7807API-U/PF
IC352 6-712-295-01 IC KIA7907PI
IC400 6-716-394-01 IC BD3470KS2
IC501 6-715-582-01 IC STK350-630TS-E
IC601 6-715-582-01 IC STK350-630TS-E
IC701 6-715-582-01 IC STK350-630TS-E
IC801 6-715-582-01 IC STK350-630TS-E
< JACK >
J401 1-774-411-11 JACK, PIN 6P
(VIDEO 1 AUDIO OUT/IN, SAT/CATV AUDIO IN)
J405 1-774-785-11 JACK, PIN 1P (SUBWOOFER AUDIO OUT)
J409 1-794-981-11 JACK, PIN 4P
(SA-CD/CD AUDIO IN, TV AUDIO IN)
< JUMPER RESISTOR >
JR600 1-216-864-11 SHORT CHIP 0
JR601 1-216-864-11 SHORT CHIP 0
JR602 1-216-864-11 SHORT CHIP 0
JR603 1-216-296-11 SHORT CHIP 0
JR604 1-216-864-11 SHORT CHIP 0
JR605 1-216-864-11 SHORT CHIP 0
JR606 1-216-296-11 SHORT CHIP 0
JR607 1-216-296-11 SHORT CHIP 0
JR608 1-216-864-11 SHORT CHIP 0
JR609 1-216-864-11 SHORT CHIP 0
JR700 1-216-864-11 SHORT CHIP 0
JR701 1-216-864-11 SHORT CHIP 0
JR706 1-216-864-11 SHORT CHIP 0
JR707 1-216-296-11 SHORT CHIP 0
< COIL >
L550 1-420-872-52 COIL, AIR-CORE
L628 1-420-872-52 COIL, AIR-CORE
L678 1-420-872-52 COIL, AIR-CORE
L728 1-420-872-52 COIL, AIR-CORE
L778 1-420-872-52 COIL, AIR-CORE
L828 1-420-872-52 COIL, AIR-CORE
L878 1-420-872-52 COIL, AIR-CORE
< TRANSISTOR >
Q301 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q320 6-550-327-01 TR 2SA1514KT146S
Q321 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q323 6-550-327-01 TR 2SA1514KT146S
Q324 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q325 8-729-271-31 TRANSISTOR 2SC2713-G
Q350 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q355 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q360 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q365 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q375 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q550 6-550-327-01 TR 2SA1514KT146S
Q551 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q552 8-729-922-39 TRANSISTOR 2SD2144S-V
Q555 6-550-327-01 TR 2SA1514KT146S
Q601 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q602 8-729-922-39 TRANSISTOR 2SD2144S-V
Q611 6-550-327-01 TR 2SA1514KT146S
Q612 6-550-327-01 TR 2SA1514KT146S
Q651 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q652 8-729-922-39 TRANSISTOR 2SD2144S-V
Q661 6-550-327-01 TR 2SA1514KT146S
Q662 6-550-327-01 TR 2SA1514KT146S
Q701 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q702 8-729-922-39 TRANSISTOR 2SD2144S-V
Q711 6-550-327-01 TR 2SA1514KT146S
Q712 6-550-327-01 TR 2SA1514KT146S
Q751 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q752 8-729-922-39 TRANSISTOR 2SD2144S-V
Q761 6-550-327-01 TR 2SA1514KT146S
Q762 6-550-327-01 TR 2SA1514KT146S
Q801 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q802 8-729-922-39 TRANSISTOR 2SD2144S-V
Q811 6-550-327-01 TR 2SA1514KT146S
Q812 6-550-327-01 TR 2SA1514KT146S
Q851 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q852 8-729-922-39 TRANSISTOR 2SD2144S-V
Q861 6-550-327-01 TR 2SA1514KT146S
Q862 6-550-327-01 TR 2SA1514KT146S
Q920 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R301 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R302 1-249-405-11 CARBON 100 5% 1/4W
R304 1-216-841-11 METAL CHIP 47K 5% 1/10W
R320 1-216-837-11 METAL CHIP 22K 5% 1/10W
R321 1-216-837-11 METAL CHIP 22K 5% 1/10W
R325 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R326 1-216-840-11 METAL CHIP 39K 5% 1/10W
R327 1-216-833-11 METAL CHIP 10K 5% 1/10W
R328 1-216-821-11 METAL CHIP 1K 5% 1/10W
R348 1-216-835-11 METAL CHIP 15K 5% 1/10W
R350 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R351 1-249-399-11 CARBON 33 5% 1/4W
R353 1-216-841-11 METAL CHIP 47K 5% 1/10W
R354 1-216-864-11 SHORT CHIP 0
R355 1-216-821-11 METAL CHIP 1K 5% 1/10W
R356 1-249-399-11 CARBON 33 5% 1/4W
R357 1-216-821-11 METAL CHIP 1K 5% 1/10W
R358 1-216-841-11 METAL CHIP 47K 5% 1/10W
R360 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R361 1-249-399-11 CARBON 33 5% 1/4W
R363 1-216-841-11 METAL CHIP 47K 5% 1/10W
R365 1-249-399-11 CARBON 33 5% 1/4W
R366 1-216-841-11 METAL CHIP 47K 5% 1/10W
R367 1-216-821-11 METAL CHIP 1K 5% 1/10W
R375 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R377 1-249-404-00 CARBON 82 5% 1/4W
R378 1-216-841-11 METAL CHIP 47K 5% 1/10W
R380 1-216-821-11 METAL CHIP 1K 5% 1/10W
R381 1-216-821-11 METAL CHIP 1K 5% 1/10W
R382 1-216-821-11 METAL CHIP 1K 5% 1/10W
R383 1-216-821-11 METAL CHIP 1K 5% 1/10W
R384 1-216-821-11 METAL CHIP 1K 5% 1/10W
R385 1-216-821-11 METAL CHIP 1K 5% 1/10W
R386 1-216-821-11 METAL CHIP 1K 5% 1/10W
R387 1-216-821-11 METAL CHIP 1K 5% 1/10W
R388 1-216-821-11 METAL CHIP 1K 5% 1/10W
MAIN
To Next Page
