16
GB
D:\NORM'S JOB\SONY HA\SO160008\STR-DN1070 (PMRF 02)\4583748131_GB\030CON.fm masterpage: Left
STR-DN1070
4-583-748-13(1)
Select the speaker pattern according to the speaker configuration which you are using.
* You can only enable the SPEAKERS ZONE 2 terminals if you set [SURROUND BACK/ZONE2 Priority] in [Speaker
Settings] to [ZONE2 Terminals], and turn on the ZONE 2 power.
** You can only set [Surround Back Speaker Assign] if the speaker pattern is set to a setting that does not have
surround back and front high speakers.
Connecting Speakers
This receiver allows you to connect up to 7.1-channel system.
The speaker layout diagram is a guide for the ideal speaker placement. You do not need to adjust
your speaker placement exactly the same as the diagram.
Before connecting cables, be sure to disconnect the AC power cord (mains lead).
Before connecting the AC power cord (mains lead), make sure that metallic wires of the speaker cables are
not touching each other between the SPEAKERS terminals.
When you connect a subwoofer with an auto standby function, turn off the function when watching movies.
If the auto standby function is set to on, it turns to standby mode automatically based on the level of the input
signal to the subwoofer, and the sound may not be output.
If you have two subwoofers, you can connect them to both SUBWOOFER OUT jacks.
Speaker configuration and speaker pattern settings
Speaker configuration in each zone
Main zone Zone 2* Zone 3 [Surround
Back
Speaker
Assign]**
[Surround
Speaker
Assign]
Speaker
pattern to
be selected
in [Speaker
Settings]
For
connection,
see page
5.1-channel Not used Not used [Off] [Off] [5.1] 17
7.1-channel
using surround
back speakers
Not used Not used [Off] [Off] [7.1] 18
7.1-channel
using front high
speakers
Not used Not used [Off] [Off] [7.1 (FH)] 19
5.1-channel with
Zone 2 speakers
2-channel Not used [Off] [Off] [5.1] 20
3.1-channel with
Zone 2 and
Zone 3
connections
2-channel 2-channel [Off] [Zone3] [3.1] 21
5.1-channel with
Bi-Amplifier
connection
Not used Not used [Bi-Amp] [Off] [5.1] 22
5.1-channel with
Front B speakers
Not used Not used [Front B] [Off] [5.1] 23
Note
