STR-K1600
• Circuit Boards Location
SECTION 5
DIAGRAMS
MAIN board
DIGITAL board
HDMI SW board
VIDEO boar
d
DCDC board
(AUS, MY, SP, TH model)
DISPLAY board
POWER KEY board
DCAC board
HEADPHONE board
VIDEO 3 board
STANDBY board
AC SELECT board
(E51 model)
Ver. 1.1
