Sony STR-K760P - Display Board Resistors and Components

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
36
STR-K760P
DISPLAYDIGITAL
R1640 1-216-809-11 METAL CHIP 100 5% 1/10W
R1641 1-216-809-11 METAL CHIP 100 5% 1/10W
R1642 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1643 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1644 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1645 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1646 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1647 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1648 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1649 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1650 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1651 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1652 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1653 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1654 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1655 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1656 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1657 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1658 1-216-809-11 METAL CHIP 100 5% 1/10W
R1660 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1662 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1663 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1664 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1667 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1668 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1669 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1670 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1671 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1672 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1673 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1675 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1676 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1677 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1678 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1679 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1680 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1681 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1682 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1683 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1684 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1685 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1686 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1687 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1688 1-216-864-11 SHORT CHIP 0
R1689 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1690 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1694 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1696 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1697 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1698 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1699 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< VIBRATOR >
X1101 1-795-126-21 VIBRATOR, CRYSTAL 12.288MHz
X1201 1-795-363-21 VIBRATOR, CERAMIC 13.5MHz
X1601 1-767-922-11 VIBRATOR, CERAMIC 16.0MHz
************************************************************
A-4750-437-A DISPLAY BOARD, COMPLETE
***********************
< CAPACITOR >
C100 1-164-159-11 CERAMIC 0.1uF 50V
C101 1-164-159-11 CERAMIC 0.1uF 50V
C105 1-126-795-11 ELECT 10uF 20% 50V
C108 1-164-159-11 CERAMIC 0.1uF 50V
C109 1-164-159-11 CERAMIC 0.1uF 50V
C110 1-128-825-11 CERAMIC 2200PF 5% 50V
C111 1-128-809-11 CERAMIC 100PF 5% 50V
C112 1-128-809-11 CERAMIC 100PF 5% 50V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-126-795-11 ELECT 10uF 20% 50V
C132 1-128-813-11 CERAMIC 220PF 5% 50V
C133 1-128-813-11 CERAMIC 220PF 5% 50V
C134 1-128-813-11 CERAMIC 220PF 5% 50V
C135 1-128-813-11 CERAMIC 220PF 5% 50V
C136 1-128-813-11 CERAMIC 220PF 5% 50V
C137 1-128-813-11 CERAMIC 220PF 5% 50V
C138 1-128-813-11 CERAMIC 220PF 5% 50V
C139 1-128-813-11 CERAMIC 220PF 5% 50V
C140 1-128-813-11 CERAMIC 220PF 5% 50V
C141 1-128-813-11 CERAMIC 220PF 5% 50V
C142 1-128-813-11 CERAMIC 220PF 5% 50V
C143 1-128-813-11 CERAMIC 220PF 5% 50V
C144 1-164-159-11 CERAMIC 0.1uF 50V
C150 1-164-159-11 CERAMIC 0.1uF 50V
C151 1-126-795-11 ELECT 10uF 20% 50V
C152 1-128-813-11 CERAMIC 220PF 5% 50V
C153 1-128-813-11 CERAMIC 220PF 5% 50V
C154 1-128-813-11 CERAMIC 220PF 5% 50V
C155 1-164-159-11 CERAMIC 0.1uF 50V
C156 1-164-159-11 CERAMIC 0.1uF 50V
C157 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CNP101 1-564-518-11 PLUG, CONNECTOR 3P
* CNP103 1-564-517-11 PLUG, CONNECTOR 2P
< CONNECTOR >
CNS100 1-569-323-11 SOCKET, CONNECTOR 19P
< DIODE >
D102 8-719-061-96 DIODE SLR-325DCT31 (2CH)
D103 8-719-061-96 DIODE SLR-325DCT31 (MUSIC)
D104 8-719-061-96 DIODE SLR-325DCT31 (MOVIE)
D105 8-719-061-96 DIODE SLR-325DCT31 (A.F.D.)
< FLUORECENT INDICATOR TUBE >
FL101 1-518-966-11 VOCUUM FLUORESENT DISPLAYS
< IC >
IC100 8-759-643-83 IC PT6315
IC101 8-759-243-51 IC TC74ACT08P
IC102 6-600-309-01 IC RPM7240-H9 ( )
