Sony STR-K760P - Main;Power Board Resistors (R675-R803); Relays, Terminals, and Switches

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
41
STR-K760P
R675 1-247-863-91 CARBON 22K 5% 1/4W
R676 1-247-863-91 CARBON 22K 5% 1/4W
R677 1-249-431-11 CARBON 15K 5% 1/4W
R680 1-247-863-91 CARBON 22K 5% 1/4W
R681 1-247-843-11 CARBON 3.3K 5% 1/4W
R690 1-247-887-00 CARBON 220K 5% 1/4W
0 R691 1-216-452-11 METAL OXIDE 180 5% 2W
0 R692 1-215-888-00 METAL OXIDE 220 5% 2W
(EXCEPT CND)
0 R692 1-215-889-00 METAL OXIDE 330 5% 2W
(CND)
R693 1-249-429-11 CARBON 10K 5% 1/4W
R694 1-249-429-11 CARBON 10K 5% 1/4W
R695 1-249-429-11 CARBON 10K 5% 1/4W
R696 1-249-435-11 CARBON 33K 5% 1/4W
R698 1-249-429-11 CARBON 10K 5% 1/4W
R699 1-247-895-00 CARBON 470K 5% 1/4W
R701 1-247-831-91 CARBON 1K 5% 1/4W
R702 1-249-439-11 CARBON 68K 5% 1/4W
R703 1-249-421-11 CARBON 2.2K 5% 1/4W
R704 1-249-439-11 CARBON 68K 5% 1/4W
R710 1-249-421-11 CARBON 2.2K 5% 1/4W
R711 1-249-440-11 CARBON 82K 5% 1/4W
R713 1-249-414-11 CARBON 560 5% 1/4W
R714 1-249-405-11 CARBON 100 5% 1/4W
R715 1-249-405-11 CARBON 100 5% 1/4W
0 R716 1-234-182-11 ENCAPSULATED COMPONENT
R717 1-249-393-11 CARBON 10 5% 1/4W
R718 1-249-389-11 CARBON 4.7 5% 1/4W
R719 1-247-847-91 CARBON 4.7K 5% 1/4W
R721 1-247-850-11 CARBON 6.2K 5% 1/4W
R722 1-249-419-11 CARBON 1.5K 5% 1/4W
R723 1-247-871-91 CARBON 47K 5% 1/4W
R724 1-249-431-11 CARBON 15K 5% 1/4W
R725 1-249-439-11 CARBON 68K 5% 1/4W
R731 1-247-847-91 CARBON 4.7K 5% 1/4W
R732 1-249-381-11 CARBON 1 5% 1/4W
R733 1-249-381-11 CARBON 1 5% 1/4W
R734 1-249-404-00 CARBON 82 5% 1/4W
R735 1-249-427-11 CARBON 6.8K 5% 1/4W
R736 1-247-831-91 CARBON 1K 5% 1/4W
R737 1-249-436-11 CARBON 39K 5% 1/4W
R740 1-247-863-91 CARBON 22K 5% 1/4W
R744 1-247-863-91 CARBON 22K 5% 1/4W
R745 1-247-863-91 CARBON 22K 5% 1/4W
R746 1-247-863-91 CARBON 22K 5% 1/4W
R747 1-249-431-11 CARBON 15K 5% 1/4W
R748 1-247-843-11 CARBON 3.3K 5% 1/4W
R750 1-247-863-91 CARBON 22K 5% 1/4W
R751 1-247-831-91 CARBON 1K 5% 1/4W
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-421-11 CARBON 2.2K 5% 1/4W
R754 1-249-439-11 CARBON 68K 5% 1/4W
R755 1-247-863-91 CARBON 22K 5% 1/4W
R756 1-247-863-91 CARBON 22K 5% 1/4W
R757 1-249-431-11 CARBON 15K 5% 1/4W
R758 1-247-843-11 CARBON 3.3K 5% 1/4W
R760 1-249-421-11 CARBON 2.2K 5% 1/4W
R761 1-249-440-11 CARBON 82K 5% 1/4W
R763 1-249-414-11 CARBON 560 5% 1/4W
R764 1-249-405-11 CARBON 100 5% 1/4W
R765 1-249-405-11 CARBON 100 5% 1/4W
0 R766 1-234-182-11 ENCAPSULATED COMPONENT
R767 1-249-393-11 CARBON 10 5% 1/4W
R768 1-249-389-11 CARBON 4.7 5% 1/4W
R769 1-247-847-91 CARBON 4.7K 5% 1/4W
R770 1-247-871-91 CARBON 47K 5% 1/4W
R771 1-247-850-11 CARBON 6.2K 5% 1/4W
R772 1-249-419-11 CARBON 1.5K 5% 1/4W
R773 1-247-871-91 CARBON 47K 5% 1/4W
R775 1-249-439-11 CARBON 68K 5% 1/4W
R778 1-249-431-11 CARBON 15K 5% 1/4W
R780 1-249-429-11 CARBON 10K 5% 1/4W
R791 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R792 1-215-868-00 METAL OXIDE 680 5% 1W
R793 1-249-404-00 CARBON 82 5% 1/4W
0 R794 1-215-868-00 METAL OXIDE 680 5% 1W
R802 1-249-409-11 CARBON 220 5% 1/4W
R803 1-249-389-11 CARBON 4.7 5% 1/4W
< RESISTOR >
RR11 1-249-393-11 CARBON 10 5% 1/4W
(AUS)
RR12 1-249-393-11 CARBON 10 5% 1/4W
(AUS)
RR13 1-249-393-11 CARBON 10 5% 1/4W
(AUS)
RR14 1-249-393-11 CARBON 10 5% 1/4W
(AUS)
RR15 1-249-393-11 CARBON 10 5% 1/4W
(AUS)
< RELAY >
RY501 1-755-421-11 RELAY
RY560 1-755-267-11 RELAY
RY601 1-755-421-11 RELAY
RY701 1-755-421-11 RELAY
RY791 1-755-421-11 RELAY
< TERMINAL >
TM601 1-694-785-11 TERMINAL BOARD (SURROUND)
TM602 1-694-805-11 TERMINAL BOARD (FRONT)
************************************************************
1-861-045-11 POWER BOARD
************
< RESISTOR >
R124 1-247-847-91 CARBON 4.7K 5% 1/4W
< SWITCH >
S122 1-771-410-21 SWITCH, TACTILE (DIMMER)
S123 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S152 1-771-410-21 SWITCH, TACTILE (?/1)
************************************************************
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MAIN POWER
