Sony STR-K760P - Video Board Capacitors and Resistors; Miscellaneous Components and Power Transformers

Ref. No. Part No. Description Remarks
43
STR-K760P
C210 1-126-964-11 ELECT 10uF 20% 50V
C213 1-126-934-11 ELECT 220uF 20% 16V
C214 1-164-159-11 CERAMIC 0.1uF 50V
C215 1-164-159-11 CERAMIC 0.1uF 50V
C248 1-128-825-11 CERAMIC 2200PF 5% 50V
C809 1-126-934-11 ELECT 220uF 20% 16V
C824 1-164-159-11 CERAMIC 0.1uF 50V
C825 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP156 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< CONNECTOR >
CNS250 1-569-315-11 SOCKET, CONNECTOR 5P
< IC >
IC203 8-759-333-84 IC NJM2279D
IC804 8-759-701-65 IC NJM79M05FA
IC807 8-759-231-53 IC TA7805S
< JACK >
J200 1-794-978-11 JACK, PIN 3P (DVD/VIDEO 1/VIDEO 2)
J201 1-815-043-11 JACK, PIN 2P (MONITOR/VIDEO 1)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
************************************************************
MISCELLANEOUS
**************
8 1-773-114-11 WIRE (FLAT TYPE) (19 CORE)
0 59 1-777-071-23 POWER SUPPLY CORD (E51,MY,SP)
0 59 1-783-820-11 CORD, POWER (CND)
0 59 1-827-295-21 CORD, POWER (AUS)
65 1-693-577-13 TUNER UNIT (CND,E51)
65 1-693-580-24 TUNER UNIT (AUS,MY,SP)
0 F901 1-532-464-32 FUSE (T2.5AL/250V)(E51)
0 F901 1-532-503-51 FUSE (T1.6AL/250V)(AUS,MY,SP)
0 F901 1-533-452-12 FUSE, GLASS TUBE (DIA. 5)(T4.0AL/125V)
(CND)
Q503 8-749-010-25 IC MN2488-OPY-M
Q504 8-749-010-26 IC MP1620-OPY-M
Q603 8-749-010-25 IC MN2488-OPY-M
Q604 8-749-010-26 IC MP1620-OPY-M
Q653 8-749-010-25 IC MN2488-OPY-M
Q654 8-749-010-26 IC MP1620-OPY-M
Q703 8-749-010-25 IC MN2488-OPY-M
Q704 8-749-010-26 IC MP1620-OPY-M
Q753 8-749-010-25 IC MN2488-OPY-M
Q754 8-749-010-26 IC MP1620-OPY-M
0 T901 1-443-185-11 POWER TRANSFORMER (CND)
0 T901 1-443-186-11 POWER TRANSFORMER (E51)
0 T901 1-443-211-11 POWER TRANSFORMER (AUS,MY,SP)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
VIDEO
