Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM2/KM3
70
L3510 1-481-524-11 INDUCTOR 10uH (KM3)
* L3511 1-460-416-11 COMMON MODE CHOKE COIL (KM3)
* L3512 1-460-416-11 COMMON MODE CHOKE COIL (KM3)
L3514 1-412-977-41 INDUCTOR 0.68uH (KM3)
L3515 1-412-975-31 INDUCTOR 0.47uH (KM3)
< RESISTOR >
R3042 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(KM3)
R3510 1-218-933-11 METAL CHIP 22 5% 1/16W
(KM3)
R3511 1-218-933-11 METAL CHIP 22 5% 1/16W
(KM3)
R3517 1-218-933-11 METAL CHIP 22 5% 1/16W
(KM3)
R3518 1-218-933-11 METAL CHIP 22 5% 1/16W
(KM3)
R3520 1-218-933-11 METAL CHIP 22 5% 1/16W
(KM3)
R3521 1-218-933-11 METAL CHIP 22 5% 1/16W
(KM3)
R3523 1-218-973-11 METAL CHIP 47K 5% 1/16W
(KM3)
R3524 1-218-973-11 METAL CHIP 47K 5% 1/16W
(KM3)
R3530 1-218-973-11 METAL CHIP 47K 5% 1/16W
(KM3)
R3567 1-218-937-11 METAL CHIP 47 5% 1/16W
(KM3)
R3578 1-218-937-11 METAL CHIP 47 5% 1/16W
(KM3)
R3579 1-218-945-11 METAL CHIP 220 5% 1/16W
(KM3)
R3583 1-218-945-11 METAL CHIP 220 5% 1/16W
(KM3)
R3587 1-218-989-11 METAL CHIP 1M 5% 1/16W
(KM3)
R3588 1-218-990-81 SHORT CHIP 0 (KM3)
R3590 1-218-935-11 METAL CHIP 33 5% 1/16W
(KM3)
R3592 1-218-935-11 METAL CHIP 33 5% 1/16W
(KM3)
R3593 1-218-941-81 METAL CHIP 100 5% 1/16W
(KM3)
R3598 1-218-943-11 METAL CHIP 150 5% 1/16W
(KM3)
R3599 1-218-937-11 METAL CHIP 47 5% 1/16W
(KM3)
R3601 1-218-943-11 METAL CHIP 150 5% 1/16W
(KM3)
R3623 1-218-941-81 METAL CHIP 100 5% 1/16W
(KM3)
R3624 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(KM3)
* R3625 1-250-491-11 METAL CHIP 680 1% 1/16W
(KM3)
R3626 1-218-929-11 METAL CHIP 10 5% 1/16W
(KM3)
R3627 1-218-929-11 METAL CHIP 10 5% 1/16W
(KM3)
R3628 1-218-990-81 SHORT CHIP 0 (KM3)
R3629 1-218-937-11 METAL CHIP 47 5% 1/16W
(KM3)
R3630 1-250-453-11 METAL CHIP 18 1% 1/16W
(KM3)
R3631 1-218-937-11 METAL CHIP 47 5% 1/16W
(KM3)
R3634 1-218-965-11 METAL CHIP 10K 5% 1/16W
(KM3)
R3638 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
(KM3)
R3639 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
(KM3)
R3640 1-218-973-11 METAL CHIP 47K 5% 1/16W
(KM3)
R3641 1-218-953-11 METAL CHIP 1K 5% 1/16W
(KM3)
R3658 1-218-938-11 METAL CHIP 56 5% 1/16W
(KM3)
R3659 1-218-938-11 METAL CHIP 56 5% 1/16W
(KM3)
R3660 1-218-938-11 METAL CHIP 56 5% 1/16W
(KM3)
R3661 1-218-938-11 METAL CHIP 56 5% 1/16W
(KM3)
R3662 1-218-938-11 METAL CHIP 56 5% 1/16W
(KM3)
R3663 1-218-938-11 METAL CHIP 56 5% 1/16W
(KM3)
R3664 1-218-938-11 METAL CHIP 56 5% 1/16W
(KM3)
R3665 1-218-937-11 METAL CHIP 47 5% 1/16W
(KM3)
R3666 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(KM3)
R3676 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(KM3)
R3678 1-218-937-11 METAL CHIP 47 5% 1/16W
(KM3)
R3679 1-218-941-81 METAL CHIP 100 5% 1/16W
(KM3)
R3681 1-218-941-81 METAL CHIP 100 5% 1/16W
(KM3)
R3684 1-208-859-81
METAL CHIP 68 0.5% 1/16W
(KM3)
R3685 1-208-859-81 METAL CHIP 68 0.5% 1/16W
(KM3)
R3694 1-218-941-81 METAL CHIP 100 5% 1/16W
(KM3)
R3695 1-218-981-91 METAL CHIP 220K 5% 1/16W
(KM3)
R3697 1-218-965-11 METAL CHIP 10K 5% 1/16W
(KM3)
R3710 1-218-965-11 METAL CHIP 10K 5% 1/16W
(KM3)
R3711 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
(KM3)
R3712 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
(KM3)
R3713 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
(KM3)
R3722 1-218-949-11 METAL CHIP 470 5% 1/16W
(KM3)
R3725 1-218-973-11 METAL CHIP 47K 5% 1/16W
(KM3)
R3726 1-250-521-11 METAL CHIP 12K 1% 1/16W
(KM3)
* R3727 1-250-523-11 METAL CHIP 15K 1% 1/16W
(KM3)
* R3728 1-250-479-11 METAL CHIP 220 1% 1/16W
(KM3)
HDMI RE
Ver. 1.2
