Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM2/KM3
71
R3746 1-218-965-11 METAL CHIP 10K 5% 1/16W
(KM3)
R3747 1-218-965-11 METAL CHIP 10K 5% 1/16W
(KM3)
R3748 1-218-965-11 METAL CHIP 10K 5% 1/16W
(KM3)
R3756 1-218-965-11 METAL CHIP 10K 5% 1/16W
(KM3)
R3757 1-218-990-81 SHORT CHIP 0 (KM3)
R3758 1-218-965-11 METAL CHIP 10K 5% 1/16W
(KM3)
R3759 1-218-990-81 SHORT CHIP 0 (KM3)
R3760 1-218-965-11 METAL CHIP 10K 5% 1/16W
(KM3)
R3761 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
(KM3)
R3762 1-218-990-81 SHORT CHIP 0 (KM3)
R3763 1-218-990-81 SHORT CHIP 0 (KM3)
R3765 1-218-990-81 SHORT CHIP 0 (KM3)
R3773 1-218-965-11 METAL CHIP 10K 5% 1/16W
(KM3)
R3780 1-218-990-81 SHORT CHIP 0 (KM3)
R3781 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
(KM3)
R3782 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
(KM3)
R3784 1-218-990-81 SHORT CHIP 0 (KM3)
* R3785 1-250-523-11 METAL CHIP 15K 1% 1/16W
(KM3)
R3788 1-250-487-11 METAL CHIP 470 1% 1/16W
(KM3)
R3789 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(KM3)
R3790 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
(KM3)
< COMPOSITION CIRCUIT BLOCK >
RB3500 1-234-714-11 RES, NETWORK 56 (1005X4) (KM3)
RB3501 1-234-714-11 RES, NETWORK 56 (1005X4) (KM3)
RB3502 1-234-714-11 RES, NETWORK 56 (1005X4) (KM3)
RB3503 1-234-714-11 RES, NETWORK 56 (1005X4) (KM3)
RB3505 1-234-714-11 RES, NETWORK 56 (1005X4) (KM3)
RB3506 1-234-714-11 RES, NETWORK 56 (1005X4) (KM3)
RB3507 1-234-714-11 RES, NETWORK 56 (1005X4) (KM3)
RB3508 1-234-714-11 RES, NETWORK 56 (1005X4) (KM3)
RB3509 1-234-372-11 RES, NETWORK 100 (1005X4) (KM3)
RB3510 1-234-371-11 RES, NETWORK 47 (1005X4) (KM3)
< VIBRATOR >
X3501 1-814-023-11 QUARTS CRYSTAL UNIT (27MHz) (KM3)
*************************************************************
LED BAR BOARD
**************
< CAPACITOR >
C123 1-114-321-11 CERAMIC CHIP 0.0022uF 10% 50V
C124 1-114-321-11 CERAMIC CHIP 0.0022uF 10% 50V
C130 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C134 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C137 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN104 1-779-283-11 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
CN106 1-775-377-51 LEAD (WITH CONNECTOR)
< DIODE >
D130 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D130 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D132 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D132 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D133 6-503-719-01 DI 1L0352W32B0MIT01 (EXCEPT SAF)
D133 6-503-721-01 DI 1L0353Y22G3MKT01 (SAF)
D135 6-503-719-01 DI 1L0352W32B0MIT01 (EXCEPT SAF)
D135 6-503-721-01 DI 1L0353Y22G3MKT01 (SAF)
D136 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D136 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D138 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D138 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D139 6-503-719-01 DI 1L0352W32B0MIT01 (EXCEPT SAF)
D139 6-503-721-01 DI 1L0353Y22G3MKT01 (SAF)
D141 6-503-719-01 DI 1L0352W32B0MIT01 (EXCEPT SAF)
D141 6-503-721-01 DI 1L0353Y22G3MKT01 (SAF)
D142 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D142 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D144 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D144 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D146 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D146 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D147 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D147 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D155 6-503-013-01 DI DZ2J043M0L
D156 6-503-013-01 DI DZ2J043M0L
D157 6-503-013-01 DI DZ2J043M0L
D158 6-503-013-01 DI DZ2J043M0L
D159 6-503-013-01 DI DZ2J043M0L
D160 6-503-013-01 DI DZ2J043M0L
< JUMPER RESISTOR >
JR200 1-216-296-11 SHORT CHIP 0
JR201 1-216-296-11 SHORT CHIP 0
JR202 1-216-864-11 SHORT CHIP 0
JR203 1-216-296-11 SHORT CHIP 0
JR204 1-216-296-11 SHORT CHIP 0
JR205 1-216-296-11 SHORT CHIP 0
JR206 1-216-296-11 SHORT CHIP 0
JR207 1-216-296-11 SHORT CHIP 0
JR208 1-216-296-11 SHORT CHIP 0
JR209 1-216-296-11 SHORT CHIP 0
JR210 1-216-296-11 SHORT CHIP 0
JR211 1-216-296-11 SHORT CHIP 0
JR212 1-216-296-11 SHORT CHIP 0
JR213 1-216-864-11 SHORT CHIP 0
JR214 1-216-296-11 SHORT CHIP 0
JR215 1-216-296-11 SHORT CHIP 0
JR217 1-216-296-11 SHORT CHIP 0
JR221 1-216-296-11 SHORT CHIP 0
JR230 1-216-296-11 SHORT CHIP 0
JR231 1-216-864-11 SHORT CHIP 0
JR232 1-216-296-11 SHORT CHIP 0
JR233 1-216-296-11 SHORT CHIP 0
JR234 1-216-296-11 SHORT CHIP 0
