Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM2/KM3
72
JR235 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R140 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R140 1-216-815-11 METAL CHIP 330 5% 1/10W
(SAF)
R142 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R142 1-216-815-11 METAL CHIP 330 5% 1/10W
(SAF)
R143 1-216-810-11 METAL CHIP 120 5% 1/10W
(EXCEPT SAF)
R143 1-216-812-11 METAL CHIP 180 5% 1/10W
(SAF)
R145 1-216-810-11 METAL CHIP 120 5% 1/10W
(EXCEPT SAF)
R145 1-216-812-11 METAL CHIP 180 5% 1/10W
(SAF)
R146 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R146 1-216-815-11 METAL CHIP 330 5% 1/10W
(SAF)
R148 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R148 1-216-815-11 METAL CHIP 330 5% 1/10W
(SAF)
R149 1-216-810-11 METAL CHIP 120 5% 1/10W
(EXCEPT SAF)
R149 1-216-812-11 METAL CHIP 180 5% 1/10W
(SAF)
R151 1-216-810-11 METAL CHIP 120 5% 1/10W
(EXCEPT SAF)
R151 1-216-812-11 METAL CHIP 180 5% 1/10W
(SAF)
R152 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R152 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
R154 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R154 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
R156 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R156 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
R157 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R157 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
R159 1-216-837-11 METAL CHIP 22K 5% 1/10W
R160 1-216-833-11 METAL CHIP 10K 5% 1/10W
R161 1-216-821-11 METAL CHIP 1K 5% 1/10W
R162 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R163 1-216-821-11 METAL CHIP 1K 5% 1/10W
< ROTARY ENCODER >
RV101 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S101 1-762-875-21 SWITCH, TACTILE (SURROUND SPEAKER)
S102 1-762-875-21 SWITCH, TACTILE (MOVIE)
S103 1-762-875-21 SWITCH, TACTILE (M-TURBO)
S104 1-762-875-21 SWITCH, TACTILE (MUSIC)
S105 1-762-875-21 SWITCH, TACTILE (GAMING)
*************************************************************
A-1852-012-A MAIN BOARD, COMPLETE (MX)
A-1852-073-A MAIN BOARD, COMPLETE (KM3: EXCEPT MX)
A-1852-273-A MAIN BOARD, COMPLETE (KM2)
*********************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
7-685-647-71 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
C300 1-126-964-11 ELECT 10uF 20% 50V
C301 1-126-964-11 ELECT 10uF 20% 50V
C302 1-126-964-11 ELECT 10uF 20% 50V
C304 1-126-964-11 ELECT 10uF 20% 50V
C305 1-126-964-11 ELECT 10uF 20% 50V
C306 1-126-964-11 ELECT 10uF 20% 50V
C307 1-126-964-11 ELECT 10uF 20% 50V (KM3)
C308 1-126-964-11 ELECT 10uF 20% 50V
C310 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C311 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C312 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C313 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C314 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C315 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C316 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C317 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V (KM3)
C318 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C319 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C326 1-126-963-11 ELECT 4.7uF 20% 50V
C328 1-126-963-11 ELECT 4.7uF 20% 50V
C332 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C333 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C334 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C500 1-126-964-11 ELECT 10uF 20% 50V
C501 1-126-923-91 ELECT 220uF 20% 10V
C502 1-114-324-11 CERAMIC CHIP 0.022uF 10% 50V
C507 1-126-947-11 ELECT 47uF 20% 35V
C510 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C512 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C514 1-116-138-11 CERAMIC CHIP 4PF 0.25PF 100V
C515 1-116-137-91 CERAMIC CHIP 12PF 5% 100V
C516 1-114-324-11 CERAMIC CHIP 0.022uF 10% 50V
C518 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
C519 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
C520 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C550 1-126-964-11 ELECT 10uF 20% 50V
C551 1-126-923-91 ELECT 220uF 20% 10V
C552 1-114-324-11 CERAMIC CHIP 0.022uF 10% 50V
C557 1-126-947-11 ELECT 47uF 20% 35V
C560 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C562 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C564 1-116-138-11 CERAMIC CHIP 4PF 0.25PF 100V
C565 1-116-137-91 CERAMIC CHIP 12PF 5% 100V
C566 1-114-324-11 CERAMIC CHIP 0.022uF 10% 50V
C568 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
C569 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
C600 1-126-964-11 ELECT 10uF 20% 50V
C601 1-126-923-91 ELECT 220uF 20% 10V
MAINLED BAR
Ver. 1.2
