Sony STR-KM3 - Page 77

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM2/KM3
77
RY355 1-755-307-21 RELAY
RY950 1-755-593-11 RELAY
< TERMINAL >
TB352 1-780-932-11 TERMINAL BOARD (SPEAKERS SUBWOOFER)
TB353 1-820-067-21 TERMINAL BOARD (SPEAKER)
(SPEAKERS FRONT L/R)
TB354 1-780-812-21 TERMINAL BOARD (SPEAKER)
(SPEAKERS CENTER) (KM3)
TB355 1-820-067-21 TERMINAL BOARD (SPEAKER)
(SPEAKERS SURROUND L/R)
*************************************************************
A-1852-100-A POWER AVIDEO BOARD, COMPLETE (KM3: SAF)
A-1852-109-A POWER AVIDEO BOARD, COMPLETE (TH, AUS)
A-1852-125-A POWER AVIDEO BOARD, COMPLETE (EA)
A-1852-233-A POWER AVIDEO BOARD, COMPLETE (KM3: E51)
A-1852-251-A POWER AVIDEO BOARD, COMPLETE (MX)
A-1852-264-A POWER AVIDEO BOARD, COMPLETE (KM3: AR)
A-1852-274-A POWER AVIDEO BOARD, COMPLETE (KM2: SAF)
A-1852-317-A POWER AVIDEO BOARD, COMPLETE (KM2: E51)
A-1852-339-A POWER AVIDEO BOARD, COMPLETE (KM2: AR)
A-1879-728-A POWER AVIDEO BOARD, COMPLETE (SP)
A-1887-724-A POWER AVIDEO BOARD, COMPLETE (RU)
*****************************
< CAPACITOR >
C205 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C901 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C902 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C903 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C904 1-126-936-11 ELECT 3300uF 20% 16V
C905 1-126-960-11 ELECT 1uF 20% 50V
C906 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C911 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C912 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C916 1-126-952-11 ELECT 1000uF 20% 35V
< CONNECTOR >
CN271 1-842-650-11 CONNECTOR, BOARD TO BOARD 12P
* CN911 1-564-507-11 PLUG, CONNECTOR 4P
CN912 1-842-639-11 CONNECTOR, BOARD TO BOARD 9P
* CNP901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
* CNP902 1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
* CNP903 1-564-687-11 PIN, CONNECTOR (3.96mm PITCH) 3P
(KM2: E51/KM3: E51, EA, MX)
< DIODE >
D901 6-502-961-01 DI DA2J10100L
D902 6-500-848-01 DIODE MC2840-T112-1
D903 6-500-848-01 DIODE MC2840-T112-1
D904 6-500-335-01 DIODE MC2838-T112-1
D912 6-503-401-01 DI D3SBA60-7101
< FUSE >
0 F911 1-523-086-11 FUSE (3.15A/250V)
0 F912 1-523-086-11 FUSE (3.15A/250V)
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
(KM2: EXCEPT E51/KM3: EXCEPT MX)
FH902 1-533-217-41 HOLDER, FUSE
(KM2: EXCEPT E51/KM3: EXCEPT MX)
FH903 1-533-217-41 HOLDER, FUSE (KM2: E51/KM3: E51, EA, MX)
FH904 1-533-217-41 HOLDER, FUSE (KM2: E51/KM3: E51, EA, MX)
< JUMPER RESISTOR >
JR200 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q901 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q902 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R201 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(RU)
R201 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(TH, AUS)
R201 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SP)
R201 1-216-837-11 METAL CHIP 22K 5% 1/10W
(SAF)
R201 1-216-841-11 METAL CHIP 47K 5% 1/10W
(KM2: E51, AR/KM3: AR, E51, EA, MX)
R203 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(MX)
R203 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(AR)
R203 1-216-837-11 METAL CHIP 22K 5% 1/10W
(E51)
R203 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EXCEPT E51, AR, MX)
R902 1-249-399-11 CARBON 33 5% 1/4W
R903 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R904 1-216-841-11 METAL CHIP 47K 5% 1/10W
R905 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R906 1-216-835-11 METAL CHIP 15K 5% 1/10W
R907 1-216-833-11 METAL CHIP 10K 5% 1/10W
< RELAY >
0 RY901 1-755-541-11 RELAY
< SWITCH >
S901 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (KM2: E51/KM3: E51, EA)
< TRANSFORMER >
0 T902 1-443-518-11 POWER TRANSFORMER (SUB) (MX)
0 T902 1-697-150-11 POWER TRANSFORMER (SUB)
(KM2: E51/KM3: E51, EA)
0 T902 1-697-152-11 POWER TRANSFORMER (SUB)
(EXCEPT E51, EA, MX)
< EARTH TERMINAL >
TM200 4-924-264-01 TERMINAL, MOUNT
*************************************************************
POWER KEY BOARD
****************
< CAPACITOR >
C100 1-114-321-11 CERAMIC CHIP 0.0022uF 10% 50V
C101 1-114-321-11 CERAMIC CHIP 0.0022uF 10% 50V
POWER KEYPOWER AVIDEOMAIN
Ver. 1.2
