Sony STR-KM3 - Page 78

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM2/KM3
78
C132 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C133 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN107 1-775-377-51 LEAD (WITH CONNECTOR)
< DIODE >
D100 6-503-719-01 DI 1L0352W32B0MIT01 (EXCEPT SAF)
D100 6-503-721-01 DI 1L0353Y22G3MKT01 (SAF)
D102 6-503-719-01 DI 1L0352W32B0MIT01 (EXCEPT SAF)
D102 6-503-721-01 DI 1L0353Y22G3MKT01 (SAF)
D103 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D103 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D105 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D105 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D107 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D107 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D109 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D109 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
< JUMPER RESISTOR >
JR250 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R100 1-216-837-11 METAL CHIP 22K 5% 1/10W
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R102 1-216-810-11 METAL CHIP 120 5% 1/10W
(EXCEPT SAF)
R102 1-216-812-11 METAL CHIP 180 5% 1/10W
(SAF)
R104 1-216-810-11 METAL CHIP 120 5% 1/10W
(EXCEPT SAF)
R104 1-216-812-11 METAL CHIP 180 5% 1/10W
(SAF)
R105 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R105 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
R107 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R107 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
R109 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R109 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
R111 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R111 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
< ROTARY ENCODER >
RV100 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(INPUT SELECTOR)
< SWITCH >
S100 1-762-875-21 SWITCH, TACTILE (\/1)
*************************************************************
THERMAL BOARD
**************
< CAPACITOR >
C250 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
< RESISTOR >
R251 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R252 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
< THERMISTOR >
0 TH251 1-804-045-11 THERMISTOR
0 TH252 1-804-045-11 THERMISTOR
*************************************************************
TUNER1 BOARD
*************
< CAPACITOR >
C101 1-100-155-91 CERAMIC CHIP 470PF 5% 100V
C102 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C103 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C105 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C106 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C107 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C108 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C109 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C111 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C112 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
< CONNECTOR >
CN101 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
* CN103 1-506-680-11 PLUG, CONNECTOR (2.5MM) 3P (ANTENNA AM)
CN104 1-780-920-11 TERMINAL (FMAMF)
(ANTENNA 75Ω COAXIAL FM) (MX)
< DIODE >
D101 6-501-579-01 DIODE MC2837
D102 6-501-579-01 DIODE MC2837
D103 6-501-579-01 DIODE MC2837
< FILTER >
FL101 1-236-711-21 FILTER, BAND PASS
< IC >
IC101 6-717-980-01 IC RZ5B801-0001E2 (MX)
IC101
6-717-981-01 IC RZ5B801-0002E2 (EXCEPT MX)
IC102 6-715-134-01 IC MM3404A33URE
< JUMPER RESISTOR >
JR101 1-216-864-1
1 SHORT CHIP 0
JR102 1-216-296-11 SHORT CHIP 0
JR105 1-216-296-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR109 1-216-296-11 SHORT CHIP 0
JR112 1-216-296-11 SHORT CHIP 0
THERMALPOWER KEY TUNER1
Ver. 1.2
