Sony STR-KM3 - Page 79

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM2/KM3
79
< COIL >
L101 1-457-998-11 COIL, AM ANTENNA
L103 1-414-576-41 INDUCTOR 47nH
L104 1-481-330-21 INDUCTOR 220nH
L105 1-481-523-11 INDUCTOR 4.7uH
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-801-11 METAL CHIP 22 5% 1/10W
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-801-11 METAL CHIP 22 5% 1/10W
R106 1-216-809-11 METAL CHIP 100 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-296-11 SHORT CHIP 0
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X101 1-767-317-11 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
A-1851-779-A USB BOARD, COMPLETE (EXCEPT SAF, AR)
********************
< CAPACITOR >
C4101 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
(EXCEPT SAF, AR)
C4109 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4110 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SAF, AR)
C4111 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4112 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4113 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
(EXCEPT SAF, AR)
C4114 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
(EXCEPT SAF, AR)
C4115 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4116 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4117 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4118 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4119 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT SAF, AR)
C4120 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT SAF, AR)
C4121 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4162 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
(EXCEPT SAF, AR)
C4163 1-114-330-11 CERAMIC CHIP 2.2uF 10% 16V
(EXCEPT SAF, AR)
C4164 1-114-330-11 CERAMIC CHIP 2.2uF 10% 16V
(EXCEPT SAF, AR)
C4165 1-114-329-11 CERAMIC CHIP 0.47uF 10% 50V
(EXCEPT SAF, AR)
C4166 1-128-390-11 ELECT CHIP 220uF 20% 6.3V
(EXCEPT SAF, AR)
C4167 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SAF, AR)
C4168 1-128-394-11 ELECT CHIP 220uF 20% 10V
(EXCEPT SAF, AR)
C4169 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4182 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SAF, AR)
C4183 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4185 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4186 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SAF, AR)
C4187 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT SAF, AR)
C4189 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
< CONNECTOR >
CN4100 1-817-097-21 PIN, CONNECTOR (1.5MM) (SMD) 13P
(EXCEPT SAF, AR)
CN4101 1-819-866-11 USB CONNECTOR (A) (
) (EXCEPT SAF, AR)
< DIODE >
D4106 8-719-049-09 DIODE 1SS367-T3SONY (EXCEPT SAF, AR)
D4107 6-500-848-01 DIODE MC2840-T112-1 (EXCEPT SAF, AR)
< EARTH TERMINAL >
* ET4100 1-780-408-11 TERMINAL, LUG (EXCEPT SAF, AR)
< FERRITE BEAD >
FB4100 1-469-118-21 FERRITE, EMI (SMD) (1608) (EXCEPT SAF, AR)
FB4102 1-469-324-21 FERRITE, EMI (SMD) (2012) (EXCEPT SAF, AR)
FB4161 1-481-218-21 FERRITE, EMI (SMD) (1608) (EXCEPT SAF, AR)
< IC >
IC4100 6-717-986-11 IC BU94604BKV-ZAE2 (EXCEPT SAF, AR)
IC4101 6-715-164-01 IC TPS2553DBVR (EXCEPT SAF, AR)
IC4102 6-716-739-01 IC BD00GC0WEFJ-SE2 (EXCEPT SAF, AR)
IC4161 6-705-468-01 IC BA33BC0FP-E2 (EXCEPT SAF, AR)
<RESISTOR>
R4111 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4112 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4114 1-218-990-81 SHORT CHIP 0 (EXCEPT SAF, AR)
R4115 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4116 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4117 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4118 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4119 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4120 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4121 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
TUNER1 USB
Ver. 1.2
