Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM2/KM3
80
USB
R4122 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
(EXCEPT SAF, AR)
R4123 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4124 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4125 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
(EXCEPT SAF, AR)
R4126 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4127 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4129 1-218-873-11 METAL CHIP 12K 0.5% 1/10W
(EXCEPT SAF, AR)
R4130 1-218-989-11 METAL CHIP 1M 5% 1/16W
(EXCEPT SAF, AR)
R4131 1-218-945-11 METAL CHIP 220 5% 1/16W
(EXCEPT SAF, AR)
R4162 1-218-945-11 METAL CHIP 220 5% 1/16W
(EXCEPT SAF, AR)
R4174 1-216-864-11 SHORT CHIP 0 (EXCEPT SAF, AR)
R4175 1-216-864-11 SHORT CHIP 0 (EXCEPT SAF, AR)
R4180 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
(EXCEPT SAF, AR)
R4181 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
(EXCEPT SAF, AR)
R4182 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(EXCEPT SAF, AR)
R4184 1-218-953-11 METAL CHIP 1K 5% 1/16W
(EXCEPT SAF, AR)
R4185 1-218-977-11 METAL CHIP 100K 5% 1/16W
(EXCEPT SAF, AR)
R4186 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4188 1-250-531-11 METAL CHIP 33K 1% 1/16W
(EXCEPT SAF, AR)
* R4189 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
(EXCEPT SAF, AR)
R4190 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4193 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
VD4170 1-811-155-11 ELEMENT, ESD PROTECT (EXCEPT SAF, AR)
VD4171 1-811-155-11 ELEMENT, ESD PROTECT (EXCEPT SAF, AR)
< VIBRATOR >
X4102 1-814-482-11 QUARTZ CRYSTAL UNIT (16.9344MHz)
(EXCEPT SAF, AR)
*************************************************************
MISCELLANEOUS
**************
55 1-828-341-61 WIRE (FLAT TYPE) (15 CORE)
101 1-828-368-61 WIRE (FLAT TYPE) (21 CORE)
104 1-828-310-61 WIRE (FLAT TYPE) (9 CORE)
105 A-1846-561-A TUNER1AMPR ASSY (EXCEPT MX)
105 A-1846-564-A TUNER1AMF ASSY (MX)
0 109 1-777-071-83 CORD, POWER (E51, SAF, RU, SP)
0 109 1-833-566-21 POWER-SUPPLY CORD (AUS)
0 109 1-834-288-21 POWER-SUPPLY CORD (TH)
0 109 1-835-078-31 CORD, POWER (EA)
0 109 1-837-312-11 CORD, POWER-SUPPLY (AR)
0 109 1-837-344-11 CORD, POWER-SUPPLY (MX)
0 110 1-785-504-21 ADAPTOR, CONVERSION (E51)
0 F901 1-532-465-32 FUSE (T3.15AL/250V) (EXCEPT RU, MX)
0 F902 1-532-505-32 FUSE (T5AL/250V) (E51, EA)
0 F902 1-532-506-32 FUSE (T6.3AL/250V) (MX)
0 F954 1-533-949-33 FUSE (T8AL/250V)
0 F955 1-533-949-33 FUSE (T8AL/250V)
Q502 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q503 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q552 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q553 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q602 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q603 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q652 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q653 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q702 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q703 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q752 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q753 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q802 6-702-390-01 TRANSISTOR MN2488-OPY-MK (KM3)
Q803 6-702-391-01 TRANSISTOR MP1620-OPY-MK (KM3)
0 T901 1-697-126-11 POWER TRANSFORMER (MAIN) (E51, EA)
0 T901 1-697-127-11 POWER TRANSFORMER (MAIN)
(EXCEPT E51, EA, MX)
0 T901 1-697-128-11 POWER TRANSFORMER (MAIN) (MX)
Note: If wire (fl at type) is replaced, install it after bending it in the
same form as that before replacement.
Ver. 1.2
