STR-KS360/KS360S
50
HDMI BOARD IC3519 R5F3640DDFBR-128 (HDMI CONTROLLER)
Pin No. Pin Name I/O Description
1 to 5 NC - Not used
6
BYTE I External data bus width selection signal input terminal “L”: 16 bit Fixed at “L” in this set
7
CNVSS I
Processor mode selection signal input terminal “L”: single chip mode
Fixed at “L” in this set
8, 9 NC - Not used
10 RESET I Reset signal input from the system controller “L”: reset
11 XOUT O System clock output terminal (10 MHz)
12 VSS - Ground terminal
13 XIN I System clock input terminal (10 MHz)
14 VCC_3.3V - Power supply terminal (+3.3V)
15
NMI I Non-maskable interrupt signal input terminal Not used
16 to 18 NC - Not used
19 RX_RST O Reset signal output to the HDMI receiver “L”: reset
20 RX_INT I Interrupt signal input from the HDMI receiver
21 RX_HPD1 O Hot plug detection control signal output to the HDMI input selector
22 to 26 NC - Not used
27 CSCL O I2C clock signal output to the EEPROM, HDMI receiver and HDMI transmitter
28 CSDA I/O I2C two-way data bus with the EEPROM, HDMI receiver and HDMI transmitter
29 232COUT O Serial data output terminal for the RS-232C
30 232CIN I Serial data input terminal for the RS-232C
31 CLK1 O Not used
32 RTS O Not used
33 TX I Serial data input from the system controller
34 RX O Serial data output to the system controller
35 EEPROMSEL1 O Write protect signal output to the EEPROM
36 to 39 NC - Not used
40 SPDIF_SEL O SPDIF selection signal output terminal Not used
41 TX_5VPWR O Power supply on/off control signal output terminal for HDMI +5V power “H”: power on
42 TX_RST I Reset signal input from the HDMI transmitter “L”: reset
43 TX_INT O Interrupt signal output to the HDMI transmitter
44 to 48 NC - Not used
49 eHDMI _IN - Not used
50 eHDMI _OUT - Not used
51 to 53 TMDS_S1 to TMDS_S3 O HDMI input selection signal output to the HDMI input selector
54 TMDS_OEB O Output enable signal output to the HDMI input selector
55, 56 P5V_SELA, P5V_SELB O HDMI +5V power input selection signal output terminal
57 to 59 NC - Not used
60 VCC_3.3V - Power supply terminal (+3.3V)
61 NC - Not used
62 VSS - Ground terminal
63, 64 NC - Not used
65 MUTE O HDMI muting control signal output terminal
66 to 90 NC - Not used
91 to 93
MODEL_SW3 to
MODEL_SW1
I Model setting terminal
94 AVSS - Ground terminal
95 NC - Not used
96 VREF I Reference voltage (+3.3V) input terminal
97 AVCC - Power supply terminal (+3.3V)
98 to 100 NC - Not used
