STR-KS360/KS360S
7
SECTION 3
DISASSEMBLY
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE
3-2. CASE
(Page 7)
3-4. IO BOARD
(Page 8)
3-3. S-AIR BOARD (KS360S)
(Page 8)
3-6. MAIN BOARD
(Page 9)
3-5. FRONT PANEL BLOCK
(Page 9)
SET
two screws
(BV3)
case
two tapping screws
two tapping screws
Lift up the case
in the direction of arrow.
two claws
