Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KS360/KS360S
5555
9 A-1629-328-A HDMI BOARD, COMPLETE (for SERVICE)
********************
< CAPACITOR >
C3501 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3502 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3505 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3508 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3509 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3511 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3512 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3513 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3516 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3517 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3518 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3519 1-126-210-21 ELECT CHIP 220uF 20% 4V
C3521 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3522 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3523 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3524 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3525 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3526 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3527 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3529 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3530 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3531 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3533 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3534 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3535 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3536 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3537 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3538 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C3539 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3540 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C3541 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3542 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3543 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3544 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3545 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3547 1-100-053-21 ELECT CHIP 220uF 20% 6.3V
C3548 1-126-210-21 ELECT CHIP 220uF 20% 4V
C3549 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3550 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3551 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3552 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3553 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3555 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3556 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3557 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3558 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3561 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3562 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3563 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3564 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3566 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3567 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3568 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3569 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3570 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3571 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3572 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C3573 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3574 1-126-210-21 ELECT CHIP 220uF 20% 4V
C3575 1-100-053-21 ELECT CHIP 220uF 20% 6.3V
C3576 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C3579 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3580 1-165-667-21 ELECT CHIP 100uF 20% 6.3V
C3584 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C3585 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C3586 1-117-681-11 ELECT CHIP 100uF 20% 16V
C3590 1-128-934-11 CERAMIC CHIP 0.33uF 20% 10V
C3591 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3593 1-128-994-21 ELECT CHIP 47uF 20% 10V
C3596 1-128-994-21 ELECT CHIP 47uF 20% 10V
C3597 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3615 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3616 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3617 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3618 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3619 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3620 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3621 1-112-791-11 ELECT CHIP 100uF 20% 16V
C3625 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3627 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3630 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3631 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3632 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3633 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3634 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3635 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3644 1-126-210-21 ELECT CHIP 220uF 20% 4V
C3646 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C3655 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C3656 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3657 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3661 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C3662 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN3501 1-820-735-31 HDMI CONNECTOR (HDMI BD IN)
CN3502 1-820-735-31 HDMI CONNECTOR (HDMI DVD IN)
CN3503 1-820-735-31 HDMI CONNECTOR (HDMI SAT IN)
CN3504 1-820-735-31 HDMI CONNECTOR (HDMI OUT)
CN3509 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN3510 1-784-859-51 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN3511 1-820-116-41 CONNECTOR, FFC/FPC 17P
< DIODE >
D3501 8-719-049-09 DIODE 1SS367-T3SONY
D3502 8-719-049-09 DIODE 1SS367-T3SONY
D3510 8-719-053-18 DIODE 1SR154-400TE-25
< EARTH TERMINAL >
* ET3504 1-780-408-11 TERMINAL, LUG
