Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KS360/KS360S
58
C271 1-126-933-11 ELECT 100uF 20% 16V
C272 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C273 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C274 1-126-964-11 ELECT 10uF 20% 50V
C275 1-126-964-11 ELECT 10uF 20% 50V
C276 1-126-964-11 ELECT 10uF 20% 50V
C277 1-126-964-11 ELECT 10uF 20% 50V
C278 1-126-933-11 ELECT 100uF 20% 16V
C280 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C281 1-126-947-11 ELECT 47uF 20% 35V
C282 1-126-947-11 ELECT 47uF 20% 35V
C283 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C284 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
< CONNECTOR >
CNS200 1-779-293-11 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
CNS250 1-784-770-11 CONNECTOR, FFC 9P
(KS360/KS360S: US, CND, AUS)
CNS251 1-568-830-11 CONNECTOR, FFC 11P (KS360S: AEP, UK)
< FERRITE BEAD >
FB200 1-414-760-21 FERRITE, EMI (SMD) (1608)
< IC >
IC200 8-759-710-97 IC NJM4565M-D
IC201 8-759-710-97 IC NJM4565M-D
IC202 6-600-466-01 IC TORX147L (SONY) (DIGITAL OPT IN SA
T)
IC203 6-600-466-01 IC TORX147L (SONY) (TV OPT IN)
IC209 8-759-278-58 IC NJM4558V-TE2
IC210 8-759-524-09 IC TC74VHC153FT (EL)
IC211 8-759-591-61 IC TC7WHU04FU (TE12R)
IC212 6-703-518-01 IC BD3842FS-FD2
< JACK >
J200 1-563-330-31 JACK (AUTO CAL MIC)
J201 1-784-920-11 JACK, PIN 6P (VIDEO 1 AUDIO IN,
TV AUDIO IN, SA-CD/CD AUDIO IN)
J202 1-784-431-11 JACK, PIN 1P (DIGITAL COAX IN VIDEO 2)
< COIL >
L200 1-469-525-91 INDUCTOR 10uH
L201 1-414-406-41 INDUCTOR 220uH
< TRANSISTOR >
Q200 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q201 8-729-038-28 TRANSISTOR RT1N441C-TP-1
< RESISTOR >
R200 1-216-833-11 METAL CHIP 10K 5% 1/10W
R201 1-216-833-11 METAL CHIP 10K 5% 1/10W
R206 1-216-833-11 METAL CHIP 10K 5% 1/10W
R207 1-216-833-11 METAL CHIP 10K 5% 1/10W
R208 1-216-833-11 METAL CHIP 10K 5% 1/10W
R209 1-216-833-11 METAL CHIP 10K 5% 1/10W
R210 1-216-833-11 METAL CHIP 10K 5% 1/10W
R211 1-216-833-11 METAL CHIP 10K 5% 1/10W
R216 1-218-285-11 METAL CHIP 75 5% 1/10W
R217 1-216-817-11 METAL CHIP 470 5% 1/10W
R218 1-216-841-11 METAL CHIP 47K 5% 1/10W
R219 1-216-853-11 METAL CHIP 470K 5% 1/10W
R220 1-216-809-11 METAL CHIP 100 5% 1/10W
R221 1-216-821-11 METAL CHIP 1K 5% 1/10W
R222 1-216-821-11 METAL CHIP 1K 5% 1/10W
R223 1-216-821-11 METAL CHIP 1K 5% 1/10W
R224 1-216-821-11 METAL CHIP 1K 5% 1/10W
R225 1-216-821-11 METAL CHIP 1K 5% 1/10W
R226 1-216-821-11 METAL CHIP 1K 5% 1/10W
R227 1-216-845-11 METAL CHIP 100K 5% 1/10W
R228 1-216-845-11 METAL CHIP 100K 5% 1/10W
R229 1-216-845-11 METAL CHIP 100K 5% 1/10W
R230 1-216-845-11 METAL CHIP 100K 5% 1/10W
R231 1-216-845-11 METAL CHIP 100K 5% 1/10W
R232 1-216-845-11 METAL CHIP 100K 5% 1/10W
R241 1-216-841-11 METAL CHIP 47K 5% 1/10W
R242 1-216-841-11 METAL CHIP 47K 5% 1/10W
R243 1-216-841-11 METAL CHIP 47K 5% 1/10W
R252 1-216-841-11 METAL CHIP 47K 5% 1/10W
R253 1-216-841-11 METAL CHIP 47K 5% 1/10W
R254 1-216-841-11 METAL CHIP 47K 5% 1/10W
R255 1-216-841-11 METAL CHIP 47K 5% 1/10W
R256 1-216-841-11 METAL CHIP 47K 5% 1/10W
R257 1-216-841-11 METAL CHIP 47K 5% 1/10W
R258 1-216-841-11 METAL CHIP 47K 5% 1/10W
R262 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R263 1-216-845-11 METAL CHIP 100K 5% 1/10W
R264 1-216-817-11 METAL CHIP 470 5% 1/10W
R265 1-216-821-11 METAL CHIP 1K 5% 1/10W
R266 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R267 1-216-817-11 METAL CHIP 470 5% 1/10W
R268 1-216-838-11 METAL CHIP 27K 5% 1/10W
R269 1-216-837-11 METAL CHIP 22K 5% 1/10W
R270 1-216-809-11 METAL CHIP 100 5% 1/10W
R271 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R272 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R273 1-216-821-11 METAL CHIP 1K 5% 1/10W
R274 1-216-833-11 METAL CHIP 10K 5% 1/10W
R275 1-216-833-11 METAL CHIP 10K 5% 1/10W
R276 1-216-809-11 METAL CHIP 100 5% 1/10W
R277 1-216-809-11 METAL CHIP 100 5% 1/10W
R281 1-216-841-11 METAL CHIP 47K 5% 1/10W
R282 1-216-809-11 METAL CHIP 100 5% 1/10W
R283 1-216-809-11 METAL CHIP 100 5% 1/10W
R284 1-216-809-11 METAL CHIP 100 5% 1/10W
R285 1-216-809-11 METAL CHIP 100 5% 1/10W
R286 1-216-809-11 METAL CHIP 100 5% 1/10W
R287 1-216-809-11 METAL CHIP 100 5% 1/10W
R288 1-216-809-11 METAL CHIP 100 5% 1/10W
R289 1-216-841-11 METAL CHIP 47K 5% 1/10W
R290 1-216-841-11 METAL CHIP 47K 5% 1/10W
R291 1-216-821-11 METAL CHIP 1K 5% 1/10W
(KS360S: AEP, UK)
R292 1-216-821-11 METAL CHIP 1K 5% 1/10W
R293 1-216-821-11 METAL CHIP 1K 5% 1/10W
R294 1-216-821-11 METAL CHIP 1K 5% 1/10W
R295 1-216-821-11 METAL CHIP 1K 5% 1/10W
R296 1-216-841-11 METAL CHIP 47K 5% 1/10W
R297 1-216-841-11 METAL CHIP 47K 5% 1/10W
************************************************************
