Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KS360/KS360S
6767
< VIBRATOR >
X1000 1-814-271-11 QUARTS CRYSTAL UNIT (25MHz)
X1001 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
X1700 1-814-109-21 VIBRATOR, CRYSTAL (12.288MHz)
X3000 1-814-108-21 VIBRATOR, CRYSTAL (49.1MHz)
************************************************************
S-AIR BOARD (KS360S)
***********
< CONNECTOR >
CN100 1-821-744-11 CONNECTOR, CARD EDGE 30P (EZW-T100)
CN104 1-770-411-11 CONNECTOR, BOARD TO BOARD 20P
< RESISTOR >
R100 1-216-833-11 METAL CHIP 10K 5% 1/10W
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
R105 1-216-864-11 SHORT CHIP 0
R106 1-216-864-11 SHORT CHIP 0
R107 1-216-864-11 SHORT CHIP 0
R108 1-216-864-11 SHORT CHIP 0
R109 1-216-833-11 METAL CHIP 10K 5% 1/10W
************************************************************
A-1629-285-A SMPS BOARD, COMPLETE
(KS360/KS360S: US, CND)
A-1629-286-A SMPS BOARD, COMPLETE
(KS360S: AEP, UK, AUS)
********************
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
< CAPACITOR >
0 C901 1-165-529-11 MYLAR 0.22uF 10 275V
0 C902 1-165-529-11 MYLAR 0.22uF 10 275V
0 C903 1-112-330-11 ELECT (BLOCK) 1000uF 20% 200V
(KS360/KS360S: US, CND)
0 C903 1-112-333-11 ELECT (BLOCK) 330uF 20% 450V
(KS360S: AEP, UK, AUS)
C905 1-136-601-11 FILM 0.01uF 5% 630V
(KS360/KS360S: US, CND)
C905 1-136-557-11 FILM 0.0033uF 5% 630V
(KS360S: AEP, UK, AUS)
C906 1-117-815-11 FILM 1000PF 3% 1.5KV
(KS360S: AEP, UK, AUS)
C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(KS360S: AEP, UK, AUS)
C907 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
(KS360/KS360S: US, CND)
C908 1-107-909-11 ELECT 47uF 20% 50V
C909 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C910 1-107-906-11 ELECT 10uF 20% 50V
(KS360/KS360S: US, CND)
C910 1-107-907-11 ELECT 22uF 20% 50V
(KS360S: AEP, UK, AUS)
C911 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C913 1-117-693-51 CERAMIC 100PF 10% 250V
0 C918 1-113-925-51 CERAMIC 0.01uF 20% 250V
0 C920 1-113-925-51 CERAMIC 0.01uF 20% 250V
C922 1-128-560-11 ELECT 22uF 20% 100V
C923 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C924 1-126-961-11 ELECT 2.2uF 20% 50V
C925 1-107-974-81 CERAMIC 47PF 5% 2KV
0 C928 1-117-695-51 CERAMIC 220PF 10% 250V
(KS360/KS360S: US, CND)
0 C928 1-117-697-51 CERAMIC 470PF 10% 250V
(KS360S: AEP, UK, AUS)
C929 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
0 C930 1-117-693-51 CERAMIC 100PF 10% 250V
C932 1-114-994-11 ELECT 2200uF 20% 35V
C933 1-114-994-11 ELECT 2200uF 20% 35V
C934 1-100-924-21 ELECT 2200uF 20% 35V
C935 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C936 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C937 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
0 C938 1-117-696-51 CERAMIC 330PF 10% 250V
(KS360/KS360S: US, CND)
0 C938 1-117-698-51 CERAMIC 680PF 10% 250V
(KS360S: AEP, UK, AUS)
C939 1-136-165-00 FILM 0.1uF 5% 50V
C940 1-128-947-31 ELECT 3300uF 20% 10V
C941 1-128-954-11 ELECT 1000uF 20% 25V
C942 1-126-941-11 ELECT 470uF 20% 25V
C943 1-126-933-11 ELECT 100uF 20% 16V
C944 1-128-951-21 ELECT 2200uF 20% 16V
C945 1-126-935-11 ELECT 470uF 20% 16V
C947 1-104-658-91 ELECT 100uF 20% 10V
C948 1-126-925-91 ELECT 470uF 20% 10V
C949 1-165-722-11 ELECT 100uF 20% 10V
C951 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C952 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C953 1-117-214-11 CERAMIC 0.001uF 10% 2KV
C954 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C955 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C958 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C960 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
0 C963 1-117-699-51 CERAMIC 0.001uF 20% 250V
(KS360S: AEP, UK, AUS)
0 C963 1-117-700-51 CERAMIC 0.0022uF 20% 250V
(KS360/KS360S: US, CND)
0 C964 1-117-699-51 CERAMIC 0.001uF 20% 250V
(KS360S: AEP, UK, AUS)
0 C964 1-117-700-51 CERAMIC 0.0022uF 20% 250V
(KS360/KS360S: US, CND)
0 C965 1-117-699-51 CERAMIC 0.001uF 20% 250V
(KS360S: AEP, UK, AUS)
C967 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C969 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C970 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C971 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C972 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C973 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C980 1-117-828-11 FILM 3300PF 3% 1.5KV
(KS360/KS360S: US, CND)
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN904 1-564-241-11 PIN, CONNECTOR (3.96mm PITCH) 4P
CN906 1-568-672-11 CONNECTOR, BOARD TO BOARD 12P
< DIODE >
0 D901 8-719-082-57 DIODE D5SBA60F01
0 D905 8-719-063-74 DIODE D1NL20U-TR2
