Sony STR-SL5 - Parts Identification; Main Unit Components

4
GB
Display 7 (20)
DVD 4 (17)
IR receptor 2
MASTER VOLUME 9 (17)
MUTING qs (17)
PLII q; (19)
PRESET TUNING +/– 8 (24)
SOUND FIELD qa (18, 21)
TUNER 6 (17, 23, 24)
TV/SAT 5 (17)
VIDEO 3 (17)
?/1 (power) 1 (12, 16, 17, 22)
Parts Identification
Main unit
The items are arranged in alphabetical order.
Refer to the pages indicated in parentheses ( ) for details.
1 2 3 4 5 6 7 9 q;
qs qa
8
