– 31 –
! R810 1-212-934-00 FUSIBLE 1 5% 1/2W F
! R811 1-212-853-00 FUSIBLE 6.8 5% 1/4W F
! R813 1-212-946-11 FUSIBLE 3.3 5% 1/2W F
R818 1-249-417-11 CARBON 1K 5% 1/4W
R819 1-249-417-11 CARBON 1K 5% 1/4W
R840 1-249-429-11 CARBON 10K 5% 1/4W
R851 1-249-429-11 CARBON 10K 5% 1/4W
R853 1-249-397-11 CARBON 22 5% 1/4W
R854 1-249-441-11 CARBON 100K 5% 1/4W
R856 1-249-429-11 CARBON 10K 5% 1/4W
R857 1-249-435-11 CARBON 33K 5% 1/4W
R858 1-249-437-11 CARBON 47K 5% 1/4W
R859 1-249-439-11 CARBON 68K 5% 1/4W
R860 1-249-421-11 CARBON 2.2K 5% 1/4W
R921 1-249-393-11 CARBON 10 5% 1/4W
R922 1-249-389-11 CARBON 4.7 5% 1/4W
R923 1-249-389-11 CARBON 4.7 5% 1/4W
R944 1-249-417-11 CARBON 1K 5% 1/4W
R971 1-249-393-11 CARBON 10 5% 1/4W
R972 1-249-389-11 CARBON 4.7 5% 1/4W
R973 1-249-389-11 CARBON 4.7 5% 1/4W
R1001 1-249-429-11 CARBON 10K 5% 1/4W
R1002 1-249-429-11 CARBON 10K 5% 1/4W
R1013 1-249-425-11 CARBON 4.7K 5% 1/4W
R1021 1-249-429-11 CARBON 10K 5% 1/4W
R1031 1-247-903-00 CARBON 1M 5% 1/4W
R1032 1-249-413-11 CARBON 470 5% 1/4W
R1033 1-249-433-11 CARBON 22K 5% 1/4W
R1034 1-249-433-11 CARBON 22K 5% 1/4W
R1063 1-249-425-11 CARBON 4.7K 5% 1/4W
R1071 1-249-429-11 CARBON 10K 5% 1/4W
R7001 1-249-421-11 CARBON 2.2K 5% 1/4W
R7002 1-249-429-11 CARBON 10K 5% 1/4W
R7003 1-249-441-11 CARBON 100K 5% 1/4W
R7004 1-249-441-11 CARBON 100K 5% 1/4W
R7005 1-249-441-11 CARBON 100K 5% 1/4W
R7006 1-249-441-11 CARBON 100K 5% 1/4W
R7007 1-249-441-11 CARBON 100K 5% 1/4W
R7008 1-247-807-31 CARBON 100 5% 1/4W
R7009 1-247-807-31 CARBON 100 5% 1/4W
< VARIABLE RESISTOR >
RV771 1-223-672-11 RES, VAR, CARBON 10K (MIC LEVEL)
< RELAY >
RY801 1-515-921-11 RELAY (12V)
< TERMINAL >
TB901 1-537-240-31 TERMINAL BOARD (CHECKER PIN) (SPEAKER)
< VIBRATOR >
X7001 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)
************************************************************
* A-4389-335-A PANEL BOARD, COMPLETE (German)
A-4389-336-A PANEL BOARD, COMPLETE (Italian)
* A-4389-330-A PANEL BOARD, COMPLETE (AEP,AED)
* A-4389-337-A PANEL BOARD, COMPLETE (UK)
**********************
JOG ENCODER BOARD
*******************
KEY BOARD
**********
VOL ENCODER BOARD
*******************
* 4-932-810-01 CUSHION (FL)
* 4-971-014-01 HOLDER, FL TUBE
* 4-978-036-04 HOUSE, LAMP
< CAPACITOR >
C501 1-104-905-11 CAPACITOR 0.22F 5.5V
C502 1-163-059-00 CERAMIC CHIP 0.01uF 10% 50V
C504 1-164-159-11 CERAMIC 0.1uF 50V
C505 1-164-159-11 CERAMIC 0.1uF 50V
C506 1-126-968-11 ELECT 100uF 20% 35V
C511 1-126-968-11 ELECT 100uF 20% 6.3V
C540 1-164-159-11 CERAMIC 0.1uF 50V
C541 1-126-233-11 ELECT 22uF 20% 50V
C542 1-164-159-11 CERAMIC 0.1uF 50V
C543 1-163-165-00 CERAMIC CHIP 22PF 5% 50V
C544 1-163-163-00 CERAMIC CHIP 18PF 5% 50V
C545 1-164-159-11 CERAMIC 0.1uF 50V
C5001 1-101-006-00 CERAMIC 0.047uF 50V
C5002 1-124-464-11 ELECT 0.22uF 20% 50V
C5003 1-101-004-00 CERAMIC 0.01uF 50V
C5004 1-130-473-00 MYLAR 0.0015uF 5% 50V
C5005 1-136-155-00 FILM 0.015uF 5% 50V
C5006 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C5007 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C5020 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C5021 1-124-907-11 ELECT 10uF 20% 50V
C5031 1-126-956-91 ELECT 0.1uF 20% 50V
C5032 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C5033 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C5034 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN501 1-774-344-11 PLUG, CONNECTOR (PC BOARD) 18P
CN502 1-774-343-11 PLUG, CONNECTOR (PC BOARD) 16P
< DIODE >
D503 8-719-014-73 DIODE UZP-5.6BC-TP
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
VOL ENCODER
KEY
JOG ENCODER
MAIN
PANEL
To Next Page
