– 35 –
S529 1-572-184-11 SWITCH, KEYBOARD (REPEAT TIMER SELECT)
S530 1-572-184-11 SWITCH, KEYBOARD (PLAY MODE TIMER SET)
S531 1-572-184-11 SWITCH, KEYBOARD (1/ALL DISCS CLOCKSET)
S551 1-473-480-11 ENCODER, ROTARY (JOG ENCORDER)
S552 1-467-869-11 ENCODER, ROTARY (VOL ENCORDER)
< VIBRATOR >
X501 1-579-233-11 VIBRATOR, CERAMIC (5.0MHz)
X502 1-567-098-41 VIBRATOR, CRYSTAL (32kHz)
************************************************************
* A-4389-334-A POWER AMPLIFIER BOARD, COMPLETE
(EXCEPT UK)
* A-4389-341-A POWER AMPLIFIER BOARD, COMPLETE (UK)
********************************
< CAPACITOR >
C901 1-126-963-11 ELECT 4.7uF 20% 50V
C902 1-162-293-31 CERAMIC 820PF 10% 50V
C903 1-162-286-31 CERAMIC 220PF 10% 50V
C904 1-126-967-11 ELECT 47uF 20% 50V
C905 1-126-967-11 ELECT 47uF 20% 50V
C906 1-136-163-00 FILM 0.068uF 5% 50V
C907 1-136-163-00 FILM 0.068uF 5% 50V
C929 1-164-159-11 CERAMIC 0.1uF 50V
C932 1-124-910-11 ELECT 47uF 20% 50V
C933 1-164-159-11 CERAMIC 0.1uF 50V
C934 1-126-968-11 ELECT 100uF 20% 50V
C937 1-126-965-11 ELECT 22uF 20% 50V
C938 1-126-934-11 ELECT 220uF 20% 16V
C940 1-124-910-11 ELECT 47uF 20% 50V
C950 1-136-161-00 FILM 0.047uF 5% 50V
C951 1-126-963-11 ELECT 4.7uF 20% 50V
C952 1-162-293-31 CERAMIC 820PF 10% 50V
C953 1-162-286-31 CERAMIC 220PF 10% 50V
C954 1-126-967-11 ELECT 47uF 20% 50V
C955 1-126-967-11 ELECT 47uF 20% 50V
C956 1-136-163-00 FILM 0.068uF 5% 50V
C957 1-136-163-00 FILM 0.068uF 5% 50V
< DIODE >
D903 8-719-987-63 DIODE 1N4148M
D953 8-719-987-63 DIODE 1N4148M
< IC >
IC901 8-749-920-09 IC STK-4152MK2K
< TRANSISTOR >
Q901 8-729-900-80 TRANSISTOR DTC114ES
Q902 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q952 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R121 1-249-441-11 CARBON 100K 5% 1/4W
R171 1-249-441-11 CARBON 100K 5% 1/4W
R901 1-249-417-11 CARBON 1K 5% 1/4W
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-249-413-11 CARBON 470 5% 1/4W
R904 1-249-437-11 CARBON 47K 5% 1/4W
R906 1-249-425-11 CARBON 4.7K 5% 1/4W
R907 1-249-425-11 CARBON 4.7K 5% 1/4W
R908 1-249-425-11 CARBON 4.7K 5% 1/4W
R909 1-249-425-11 CARBON 4.7K 5% 1/4W
R910 1-249-397-11 CARBON 22 5% 1/4W
R911 1-249-397-11 CARBON 22 5% 1/4W
R913 1-249-417-11 CARBON 1K 5% 1/4W
R914 1-249-431-11 CARBON 15K 5% 1/4W
R915 1-249-441-11 CARBON 100K 5% 1/4W
! R920 1-217-151-00 RES, METAL PLATE 0.22
! R932 1-212-881-11 FUSIBLE 100 5% 1/4W F
R933 1-249-421-11 CARBON 2.2K 5% 1/4W
R934 1-249-421-11 CARBON 2.2K 5% 1/4W
R935 1-249-421-11 CARBON 2.2K 5% 1/4W
R936 1-249-421-11 CARBON 2.2K 5% 1/4W
R937 1-249-437-11 CARBON 47K 5% 1/4W
R938 1-249-441-11 CARBON 100K 5% 1/4W
R939 1-249-433-11 CARBON 22K 5% 1/4W
R940 1-249-433-11 CARBON 22K 5% 1/4W
R941 1-249-429-11 CARBON 10K 5% 1/4W
R942 1-249-413-11 CARBON 470 5% 1/4W
! R943 1-212-881-11 FUSIBLE 100 5% 1/4W F
R951 1-249-417-11 CARBON 1K 5% 1/4W
R952 1-249-437-11 CARBON 47K 5% 1/4W
R953 1-249-413-11 CARBON 470 5% 1/4W
R954 1-249-437-11 CARBON 47K 5% 1/4W
R956 1-249-425-11 CARBON 4.7K 5% 1/4W
R957 1-249-425-11 CARBON 4.7K 5% 1/4W
R958 1-249-425-11 CARBON 4.7K 5% 1/4W
R959 1-249-425-11 CARBON 4.7K 5% 1/4W
R960 1-249-397-11 CARBON 22 5% 1/4W
R961 1-249-397-11 CARBON 22 5% 1/4W
R963 1-249-417-11 CARBON 1K 5% 1/4W
R964 1-249-431-11 CARBON 15K 5% 1/4W
R965 1-249-441-11 CARBON 100K 5% 1/4W
! R970 1-217-151-00
RES, METAL PLATE
0.22
! R998 1-212-849-00 FUSIBLE 4.7 5% 1/4W F
! R999 1-212-849-00 FUSIBLE 4.7 5% 1/4W F
************************************************************
* 1-660-130-11 SURROUND BOARD
****************
< CONNECTOR >
CN902 1-564-517-11 PLUG, CONNECTOR 2P
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
SURROUND
POWER AMPLIFIER
VOL ENCODER
KEY
JOG ENCODER
PANEL
To Next Page
