– 34 –
R560 1-216-170-00 METAL GLAZE 68 5% 1/8W
R561 1-216-170-00 METAL GLAZE 68 5% 1/8W
R562 1-216-170-00 METAL GLAZE 68 5% 1/8W
R563 1-216-170-00 METAL GLAZE 68 5% 1/8W
R564 1-216-009-00 METAL CHIP 22 5% 1/10W
R565 1-216-170-00 METAL GLAZE 68 5% 1/8W
R566 1-216-009-00 METAL CHIP 22 5% 1/10W
R568 1-249-425-11 CARBON 4.7K 5% 1/4W
R569 1-249-429-11 CARBON 10K 5% 1/4W
R570 1-249-393-11 CARBON 10 5% 1/4W
R576 1-249-429-11 CARBON 10K 5% 1/4W
R577 1-247-807-31 CARBON 100 5% 1/4W
R578 1-247-807-31 CARBON 100 5% 1/4W
R579 1-247-807-31 CARBON 100 5% 1/4W
R580 1-247-807-31 CARBON 100 5% 1/4W
R581 1-216-025-91 METAL GLAZE 100 5% 1/10W
R582 1-216-025-91 METAL GLAZE 100 5% 1/10W
R583 1-247-807-31 CARBON 100 5% 1/4W
R584 1-247-807-31 CARBON 100 5% 1/4W
R585 1-247-807-31 CARBON 100 5% 1/4W
R586 1-247-807-31 CARBON 100 5% 1/4W
R587 1-247-807-31 CARBON 100 5% 1/4W
R588 1-247-807-31 CARBON 100 5% 1/4W
R589 1-247-807-31 CARBON 100 5% 1/4W
R592 1-247-807-31 CARBON 100 5% 1/4W
R593 1-247-807-31 CARBON 100 5% 1/4W
R594 1-216-174-00 METAL GLAZE 100 5% 1/8W
R596 1-247-807-31 CARBON 100 5% 1/4W
R597 1-247-807-31 CARBON 100 5% 1/4W
R598 1-247-807-31 CARBON 100 5% 1/4W
R599 1-247-807-31 CARBON 100 5% 1/4W
R5001 1-216-085-00 METAL CHIP 33K 5% 1/10W
R5002 1-216-085-00 METAL CHIP 33K 5% 1/10W
R5003 1-216-085-00 METAL CHIP 33K 5% 1/10W
R5004 1-216-073-00 METAL CHIP 10K 5% 1/10W
R5009 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R5010 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R5011 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R5012 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R5013 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R5014 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R5015 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R5016 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R5017 1-249-429-11 CARBON 10K 5% 1/4W
R5018 1-249-429-11 CARBON 10K 5% 1/4W
R5019 1-249-421-11 CARBON 2.2K 5% 1/4W
R5020 1-249-429-11 CARBON 10K 5% 1/4W
R5021 1-249-429-11 CARBON 10K 5% 1/4W
R5022 1-249-429-11 CARBON 10K 5% 1/4W
R5023 1-249-429-11 CARBON 10K 5% 1/4W
R5026 1-216-073-00 METAL CHIP 10K 5% 1/10W
R5027 1-216-222-00 METAL GLAZE 10K 5% 1/8W
R5028 1-249-441-11 CARBON 100K 5% 1/4W
R5029 1-249-441-11 CARBON 100K 5% 1/4W
R5030 1-249-441-11 CARBON 100K 5% 1/4W
R5031 1-249-429-11 CARBON 10K 5% 1/4W
(AEP,UK,AED)
R5031 1-249-427-11 CARBON 6.8K 5% 1/4W
(German,Italian)
R5032 1-249-423-11 CARBON 3.3K 5% 1/4W
R5033 1-249-441-11 CARBON 100K 5% 1/4W
R5038 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R5051 1-249-421-11 CARBON 2.2K 5% 1/4W
R5052 1-249-409-11 CARBON 220 5% 1/4W
R5053 1-249-409-11 CARBON 220 5% 1/4W
R5071 1-249-423-11 CARBON 3.3K 5% 1/4W
R5072 1-216-073-00 METAL CHIP 10K 5% 1/10W
R5073 1-249-423-11 CARBON 3.3K 5% 1/4W
R5074 1-216-073-00 METAL CHIP 10K 5% 1/10W
R5075 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R5076 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R5077 1-249-429-11 CARBON 10K 5% 1/4W
R5078 1-249-429-11 CARBON 10K 5% 1/4W
R5079 1-249-437-11 CARBON 47K 5% 1/4W
R5082 1-216-073-00 METAL CHIP 10K 5% 1/10W
R5083 1-216-073-00 METAL CHIP 10K 5% 1/10W
R5084 1-216-073-00 METAL CHIP 10K 5% 1/10W
< SWITCH >
S501 1-554-303-21 SWITCH, TACTILE (SYSTEM POWER)
S502 1-554-303-21 SWITCH, TACTILE (TIMER)
S503 1-554-303-21 SWITCH, TACTILE (SLEEP)
S505 1-554-303-21 SWITCH, TACTILE (KARAOKE PON/MPX)
S506 1-554-303-21 SWITCH, TACTILE (EFECT ON/OFF)
S507 1-554-303-21 SWITCH, TACTILE (MENU 1)
S508 1-554-303-21 SWITCH, TACTILE (MENU 2)
S509 1-554-303-21 SWITCH, TACTILE (MENU 3)
S510 1-554-303-21 SWITCH, TACTILE (MENU 4)
S511 1-554-303-21 SWITCH, TACTILE (MEMORY)
S512 1-554-303-21 SWITCH, TACTILE (SURROUND)
S513 1-554-303-21 SWITCH, TACTILE (FUNCTION)
S514 1-554-303-21 SWITCH, TACTILE (DISPLAY)
S515 1-554-303-21 SWITCH, TACTILE (TUNER/BAND)
S517 1-554-303-21 SWITCH, TACTILE (P.FILE)
S518 1-554-303-21 SWITCH, TACTILE (DBFB)
S519 1-554-303-21 SWITCH, TACTILE (GROOVE)
S520 1-554-303-21 SWITCH, TACTILE (FREQUENCY +)
S521 1-554-303-21 SWITCH, TACTILE (ENTER/NEXT)
S522 1-554-303-21 SWITCH, TACTILE (FREQUENCY -)
S523 1-572-184-11 SWITCH, KEYBOARD (CLIP C)
S524 1-572-184-11 SWITCH, KEYBOARD (CLIP B)
S525 1-572-184-11 SWITCH, KEYBOARD (CLIP A)
S526 1-572-184-11 SWITCH, KEYBOARD (CLIP PLAY TUNER
MEMORY)
S527 1-572-184-11 SWITCH, KEYBOARD (CLIP ERASE)
S528 1-572-184-11 SWITCH, KEYBOARD (EDIT TUNING MODE)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
VOL ENCODER
KEY
JOG ENCODER
PANEL
