Sony STR-W55 - Front Panel Section

– 38 –
Sony Corporation
Consumer A&V Products Company
Home A&V Products Div.
< VARIABLE RESISTOR >
RV41 1-238-601-11 RES, ADJ, CARBON 22K (AM TUNING LEVEL)
RV42 1-238-600-11 RES, ADJ, CARBON 10K (FM TUNING LEVEL)
< TERMINAL >
TM1 1-537-488-11 TERMINAL BOARD (ANTENNA)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL
X41 1-760-220-11 FILTER, CERAMIC (10.7MHz)
X42 1-527-981-00 FILTER, CERAMIC (450kHz)
X43 1-577-075-11 OSCILLATOR, CERAMIC (456kHz)
************************************************************
* 1-658-764-11 TRANSFORMER A BOARD
*********************
1-533-293-11 FUSE HOLDER
< CONNECTOR >
CN851 1-564-321-00 PIN, CONNECTOR 2P
< FUSE >
! F851 1-532-285-00 FUSE,TIME LAG (1.25A / 250V)
************************************************************
* 1-658-765-11 TRANSFORMER B BOARD
*********************
1-533-293-11 FUSE HOLDER
< CONNECTOR >
* CN852 1-564-527-11 PLUG, CONNECTOR 12P
< FUSE >
! F853 1-532-203-00 FUSE,TIME LAG (2A / 250V)
! F854 1-532-203-00 FUSE,TIME LAG (2A / 250V)
! F855 1-532-203-00 FUSE,TIME LAG (2A / 250V)
! F856 1-532-203-00 FUSE,TIME LAG (2A / 250V)
************************************************************
MISCELLANEOUS
***************
5 1-533-293-11 FUSE HOLDER
! CNP801 1-574-805-11 CORD, POWER (EXCEPT UK)
! CNP801 1-696-570-21 CORD, POWER (UK)
* E801 4-942-204-01 PLATE, GROUND
FL501 1-517-483-11 INDICATOR TUBE, FLUORESCENT
! F851 1-532-285-00 FUSE,TIME LAG (1.25A / 250V)
! F853 1-532-203-00 FUSE,TIME LAG (2A / 250V)
! F854 1-532-203-00 FUSE,TIME LAG (2A / 250V)
! F855 1-532-203-00 FUSE,TIME LAG (2A / 250V)
! F856 1-532-203-00 FUSE,TIME LAG (2A / 250V)
! T801 1-429-258-11 TRANSFORMER, POWER (EXCEPT UK)
! T801 1-429-643-11 TRANSFORMER, POWER (UK)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-473-463-11 COMMANDER, STANDARD (RM-SW55)
1-501-804-11 ANTENNA (FM)
1-776-017-11 CORD (WITH CONNECTOR) (17P) (SYSTEM
CONTROL 1)
1-776-018-11 CODE (WITH CONNECTOR) (7P) (SYSTEM
CONTROL 2)
4-941-762-11 COVER (MLY), BATTERY (FOR RM-SW55)
* 4-979-069-01 CUSHION (STR) (FRONT)
* 4-979-070-01 CUSHION (STR) (REAR)
* 4-980-779-01 CARTON, INDIVIDUAL
************************************************************
******************
HARDWARE LIST
******************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-682-548-04 SCREW +BVTT 3X8 (S)
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
STR-W55
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
9-960-415-31
English
96B027558-1
Printed in Germany
© 1996.2
Published by Home A&V Products Div.
Quality Engineering Dept.
TRANSFORMER A
TCB
TRANSFORMER B
