Sony STRDG500S - DIGITAL Board; MAIN Board Section

12
STR-DG500/DG600
2-4. DIGITAL BOARD
2-5. MAIN BOARD SECTION
4 screw
(+BVTP 3
× 8)
5 DIGITAL boar
d
1 CNP505 (10P)
2 CNP503 (5P)
3 CNP504 (7P)
5 two screws
(+BV3 (3
-CR) )
8 MAIN board section
6 two screws
(+BV3 (3
-CR) )
7 screw
(+BV3 (3
-CR) )
1 CNP600 (5P)
3 CNP801 (3P)
4 CNP802 (5P)
2 CNP601 (4P)
