Sony STRDG500S - Digital Display

67
STR-DG500/DG600
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R1455 1-216-864-11 SHORT CHIP 0
R1456 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DG600)
R1460 1-216-864-11 SHORT CHIP 0
R1461 1-216-864-11 SHORT CHIP 0
R1463 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1464 1-216-864-11 SHORT CHIP 0
R1466 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1470 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1471 1-216-864-11 SHORT CHIP 0
R1472 1-216-864-11 SHORT CHIP 0
R1473 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1474 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1475 1-216-864-11 SHORT CHIP 0
R1476 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1483 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1484 1-216-864-11 SHORT CHIP 0
R1486 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1490 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1491 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1492 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1493 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1494 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1495 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1501 1-216-809-11 METAL CHIP 100 5% 1/10W
R1502 1-216-809-11 METAL CHIP 100 5% 1/10W
R1503 1-216-813-11 METAL CHIP 220 5% 1/10W
R1504 1-216-809-11 METAL CHIP 100 5% 1/10W
R1505 1-216-809-11 METAL CHIP 100 5% 1/10W
R1506 1-216-809-11 METAL CHIP 100 5% 1/10W
R1507 1-216-809-11 METAL CHIP 100 5% 1/10W
R1508 1-216-809-11 METAL CHIP 100 5% 1/10W
R1509 1-216-809-11 METAL CHIP 100 5% 1/10W
R1510 1-216-809-11 METAL CHIP 100 5% 1/10W
R1511 1-216-809-11 METAL CHIP 100 5% 1/10W
R1512 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1513 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1514 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1515 1-216-857-11 METAL CHIP 1M 5% 1/10W
R1523 1-216-813-11 METAL CHIP 220 5% 1/10W
R1524 1-216-864-11 SHORT CHIP 0
R1530 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1541 1-216-813-11 METAL CHIP 220 5% 1/10W
R1555 1-216-813-11 METAL CHIP 220 5% 1/10W
R1556 1-216-809-11 METAL CHIP 100 5% 1/10W
R1557 1-216-813-11 METAL CHIP 220 5% 1/10W
R1570 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1571 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1572 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1573 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1574 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1635 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1636 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1801 1-216-809-11 METAL CHIP 100 5% 1/10W
(DG600)
R1802 1-216-809-11 METAL CHIP 100 5% 1/10W
(DG600)
R1803 1-216-809-11 METAL CHIP 100 5% 1/10W
(DG600)
R1804 1-216-809-11 METAL CHIP 100 5% 1/10W
(DG600)
R1805 1-216-809-11 METAL CHIP 100 5% 1/10W
(DG600)
R1806 1-216-809-11 METAL CHIP 100 5% 1/10W
(DG600)
R1807 1-216-809-11 METAL CHIP 100 5% 1/10W
(DG600)
< NETWORK RESISTOR >
RB1500 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1501 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1502 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1503 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1504 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1506 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1507 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1508 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
< VIBRATOR >
X1101 1-813-448-21 PIEZOELECTRIC OSCILLATOR (24MHz)
X1301 1-795-126-21 VIBRATOR, CRYSTAL (12.288MHz)
X1502 1-813-276-21 QUARTZ, CRYSTAL (13.9MHz)
*************************************************************
A-1157-231-A DISPLAY BOARD, COMPLETE (DG500:US,CND)
A-1157-288-A DISPLAY BOARD, COMPLETE
(DG500:EXCEPT US,CND)
A-1157-415-A DISPLAY BOARD, COMPLETE (DG600)
************************
< CAPACITOR >
C100 1-127-888-11 CERAMIC 0.1uF 10% 50V
C101 1-127-888-11 CERAMIC 0.1uF 10% 50V
C104 1-113-342-11 CERAMIC 0.1uF 50V
(DG500)
C104 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DG600)
C105 1-126-795-11 ELECT 10uF 20% 50V
C106 1-127-868-11 CERAMIC 0.0022uF 10% 50V
C107 1-127-868-11 CERAMIC 0.0022uF 10% 50V
C108 1-127-888-11 CERAMIC 0.1uF 10% 50V
C109 1-127-888-11 CERAMIC 0.1uF 10% 50V
C110 1-162-286-31 CERAMIC 220PF 10% 50V
C111 1-162-286-31 CERAMIC 220PF 10% 50V
C112 1-162-286-31 CERAMIC 220PF 10% 50V
C114 1-135-798-11 CERAMIC 0.22uF 50V
C115 1-126-795-11 ELECT 10uF 20% 50V
C132 1-162-286-31 CERAMIC 220PF 10% 50V
C133 1-162-286-31 CERAMIC 220PF 10% 50V
C134 1-162-286-31 CERAMIC 220PF 10% 50V
C135 1-162-286-31 CERAMIC 220PF 10% 50V
C136 1-162-286-31 CERAMIC 220PF 10% 50V
C137 1-162-286-31 CERAMIC 220PF 10% 50V
C138 1-162-286-31 CERAMIC 220PF 10% 50V
C139 1-162-286-31 CERAMIC 220PF 10% 50V
C140 1-162-286-31 CERAMIC 220PF 10% 50V
C141 1-162-286-31 CERAMIC 220PF 10% 50V
C142 1-162-286-31 CERAMIC 220PF 10% 50V
C143 1-162-286-31 CERAMIC 220PF 10% 50V
DIGITAL DISPLAY
