Sony STRDG500S - Page 57

57
STR-DG500/DG600
Pin No. Pin Name I/O Pin Description
52 RDS_CLK/XMDPOWER I/O
RDS data clock signal input (AEP, UK model)/XM digital power control signal output
(STR-DG600)
53
RDS_DATA/
I/O RDS data input (AEP, UK model)/XM command control signal output (STR-DG600)
XM_COMMAND
54 SIRCS I SIRCS signal input
55 HP_DETECT I Headphones detection signal input
56 POWER_KEY I Power key detection signal input
57 ADCC_INT I ADCC data input from DSP IC
58 POWER_RY O Power relay driver control signal output
59 VOL_CL O Clock signal output for DIR IC
60 VOL_DA O Serial data and latch output for DIR IC
61 PROTECTOR I Protector detection signal input
62 HP_RY O Headphone relay driver control signal output
63 FUSE_DETECT I Fuse open detection signal input
64 VOL_ENCODER (B) I MASTER VOLUME encoder (B) signal input
65 VOL_ENCODER (A) I MASTER VOLUME encoder (A) signal input
66 FRONT_RY O Front speaker relay driver control signal output
67 SP_B_RY O Front speaker B relay driver control signal output
68 C/SB_RY O Center/Surround back speaker relay driver control signal output
69 REAR_RY O Surround speaker relay driver control signal output
70 SW_RY O Sub woofer relay driver control signal output
71 ANALOG_SW_CLK (DE8) O Not used (Open)
72 BRIDGEABLE_RY O Bridgeable relay driver control signal output
73 DO I Tuner serial data input
74 SLATCH O Tuner latch signal output
75 TUNED I Tuned signal detection input
76 STEREO I Stereo signal detection input
77 RSTX I Reset signal input
78 MUTE O Tuner mute signal output
79 X1A — Not used (Open)
80 X0A — Not used (Connect to VSS)
81 VSS — Ground
82 X0 — Clock signal input (24 MHz)
83 X1 — Clock signal output (24 MHz)
84 VCC3 — Power supply pin (+3.3 V)
85
ANALOG_SW_DATA
O Not used (Open)
(DE8)
86 D595_DATA O Serial data output for I/O EXPANDER IC
87 D595_CLK O Serial clock signal output for I/O EXPANDER IC
88 D595_OE O Serial output enable signal output for I/O EXPANDER IC
89 D595_LAT O Serial latch signal output for I/O EXPANDER IC
90 SELECT2 O Digital input select 2 signal output (STR-DG600)
91 SELECT1 O Digital input select 1 signal output (STR-DG600)
92 BST_SEL O 96/24 signal output for DSP IC
93 XMODE O Xmode signal output for DIR IC
94 CKSEL1 O Clock select signal output for DIR IC
95 CLK O Data clock signal output for DIR IC
96 CE O Latch signal output for DIR IC
97 DI O Data output for DIR IC
98 DO I Data input from DIR IC
99 ERROR I Error detection signal input from DIR IC
100 XSTATE I Xstate signal input from DIR IC
